Insignia NS-DXA1 Quick Start Manual

Insignia ns-dxa1 digital-to-analog converter box quick start guide
Hide thumbs


Advertisement

Quick Links

Package contents
Digital-to-analog converter box
Remote control
AAA battery
Coaxial cable
RCA audio/video cable
Install remote control battery
Remove the cover from the back of the remote control, insert the battery as shown,
then replace the cover.
Connect to antenna and TV
ANTENNA
INPUT
Converter Box
ANTENNA
INPUT
Converter Box
08-1161_NS-DXA1QSG_eng.indd 1
08-1161_NS-DXA1QSG_eng.indd 1
Method 1 (Better)
TV
1 Connect the antenna to the IN (FROM ANT) jack on your converter box using a
coaxial cable.
2 Connect the R AUDIO, L AUDIO, and VIDEO jacks on your converter box to the
corresponding jacks on your TV using an A/V cable. TV should be tuned to correct
video source (see your TV documentation).
3 Plug the power cable into a power outlet or surge protector.
This is the preferred method for the best video and audio quality.
Method 2 (Good)
TV
1 Connect the antenna to the IN (FROM ANT) jack on your converter box
using a coaxial cable.
2 Connect the OUT (TO TV) jack on your converter box to the Antenna IN jack
on your TV using a coaxial cable. Your TV must be tuned to channel 3. For best
performance with this connection, change the Audio Output option in the
Options menu to Mono. For more information, see "OPTION menu" on page 9 in
your User Guide.
3 Plug the power cable into a power outlet or surge protector.
Quick Start Guide
NS-DXA1
3/8/2008 7:47:04 AM
3/8/2008 7:47:04 AM
