Samsung WT6500 Owner's Instructions

BEFORE USING THE WASHER

In case of pump drained washer,
remove the cap-hose from
the drain hole.
CAUTIONS
Be sure that the washer is grounded.
To avoid electrical shock,use
a metal pipe for the ground
connection. But, don't ground
the washer with gas pipes or
telephone lines to avoid
dangers of explosion or lightning strike.
Do not put your hands into the spin
dryer basket when it is spinning.
Your fingers can be caught
by spinning laundry and
damaged.
Never allow children to operate
or play with the washer.
Children playing with the washer
may accidentally fall into the
washing tub.

PRECAUTIONS WHEN OPERATING

Don't use excessively hot water.
(50˚C or more)
Plastic parts may be deformed or damaged.
Also, clothing may be deformed or decolored.
Before washing,check all pockets.
If nails or pins remain in pockets,they may
damage the washer or clothes.
Close the water tap a little if the
water pressure is too high.
Disconnect the power cord from the
power supply when not in use.
Ventilation opening must not be obstructed
by carpeting when the washing machine is
installed on a carpeted floor.
If the supply cord of this appliance is damaged,
it must only be replaced by a repair shop
appointed by the manufacturer,because
special purpose tools are required.
Warning to avoid overfilling and damages
this appliance must be filled with the operator
present using a moderate water supply
pressure only.
Be sure to cover with the inner
cover on laundry before spinning.
This prevents laundry from
being tossed out and damaged.
To avoid water splashes,
close the wash tub lid.
Be sure lay the drain hose down
(in case no drain pump)
Never splash water on the control panel.
1

DESCRIPTION OF PARTS

SPIN DRYER LID
When you open this lid while
the spin basket is spinning,
the spinning will be stopped
by brake system.
WASHING
WATER INLET
LINT FILTER
WASH TUB LID
Be sure to keep the lid
closed during washing
and spinning.
PULSATOR
DRAIN FILTER
(With pump)
1. WASH SELECTOR
This is used to select Soft or Normal mode.
2. WASH TIMER
This is used to set the wash time, 1-15 minutes.
3. CYCLE SELECTOR
This is used to select the Washing or draining.
If the wash and spin time is set less than 1 minute, sometimes the timer will not be reset,
so you should first set the wash and spin timer to 2 minutes and then turn it back to
desired time.
Soft Normal
Wash Selector
Wash Water Inlet
Cycle Selector
Wash Timer
5 1 2
SPRAY WATER
INLET
INNER LID
SPIN DRYER
BASKET
POWER CORD
The plug's shape
may not correspond
with this drawing.
WASH TUB
WATER DRAIN
HOSE
(WITHOUT PUMP)

CONTROL PANEL

4. SPIN DRY TIMER
This is used to set the spin time, 1-5 minutes.
5.
WASH WATER INLET
Connect water supply hose here.
6. SPIN WATER INLET
Connect water supply hose here.
OFF
Drain
Spin Water Inlet
Spin Dry Timer
3 4 6
2
