Programming Wireless Keyless Entry Pad
Model Number GK-BX, P/N 37224R
LED
For help, refer to the owner's manual or call 1-800-35-GENIE.
WARNING: The door could move during programming. Stay clear of door
Keypad
and all moving par ts at this time.

Keypad Overview:

(enter)
LED
Keypad
LED
Keypad
(enter)
(enter)
NOTE: If your LED light is green, please begin
at the last step on the back of this card. If the
LED light is red, continue below.
Setting the PIN
for the First Time:
1. Press in order the numbers
3-5-7
2. Press the Program key
3. Type your new PIN (3-8 digits)
4. Press the Program key again
You are now ready to program
the keypad to an opener. For use
on a Single Door, continue right
to 1A OR 1B.
To use the keypad to control
multiple doors, continue
directly to the Multiple Door
Section on the back.
Quick Reference Card
n
n
n
Programming
Locate your Opener's
Programming Buttons and LED:
1A. If they look like this:
Synchronizing Keypad to Opener
PROGRAM
PROGRAM
+
SET
• Press Program Set button 2
seconds until the round LED turns
blue, then release. The long purple
LED will blink. Immediately
proceed to Step 2 below.
-OR-
1B. If they look like this:
RADIO
SIGNAL
LEARN
CODE
Synchronizing Keypad to Opener
RADIO
SIGNAL
LEARN
CODE
• Press the Learn Code button and
LED will blink. Immediately
proceed to Step 2 below.
2. Type your new PIN on the
keypad.
3. Press Up/Down key and Opener
LEDs will stay on steady.
4. Press Up/Down key again and
Opener LEDs turn off.
5. Press Up/Down key a third time
and Opener runs.
The process of programming ONE
keypad to ONE opener is complete.
PROGRAM
+
SET
SET
OPEN
SET
LEARN
MANUAL
LIMIT
FORCE
SET
CODE
CLOSE
RADIO
SIGNAL
LEARN
CODE
+
LEARN
CODE
