- Page 1 series LED TV y l l retain them for future reference. u l l v i t . y l TQB4GC0927...
- Page 2 Bluetooth SIG, Inc. and any use ® of such marks by Panasonic Corporation is under license. Other trademarks and trade names are those of their respective owners. HDMI, the HDMI Logo, and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.
-
Page 3: Table Of Contents
The recording and playback of content on this or any Quick Start Guide other device may require permission from the owner of the copyright or other such rights in that content. Panasonic has Accessories / Options ···········································6 no authority to and does not grant you that permission and Identifying Controls ·············································... -
Page 4: Safety Precautions
Using an unapproved pedestal or other fixtures may or other open flames make the TV unstable, risking injury. Be sure to ask ● your local Panasonic dealer to perform setup. ● away from this product ● Use approved pedestals (p. 8) / wall-hanging brackets (p. - Page 5 TV off with Mains power On / Off switch, then turn it on again. ● Additional information for built-in wireless LAN and access point may be on the following website. (English only) http://panasonic.jp/support/global/cs/tv/ ■ Bluetooth wireless technology ®...
-
Page 6: Accessories / Options
● Failure to use a Panasonic bracket or choosing to mount the unit yourself will be done at the risk of the consumer. Always be sure to ask a qualified technician to carry out set up. Incorrect fitting may cause equipment to fall, resulting in injury and product damage. - Page 7 ● TY-ER3D4MW ● If you need 3D Eyewears additionally, please purchase this optional accessory. ● ● TY-ER3D4SW Use Panasonic 3D Eyewear for active 3D supporting Bluetooth wireless technology. ● For more information (English only): http://panasonic.net/avc/viera/3d/asia.html Communication Camera ● TY-CC20W ●...
- Page 8 Otherwise the TV may fall over and become damaged, and personal injury may result. Do not use the pedestal if it becomes warped or physically damaged. ● If you use the pedestal while it is physically damaged, personal injury may result. Contact your local Panasonic ■ dealer immediately.
- Page 9 ■ Preparations Take out the pedestal and the TV from the packing case and put the TV onto a work table with the screen panel down on the clean and soft cloth (blanket, etc.) ● Use a firm table bigger than the TV. ●...
- Page 10 ■ Moving the TV Hold the specified parts as shown to stand the TV up and move it with two people. Removing the pedestal from the TV Be sure to remove the pedestal in the following way when using the wall-hanging bracket or repacking the TV. 1 Put the TV onto a work table with the screen panel down on the clean and soft cloth.
-
Page 11: Identifying Controls
Identifying Controls Remote Control INTERNET ([VIERA Connect]) (p. 21, 75) ● Displays VIERA Connect home screen. ● Confirms selections and choices. ● Press after selecting channel positions to quickly change channel. ● Displays the Channel List. [Option Menu] (p. 24) ●... - Page 12 VIERA Touch Pad Controller This touch pad controller is designed for the convenient operations, especially, on VIERA Connect or internet contents. You can operate the TV intuitively with this controller. ● The touch pad controller can be used by registering to this TV with Bluetooth wireless technology. Setup screen to register will appear in “Auto Tuning”...
- Page 13 Indicator / Control panel Front Logo LED ● To turn the LED on / off, set [Front Logo LED] in Setup Menu. (p. 45) Remote control signal receiver ● Do not place any objects between the TV remote control signal receiver and remote control. Function select ●...
-
Page 14: Basic Connection
Basic Connection ● ● External equipment and cables shown are not supplied with this TV. ● Please ensure that the unit is disconnected from the mains socket before attaching or disconnecting any leads. There are some restrictions on placement for viewing 3D images. For details (p. - Page 15 Note ● Keep RF (antenna) cable away from the mains lead to avoid and minimise mains interference pickup. ● Do not place the RF cable under the TV. To obtain optimum quality picture and sound, an aerial, the correct cable (75 Ω coaxial), and the correct terminating ●...
- Page 16 Network To enable the network service functions (VIERA Connect, etc.), you need to connect the TV to a broadband network environment. ● If you do not have any broadband network services, please consult your retailer for assistance. ● ● Prepare the internet environment for wired connection or wireless connection. ●...
-
Page 17: Auto Tuning
Auto Tuning Search and store TV channels automatically. ● These steps are not necessary if the setup has been completed by your local dealer. ● Please complete connections (p. 14 - 16) and settings (if necessary) of the connected equipment before starting Auto Tuning. - Page 18 Setup the network connection Setup the network connection to enable the network service functions such as VIERA Connect, etc. (p. 21, 75). ● Please note that this TV does not support wireless public access points. ● Ensure the network connections (p. 16) and network environment are completed before starting setup. Select the network type [Wired] “Wired connection”...
- Page 19 4. After the access point setting is finished, perform the connection test Connection Test : succeeded Check wireless network connection. The test is successful and the TV is connected to the Check acquired IP address. Check for devices using same IP address. network.
- Page 20 Select [Home] Select [Home] viewing environment to use in your home environment. Please select your viewing environment. select Home Shop ■ [Shop] viewing environment (for shop display only) [Shop] viewing environment is the demonstration mode to explain main features of this TV. Select [Home] viewing environment to use in your home environment.
-
Page 21: Using "Viera Connect
VIERA Connect is a gateway to the internet services unique to Panasonic. VIERA Connect allows you to access some specific websites supported by Panasonic, and enjoy internet contents such as videos, games, communication tools, etc. from VIERA Connect home screen. -
Page 22: Select A Channel
Watching TV Turn power on ● Mains power On / Off switch should be on. (p. 13) ■ VIERA Connect introduction banner appears Every time you turn on the TV, this banner appears at the bottom of the screen. You can access to VIERA Connect easily and enjoy the various contents. - Page 23 Other useful functions Display Information banner Display Information banner ● Also appears when changing a channel. Example: Digital TV 20:35 Coronation Street All Digital Channels 20:30 - 20:55 BBC ONE WALES Channel position and name Programme Start / Finish time (Digital TV) Channel number, etc.
-
Page 24: Off Timer
Display the selectable settings for the current status Confirm or change the current status instantly ● To change select select / change access store [Multi Video] (Digital TV) [Channel Colour Set] (Analogue TV) Selects the image (if available) Sets colour density (p. -
Page 25: Last View
[16:9] [4:3 Full] Directly displays the image at 16:9 Displays a 4:3 image enlarged without distortion (anamorphic). horizontally to fit the screen. ● For Digital TV or HD signal [14:9] [Zoom1] Displays the image at the standard Displays a 16:9 letterbox or 4:3 image 14:9 without distortion. -
Page 26: Using Tv Guide (Digital Tv)
Using TV Guide (Digital TV) ■ TV Guide - Electronic Programme Guide (EPG) provides an on-screen listing of the programmes currently broadcast and the forthcoming broadcasts over the next seven days (depending on the broadcasters). ● When this TV is turned on for the first time, or the TV is switched off for more than a week, it may take some time before TV Guide is completely shown. -
Page 27: Timer Programming
■ To view a channel list of the selected category (Category list) select category Favourites All Digital Channels view All Digital Channels Favourites1 ● To list favourite channels (p. 46) Favourites2 Favourites3 Favourites4 Other useful functions View details of the programme Select the programme View details ●... - Page 28 Watching External Inputs Connect the external equipment (VCRs, DVD equipment, etc.) and you can watch through the input. ● To connect the equipment (p. 14 - 16, 92 - 94) The remote control is capable of operating the contents or external equipment. (p.
- Page 29 Pause / Resume Record Start recording How to change the code Each type of the Panasonic equipment has its own remote control code. Change the code according to the equipment you want to operate. Press and hold during the following operations...
-
Page 30: Viewing 3D Images
Viewing 3D images ● You can enjoy viewing 3D images with contents or programmes corresponding to the 3D effect by wearing the 3D Eyewear (supplied). “Standard accessories” (p. 6) ● This TV supports [Frame Sequential] ∗ , [Side by Side] ∗ and [Top and Bottom] ∗... - Page 31 ● Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type. 3D Eyewear ● Use the supplied 3D Eyewear or Panasonic 3D Eyewear that has this logo and supports Bluetooth wireless technology. ® “Full HD 3D Glasses™” logo indicates products that are compatible with the active shutter 3D glasses technology standards licensed by the Full HD 3D Glasses Initiative.
-
Page 32: Part Names And Functions
Part names and functions Power switch ON / OFF ● Slide the tab to the “ON” / “OFF” position to switch the power On / Off. MODE ● Slide the tab to the “MODE” position to change the mode between 3D and 2D (view a 3D image in 2D). ●... -
Page 33: Replacing The Battery
Registration again When connection with registered TV fails, or when using with another TV, re-register the 3D Eyewear. Turn the TV on Within 50 cm from the TV, hold the power switch on the “MODE” position for more than 2 seconds ●... - Page 34 3D-supported broadcast ● Please consult the suppliers of contents or programmes for availability of this service. ■ 3D photos and 3D videos taken by 3D-compatible Panasonic products ● Available in Media Player (p. 63) and Network services (p. 81) ■...
- Page 35 ■ To change 3D format manually When the image is not changed properly using [3D], [2D] or [2D 3D] mode, use this manual setting. During the above operation Select the mode select 3D Mode Selection (Manual) Original Frame Sequential - 3D Frame Sequential - 2D Side by Side - 3D Side by Side - 2D...
- Page 36 3D Settings If the 3D images are not displayed correctly or seem unusual, adjust and setup the 3D settings. Display the menu Select [Picture] select Picture access Select [3D Settings] select P-NR access 3D Settings Access Screen Display Advanced Settings Reset to Defaults Reset Select one of the following functions and set...
-
Page 37: How To Use Viera Tools
How to Use VIERA TOOLS You can access some special features easily by using the VIERA TOOLS function. Display icons of the feature Select a feature select access VIERA Link ■ To return to TV ■ Follow the operations of each feature [Music] ∗... -
Page 38: How To Use Menu Functions
How to Use Menu Functions Various menus allow you to make settings for the picture, sound, and other functions. Display the menu ● Displays the functions that can be set (varies according to the input signal). Select the menu Example: [Picture Menu] select Main Menu access... - Page 39 Menu list Menu Item Adjustments / Configurations (alternatives) Selects your favourite picture mode for each input [Dynamic] / [Normal] / [Cinema] / [True Cinema] / [Game] / [Professional1] / [Professional2] [Dynamic]: Improves contrast and sharpness for viewing in a bright room. [Normal]: Normal use for viewing in a normal lighting condition.
- Page 40 Menu Item Adjustments / Configurations (alternatives) 3D Settings Adjusts and sets to view 3D images (p. 36) Turns the screen off when you select [Off] [Off] / [On] ● The sound is active even if the screen turns off. Screen Display ●...
- Page 41 Menu Item Adjustments / Configurations (alternatives) Press the OK button to reset the current Picture Viewing Mode of the selected Reset to Defaults input to the default settings Selects your favourite sound mode for each input [Music] / [Speech] / [User] [Music]: Improves sound quality for watching music videos, etc.
- Page 42 Menu Item Adjustments / Configurations (alternatives) Selects multiplex sound mode (if available) [Stereo]: Use this normally. [Mono]: When stereo signal cannot be received. [M1] / [M2]: Available while mono signal is transmitted. ● For Analogue TV Selects the initial setting for audio tracks [Auto] / [MPEG] [Auto]: Automatically selects the audio tracks if programme has more than two tracks.
- Page 43 Sets to control the TV with the devices connected to the network (p. 77) Software Update Checks for available software updates from the Panasonic website Selects whether to give a notification message when new software is found via New Software Message...
- Page 44 Menu Item Adjustments / Configurations (alternatives) Creates a list of favourite channels (p. 46) Favourites Edit ● For Digital TV Channel List Skips the unwanted channels or edits channels (p. 47) Auto Tuning Automatically searches for the receivable channels (p. 48) Manual Tuning Searches for the channels manually (p.
- Page 45 Reduces brightness of the picture to economise on power consumption Power Save [Off] / [On] Lights the Panasonic logo on the TV front while the TV is on Front Logo LED [Off] / [On] ∗ The settings in [Tuning Menu] are applicable only for the selected TV mode. The menu name varies depending on the TV mode.
-
Page 46: Tuning And Editing Channels
Tuning and Editing Channels You can retune channels or make your favourite channel lists, skip unwanted channels, etc. Select the mode (p. 22) Display the menu and select [Setup] select Setup access Select [Digital TV Tuning Menu] or [Analogue TV Tuning Menu] select access Digital TV Tuning Menu... - Page 47 ■ To edit Favourites list While the cursor is in the Favourites field to edit ● ● To move the channel To delete the channel Select the new position Store ● To delete all channels ● To name the Favourites Set characters (maximum 10 characters) Store select...
- Page 48 Set all channels automatically [Auto Tuning] Automatically retune all channels received in the area. Start Auto Tuning Settings are made automatically Example: Digital TV Example: Digital TV Digital TV Auto Tuning Digital TV Auto Tuning Scan CH C1 All digital TV tuning data will be erased This will take about 7 minutes.
- Page 49 Update Digital TV channel automatically [Update Channel List] (Digital TV) You can add new channels, delete removed channels, update channel name and position automatically to the channel list. ● The channel list is updated while keeping your settings in [Favourites Edit], Digital TV Update Channel List Scan CH C1...
- Page 50 Timer Programming Timer Programming from Menu The Timer Programming menu allows you to choose programmes that you want to remind watching or record to the USB HDD or the SD Card. At the correct time, the TV will tune to the correct channel even if the TV is in Standby mode.
- Page 51 Set timer programming event details Start making the settings Select the function ([USB HDD Rec.], [SD Card Rec.] or [Reminder]) [USB HDD Rec.] / [SD Card Rec.]: Records the programme to the USB HDD or the SD Card. When the start time comes, the channel will be switched automatically and the video and audio signals will be output.
- Page 52 ■ To edit a timer programming event Select the event ● ● To change a timer programming event To cancel a timer programming event temporarily Each time pressed: • Timer off: cancel Timer on: stop cancelling Correct as necessary (p. 51) ●...
-
Page 53: Child Lock
Child Lock You can lock specific channels / AV input terminals and control who watches them. When the locked channel / input is selected, a message appears. Enter the PIN number to watch. Display the menu and select [Setup] select Setup access Select [Child Lock]... -
Page 54: Shipping Condition
Shipping Condition Resets the TV to its original condition, i.e. no channels tuned in. All settings other than [USB HDD Setup] are reset (channels, picture, sound settings, etc.). ● To retune TV channels only, e.g. after moving house ● [Auto Tuning] in “Tuning and Editing Channels” (p. 48, 49) Display the menu and select [Setup] select Setup... -
Page 55: Updating The Tv Software
Updating the TV Software A new version of software may be released for download to enhance the performance or operations of the TV. If there is an update available, a notification message is displayed when the channel has the update information. ●... - Page 56 Displaying PC Screen on TV The screen of the PC connected to the TV can be displayed on the TV. ● You can also listen to PC sound with the audio cable connected. ● To connect PC (p. 93) ● Select the external input Select [PC] select...
-
Page 57: Advanced Picture Settings
Advanced Picture Settings You can adjust and setup the detailed picture settings for each Viewing Mode. ● To use this function completely, set [Advance(isfccc)] to [On] in the Setup Menu. (p. 45) ● For PC input mode, some functions are available without setting [Advance(isfccc)]. Display the menu and select [Picture] select Picture... - Page 58 Menu Item Adjustments / Configurations (alternatives) R-Hue, G-Hue, B-Hue Adjusts the picture hue of red / green / blue area R-Saturation, G-Saturation, Adjusts the saturation of red / green / blue area ● ● B-Saturation ● ● R-Luminance, ● G-Luminance, Adjusts the luminance of red / green / blue area ●...
-
Page 59: Usb Hdd / Sd Card Recording
USB HDD / SD Card Recording You can record the digital TV programmes to the connected USB HDD or inserted SD Card and enjoy playing back in various ways. ● Analogue TV programme cannot be recorded on the USB HDD / SD Card. ●... - Page 60 Setting for USB HDD / SD Card Format and setup the USB HDD with this TV in order to use it for recording. Depending on the conditions of the SD Card, the recording may not work properly. Formatting the SD Card with this TV will resolve this problem.
- Page 61 Mode USB HDD Setup Product Name : The USB HDD is available for recording / playing back. USB Drive A USB HDD 1 USB Flash Disk Only one USB HDD on the list is available for recording. USB HDD name is displayed : The USB HDD is available for playing back.
- Page 62 ■ To stop recording on the way Confirm the code of the remote control to “73” (p. 29) ■ To play back or delete the recorded contents “Recorded TV mode” (p. 70) ● Even if One Touch Recording is in progress, you can play back all the contents. (Depending on the USB HDD / SD Card, it may not be available or the recording may not work properly while playback.) Record constantly [REW LIVE TV] (USB HDD only)
-
Page 63: Using Media Player
Using Media Player Media Player allows you to enjoy photo, video or music recorded on an SD Card and a USB Flash Memory, and contents recorded with this TV on the recording devices (SD Card / exclusive USB HDD). Photo mode: Still pictures recorded by digital cameras will be displayed. - Page 64 Starting Media Player Insert the SD Card or USB Flash Memory to the TV ● (p. 63) ● To play back contents in the USB HDD, check the connection and settings are completed. (p. 59, 60) ● When the SD Card is inserted, switching to Media Player will be done automatically. Start Media Player ●...
-
Page 65: Change The Contents
Change the contents You can switch to the other mode of Media Player from the thumbnail view. ● The mode can be switched in the current device. While the thumbnail is displayed, Select the content display the contents selection Contents Select select EXIT Select... -
Page 66: Multi Shot 3D
■ ■ To sort by folder, recorded date or recorded month Display the view selection in the thumbnail view Select the sort type [Folder view]: select Displays the thumbnail grouped by folder. access ● The files which are not into a folder will be collected to the folder named “/”. [Sort by Date] / [Sort by Month]: Displays the thumbnail grouped by the same date or month. - Page 67 ■ To enjoy the saved 3D photos Saved 3D photos are displayed in the Thumbnail screen. Wear the 3D Eyewear and enjoy the 3D photos. Example: Thumbnail Media Player Photo All photos Saved 3D photo Photo Settings Setup the settings for Photo mode. Display the option menu Select [Slideshow Settings] Select the items and set...
- Page 68 Menu Item Adjustments / Configurations (alternatives) Selects enlarged or normal viewing on Single view and Slideshow [Normal] / [Zoom] ● This function is not available when [Frame] is set to [Collage], [Drift], [Gallery] or Screen Mode [Cinema] or when [Transition Effect] is set to [Motion]. ●...
-
Page 69: Video Mode
Video and Recorded TV mode ● Supported file format (p. 97, 98) Video mode (For SD Card or USB Flash Memory) The thumbnail of video titles in the SD Card or USB Flash Memory will be displayed. Example: Thumbnail - [Title view] The preview will start when the title / scene is highlighted if it supports Media Player Video... - Page 70 ■ ■ Video Setup Setup the settings for Video mode. ● Menu items and selectable options vary depending on the content. Display the option menu Select [Video Setup] Select the items and set select Option Menu Video Setup access / store ■...
- Page 71 ■ Playback from the list Select the content Start playback ● If you stopped the last playback on the way, the confirmation screen is displayed to select whether to start from where you stopped last time or from the beginning. (USB HDD only) ●...
-
Page 72: Audio Output Settings
● To jump to the specified time point While the time seek bar is displayed ● Press: Search about 10 seconds Press and hold: Search rapidly ● ● To change aspect To display the subtitle (if available) ● To confirm or change the current status (if available) “Display the selectable settings for the current status”... -
Page 73: Music Setup
Music mode ● Supported file format (p. 98) The thumbnail of music folders in the SD Card or USB Flash Memory will be displayed. Example: Thumbnail - [Folder view] ● To play back the selected folder Media Player Music Folder view Select the folder Start playback My Music_1... - Page 74 To use this function with your smartphone, set [Network Remote Control] of this TV to [On]. (p. 77) And you need to install the application for controlling VIERA in your smartphone. For the information of the application: ● http://panasonic.jp/support/global/cs/tv/ For the operations, refer to the support information of the application. ● ● ●...
- Page 75 VIERA Connect is a gateway to the internet services unique to Panasonic. VIERA Connect allows you to access some specific websites supported by Panasonic, and enjoy internet contents such as videos, games, communication tools, etc. from VIERA Connect home screen.
- Page 76 Network connections ● To use only DLNA features, you need a home network environment and you can operate the features without broadband network environment. To use VIERA Connect features, you need a broadband network environment. ● If you do not have any broadband network services, please consult your retailer for assistance. ●...
-
Page 77: Network Link Settings
[Manual]: Sets the restrictions for each equipment in the [Remote Device List]. Remote Device List Lists the accessible equipment to this TV on the home network ∗ Depending on the area, this function may not be available. For details, consult your local Panasonic dealer. - Page 78 Wired connection settings This setting is for the network connection by using the LAN cable. Select [Network Connection] and set to [Wired] select Connection Test access / store Network Connection Wired Wireless Network Settings IP/DNS Settings Network Link Settings Software Update New Software Message Network Status Select [IP/DNS Settings] and set the items...
- Page 79 Select [Connection Test] and access to test select Connection Test Access access ● Performs automatic testing of the network connection for the TV. (It takes a while to test.) Connection Test : succeeded Check network cable connection. The test is successful and the TV is connected to the network. Check acquired IP address.
- Page 80 Enter the encryption key of the access point (English only) Set characters Store ● Wireless Network Settings select Encryption key A B C D E F G H J K L M N O P Q R S T U V W X Y Z v w x _ @ / “...
- Page 81 Using DLNA features ® ● Ensure the preparation of the media server, network connections and network settings are completed. (p. 74 - 80) Display [VIERA TOOLS] and select [Media Server] select access Media Server Select one of the media servers to access Example: Media server list Media Server select...
- Page 82 [Slideshow] - Slideshow completes when all photos are viewed within the list. Select the photo file from the list for the first view Start Slideshow ● ● ● To display / hide the operation guide To pause (return to Single view) To return to list For video file Playback...
- Page 83 Option menu for each content Setup the settings for Photo, Video and Music file operations on this TV. Display the Select [Slideshow Settings], [Video Setup] Select the items and set option menu or [Music Setup] select Option Menu access / store Slideshow Settings Video Setup Music Setup...
- Page 84 Audio output settings (for video contents) You can enjoy the multi-channel sound via an amplifier connected to DIGITAL AUDIO OUT or HDMI2 (ARC function) terminal. ● To confirm or change the current sound status (p. 83) Display the menu and Select [Sound] Select [SPDIF Selection] and set Sound SPDIF Selection...
-
Page 85: Link Functions (Viera Link)
Use fully wired HDMI compliant cable. ● Connect the equipment supporting VIERA Link to the TV’s HDMI terminal via an HDMI cable. ● About HDMI cable for connecting Panasonic HD Video Camera or LUMIX Camera, read the manual of the equipment. - Page 86 VIERA Link (HDMI and Audio out connections) Connected equipment ∗ Player theatre Blu-ray Disc theatre Amplifier Features Channel download – – – ∗ ∗ Easy playback – ● Power on link – Power off link ● Reduce unnecessary power ∗ –...
-
Page 87: Easy Playback
” ∗ VIERA Link “ ∗ Enjoy additional HDMI Inter-Operability with Panasonic products which have “HDAVI Control” function. This TV supports “HDAVI Control 5” function. These features are limited to models incorporating “HDAVI Control” and “VIERA Link”. ● Some functions are not available depending on the equipment’s version of HDAVI Control. Confirm the connected equipment’s version of HDAVI Control. - Page 88 Reduce unnecessary power consumption in Standby [Standby Power Save] Set Standby Power Save [On] in the Setup Menu to use this function [Standby Power Save] (p. 45) The power consumption in Standby mode of the connected equipment is controlled higher or lower in synchronisation with the TV On / Off state to reduce the consumption.
- Page 89 Pause Live TV programme [Pause Live TV] You can pause the current TV programme and resume later. The current TV programme will be recorded on HDD of the connected DIGA Recorder. ● This function is available with a DIGA Recorder which has HDD. ●...
- Page 90 Select [VIERA Link Control] select VIERA Link Menu ● Pause Live TV Start access Direct TV Rec Start VIERA Link Control Recorder Speaker Selection Home Cinema Select the equipment to access Select the type of the connected equipment and access. select VIERA Link Menu Pause Live TV...
- Page 91 Speaker control [Speaker Selection] You can control the theatre speaker with this TV remote control pointing at the TV’s signal receiver. ● If you cannot operate, check the settings and the equipment. “Summary of features” (p. 85, 86), “Preparations” (p. 87) Display [VIERA TOOLS] and select [VIERA Link] select access...
-
Page 92: External Equipment
External Equipment These diagrams show our recommendations for connection of your TV to various pieces of equipment. For other connections, consult the instructions for each piece of equipment, the basic connection (p. 14 - 16), the table (p. 94), and the specifications (p. 109, 110). ●... - Page 93 Headphones Rear of the TV (M3 stereo mini plug) ● To adjust volume [Headphone Volume] (p. 41) USB devices USB cable USB HDD Communication Camera AV2 IN (COMPONENT / VIDEO) adaptor (supplied) (Listening) (Viewing) Conversion adaptor (if necessary) Computer...
- Page 94 Types of connectable equipment to each terminal Terminal AV2 IN ∗ Features To watch 3D contents (Blu-ray Disc Player) To watch satellite broadcasts (Set top box) To watch videocassettes / DVDs (VCR / DVD player) To watch camcorder images (Video camera) To play games (Game equipment) ∗...
-
Page 95: Technical Information
Technical Information Channel Allocation (Analogue TV) Channel Asia / CIS / NZ / Indian South American American Japan China Hong Kong Plan W.Europe E.Europe Indonesia CATV Africa System CATV CATV Receive channel DISPLAY – – – – – – – –... - Page 96 Stereo / Bilingual Sound Selection (Analogue TV) ■ When you receive the stereo / bilingual sound system, sound output modes can be selected by using the [MPX] in the Sound Menu. Audio Signal STEREO MAIN I SUB II MONO Mode Indicator NICAM ..Used in New Zealand, Singapore, Hong Kong etc.
- Page 97 MPEG2 MPEG Audio structure on the device is modified. ● This TV supports Motion JPEG DivX3 DivX4 Dolby Digital recorded by Panasonic LUMIX Camera ∗ DivX5 DivX6 Dolby Digital ● This TV is not available for playing back Plus H.264 BP/MP/HP .mov...
- Page 98 Dolby Digital DivX5 DivX6 .f4v Dolby Digital ● This TV supports this container H.264 BP/MP/HP Plus .m4v recorded by Panasonic products. For ● MPEG1 details, read the manual of the products. HE-AAC .mp4 MPEG2 MPEG Audio ● MPEG4 SP/ASP ●...
- Page 99 DivX DivX Certified to play DivX and DivX Plus HD (H.264/MKV) video up to 1080p HD including premium content. ® ® ® ABOUT DIVX VIDEO: DivX is a digital video format created by DivX, LLC, a subsidiary of Rovi Corporation. This is an official DivX Certified ®...
- Page 100 ● Back up the recorded data at regular intervals in case of deteriorated or damaged data or erratic operation of the TV. ● Panasonic is not liable for any deterioration or damage of recorded data. ● ● Recording time for the USB HDD / SD Card Recording ●...
- Page 101 HDMI connection HDMI (high-definition multimedia interface) is the world’s first complete digital consumer AV interface complying with a non-compression standard. HDMI allows you to enjoy high-definition digital images and high-quality sound by connecting the TV and the equipment. HDMI-compatible equipment ∗ with an HDMI or DVI output terminal, such as a DVD player, a set top box or game equipment, can be connected to the HDMI terminal using an HDMI compliant (fully wired) cable.
- Page 102 You cannot use two or more same kind of USB devices simultaneously except USB Flash Memory or USB HDD. ● Additional information for the devices may be on the following website. (English only) http://panasonic.jp/support/global/cs/tv/ Bluetooth Setup You can use Bluetooth keyboards ∗...
- Page 103 Operations from Keyboard / Gamepad ■ USB Keyboard / Bluetooth Keyboard ● The Keyboard requiring its driver is not supported. ● Characters may not be displayed correctly on the TV screen depending on the connected keyboard. ● Some of the keys of keyboards may correspond to the operation of the remote control. Keyboard Remote Control Keyboard...
- Page 104 Characters table for numeric buttons You can enter characters by using numeric buttons for free input items. (English only) Press the numeric button repeatedly until you reach the User input desired character. Name A B C D E F G H J K L M N O P Q R S T ●...
- Page 105 FAQs Before requesting service or assistance, please follow these simple guides to resolve the problem. If the problem still persists, please contact your local Panasonic dealer for assistance. White spots or shadow images (noise) ● Check the position, direction, and connection of the aerial.
- Page 106 Problem Causes / Actions ● Is “Sound mute” active? (p. 11) No sound is produced ● Is the volume set to the minimum? Sound level is low or ● Sound signal reception may be deteriorated. ● sound is distorted Set [MPX] (p. 42) in the Sound Menu to [Mono]. (Analogue TV) ●...
- Page 107 TV off with Mains power On / Off switch, then turn it on again. message appears ● Check foreign objects are not inside the USB port. ● Follow the message’s instructions. ● An error message appears If the problem persists, contact your local Panasonic dealer or the authorised service centre.
- Page 108 Maintenance First, remove the mains plug from the socket outlet. Display panel, Cabinet, Pedestal Regular care: For stubborn dirt: Gently wipe the surface of the display panel, First clean the dust on the surface. Dampen a soft cloth with cabinet, or pedestal by using a soft cloth to clean the clean water or diluted neutral detergent (1 part detergent to 100 dirt or fingerprints.
-
Page 109: Specifications
Specifications 47” class 55” class Model No. TH-L47WT50H TH-L55WT50H Power Source AC 220 V, 50 / 60 Hz Power rating 121 W 141 W Standby condition 0.2 W 0.2 W Panel system IPS LED backlight Liquid Crystal Display Visible screen size 119 cm / 47 inches 139 cm / 55 inches (diagonal) - Page 110 0 °C - 40 °C Coin-shaped lithium battery CR2025 Battery ∗ Operation time: Approx. 75 hours in continuous use of the battery made by Panasonic Viewing range ∗ Within 3.2 m from front surface of the TV Main body: Resin...
- Page 111 MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. At least three (3) years from delivery of products, Panasonic will give to any third party who contact us at the contact information provided below, for a charge no more than our cost of physically performing source code distribution, a complete machine-readable copy of the corresponding source code covered under LGPL.
- Page 112 Warranty Service purposes. Model Number Serial Number M0412-0 Web Site: http://panasonic.net © Panasonic Corporation 2012 Printed in Malaysia...
