NAILER/STAPLER
OIL FREE - 18 GAUGE
ASSEMBLY AND OPERATION INSTRUCTIONS
Due to continuing improvements, actual product may differ slightly from the product described herein.
Visit our website at: http://www.harborfreight.com
TO PREVENT SERIOUS INJURY, READ AND UNDERSTAND
ALL WARNINGS AND INSTRUCTIONS BEFORE USE.
Copyright
2006 by Harbor Freight Tools
©
manual or any artwork contained herein may be reproduced in any shape or form
without the express written consent of Harbor Freight Tools.
For technical questions or replacement parts, please call 1-800-444-3353.
Model
3491 Mission Oaks Blvd., Camarillo, CA 93011
95218
. All rights reserved. No portion of this
®
®
Advertisement
Table of Contents
Related Manuals for Central Pneumatic 95218
Summary of Contents for Central Pneumatic 95218
- Page 1 NAILER/STAPLER OIL FREE - 18 GAUGE Model 95218 ASSEMBLY AND OPERATION INSTRUCTIONS Due to continuing improvements, actual product may differ slightly from the product described herein. ® 3491 Mission Oaks Blvd., Camarillo, CA 93011 Visit our website at: http://www.harborfreight.com TO PREVENT SERIOUS INJURY, READ AND UNDERSTAND ALL WARNINGS AND INSTRUCTIONS BEFORE USE.
-
Page 2: Product Specifications
It will do the job better and more safely at the rate for which it was intended. Do not modify this tool, and do not use this tool for a purpose for which it was not intended. For technical questions, please call 1-800-444-3353 SKU 95218 PAGE 2... - Page 3 Use of any other parts will void the warranty. Only use accessories intended for use with this tool. Approved accessories are available from Harbor Freight Tools. For technical questions, please call 1-800-444-3353 SKU 95218 PAGE 3...
- Page 4 [to the State of California] to cause cancer, birth defects or other reproductive harm. Some examples of these chemicals are: Lead from lead-based paints For technical questions, please call 1-800-444-3353 SKU 95218 PAGE 4...
-
Page 5: Air Supply Setup
For best service, you should incorporate a regulator and an in-line filter as shown in the diagram below. Hoses, couplers, regulators, and filters are all available from Harbor Freight Tools. REGULATOR COMPRESSOR NAILER/STAPLER FILTER For technical questions, please call 1-800-444-3353 SKU 95218 PAGE 5... - Page 6 The tool must not cycle (fire). If it fails to perform in the manner explained in bold, have it repaired by a qualified service technician. For technical questions, please call 1-800-444-3353 SKU 95218 PAGE 6...
- Page 7 Moveable Magazine (61). Up to 100 Brads or Staples may be loaded in front of the Moveable Magazine. Slide the Moveable Magazine (61) forward, making sure the Fixed Lever (53) locks in place. For technical questions, please call 1-800-444-3353 SKU 95218 PAGE 7...
- Page 8 Brads/Staples. Make sure to store the Nailer/Stapler in a clean, dry, safe location out of reach of children. For technical questions, please call 1-800-444-3353 SKU 95218 PAGE 8...
-
Page 9: Clearing Jams
When finished working, disconnect the air supply. Remove the Brads/Staples. Then, store the tool in a clean, dry, safe location out of reach of children. For technical questions, please call 1-800-444-3353 SKU 95218 PAGE 9... -
Page 10: Inspection, Maintenance, And Cleaning
Have a qualified service technician clean the interior of the tool and/or lubricate the magazine and install a new magazine spring. Other problems. Have a qualified service technician inspect the tool. For technical questions, please call 1-800-444-3353 SKU 95218 PAGE 10... -
Page 11: Please Read The Following Carefully
Trigger Valve Stem Fixed Lever O-Ring (1.7 x 2) Compressed Spring Note: Some parts are listed and shown for illustration purposes only, and are not available individually as replacement parts. For technical questions, please call 1-800-444-3353 SKU 95218 PAGE 11... -
Page 12: Assembly Diagram
ASSEMBLY DIAGRAM 56 55 62 61 79: Hex Wrenches (Qty. 2) not shown. For technical questions, please call 1-800-444-3353 SKU 95218 PAGE 12... - Page 13 This warranty gives you specific legal rights and you may also have other rights which vary from state to state. 3491 Mission Oaks Blvd. • PO Box 6009 • Camarillo, CA 93011 • (800) 444-3353 For technical questions, please call 1-800-444-3353 SKU 95218 PAGE 13...
