Anaheim Automation DPG10002-01 User Manual

Microstep driver pack

Advertisement

Quick Links

DPG10002-01, DPG10003-01, DPG10004-01
Microstep Driver Pack
User's Guide
A N A H E I M
A U T O M A T I O N
910 East Orangefair Lane, Anaheim, CA 92801
(714) 992-6990 fax: (714) 992-0471
e-mail: info@anaheimautomation.com
website: www.anaheimautomation.com
#L010167
December 2004

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DPG10002-01 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Anaheim Automation DPG10002-01

  • Page 1 DPG10002-01, DPG10003-01, DPG10004-01 Microstep Driver Pack User’s Guide A N A H E I M A U T O M A T I O N 910 East Orangefair Lane, Anaheim, CA 92801 (714) 992-6990 fax: (714) 992-0471 e-mail: info@anaheimautomation.com website: www.anaheimautomation.com #L010167...
  • Page 2: Pin Descriptions

    DPG10002-01, DPG10003-01, DPG10004-01 Microstep Driver Pack Features • Integrated MBC10641, Power Supply, and Cooling Fan • 90-265 VAC Input • Output Current 10.0 Amps Peak • 200 to 12,800 steps/rev (1,2,5,8,10,16,32 and 64 selectable step operations) • Short Circuit Protection •...
  • Page 3: Power Supply Requirements

    TB1: 8 Pin Terminal - All Connections INTERNALLY Wired to 25DB Port Table 2: Pin descriptions for terminal block TB1. Power Supply Requirements The DPA10002-01, DPG10003-01 and DPG10004-01 are all powered by an AC line voltage ranging from 90-265VAC. The following figure shows the various line voltages. December 2004...
  • Page 4: Absolute Maximum Ratings

    Absolute Maximum Ratings Input Voltage: 90-265 VAC Output Current: 10.0 AMPS PEAK Max Plate Temperature: 70° C Storage Temperature: 0° to +50° C Input Voltage (For isolated inputs): +5V to +24V at 2.5mA Electrical Specifications Hook Up Drawings Hook Up for Current Sinking Inputs Optional: Non-Isolated +5VDC Output can power the MBC10641 Inputs (but isolation is eliminated).
  • Page 5: Optically Isolated Inputs

    This in turn means higher step rates can be achieved. Care should be taken not to exceed the maximum voltage of the driver. Anaheim Automation offers a comprehensive line of step motors in 17, 23, 34 and 42 frame sizes. Contact the factory to verify motor/ drive compatibility .
  • Page 6: Setting The Output Current

    Microstep Selection (SW1 Settings) Switches 2, 3 and 4, of the DIP switch select the number of microsteps per step. Table 7 shows the standard resolution values along with the associated positions for the select switches. The standard wave- forms are sinusoidal. Table 6: Microstep Selection on Switch 1.
  • Page 7: Reducing Output Current

    Step Motor Selection Guide TABLE 5 - Table Selection for Anaheim Automation Motor Current Settings. Anaheim Automation offers motor cable, making hook-ups quick and easy! Contact the factory or visit our website for more motor and cable offerings. Reducing Output Current Reducing the output current is accomplished by setting switch 1 of the DIP switch to the ON position and occurs approximately 1 second after the last positive going edge of the step clock input.
  • Page 8: Step Motor Configurations

    Step Motor Configurations Step motors can be configured as 4, 6, or 8 leads. Each configuration requires different currents. Refer to the lead configurations and the procedures to determine their output current. WARNING! Step motors will run hot even when configured correctly. Damage may occur to the motor if a higher than specified current is used.
  • Page 9: Connecting The Step Motor

    8 Lead Motors Series Connection: When configuring the motor windings in series, use the per Phase (or unipolar) current rating to determine the current setting potentiometer value. Parallel Connection: When configuring the motor windings in parallel, multiply the per Phase (or unipo- lar) current rating by 2.0 to determine the current setting potentiometer value.
  • Page 10: Dimension Drawings

    Dimension Drawings DPG10002-01, DPG10003-01 and DPG10004-01 Micostep Driver Pack User’s Guide # L010167...
  • Page 11 Warranty provisions may be voided if products are subjected to physical modifications, damage, abuse, or misuse. Anaheim Automation will repair or replace at its’ option, any product which has been found to be defective and is within the warranty period, provided that the item is shipped freight prepaid, with previous authorization (RMA#) to Anaheim Automation’s plant in Anaheim, California.
  • Page 12 Torque Speed Curves A N A H E I M A U T O M A T I O N User’s Guide # L010167...
