Colour Monitor
USER GUIDE
BENUTZERHANDBUCH
MANUEL D'UTILISATION
GUIDA UTENTE
GUIA DEL USUARIO
StudioWorks 550M

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the StudioWorks 550M and is the answer not in the manual?

Questions and answers

Related Manuals for LG StudioWorks 550M

Summary of Contents for LG StudioWorks 550M

  • Page 1 Colour Monitor USER GUIDE BENUTZERHANDBUCH MANUEL D'UTILISATION GUIDA UTENTE GUIA DEL USUARIO StudioWorks 550M...
  • Page 2 - Consult the dealer or an experienced radio/TV technician for help. Caution: Changes or modifications not expressly approved by LG Electronics Inc. for compliance could void the user's (or your) authority to operate the equipment. Only peripherals (digital input/output devices, terminals, printers, etc.) certified to comply with the Class B limits may be attached to this monitor.
  • Page 3 Canadian This Class B digital apparatus meets all D. O. C. requirements of the Canadian Interference-Causing Notice Equipment Regulations. Cet appareil numérique de la classe B respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada. Products with the “CE” Marking comply with the Conformity EMC Directive(89/336/EEC) and LOW VOLTAGE Directive (73/23/EEC) issued by the Commission of...

  • Page 4: Table Of Contents

    Table of Contents Monitor Registration Notice.......................A1 Trademark Acknowledgments..............A1 Important Precautions On safety....................A2 On installation ..................A3 On cleaning....................A3 On repacking....................A3 Installing the Tilt/Swivel Base Installation....................A4 Installation Connections .....................A5 Control Layout and Descriptions Front View ....................A6 Rear View ....................A6 Image Control Panel Image Control Icons.................A8 General Operation ..................A9...

  • Page 5: Monitor Registration

    Serial No. Notice All rights reserved. Reproduction in any manner, in whole or in part, is strictly prohibited without the written permission of LG Electronics Inc. Trademark Acknowledgments LG is a trademark of LG Electronics Inc. IBM is a registered trademark and VGA is a trademark of International Business Machines Corporation.

  • Page 6: Important Precautions

    Important Precautions This unit has been engineered and manufactured to assure your personal safety, but improper use can result in potential electrical shock or fire hazard. In order not to defeat the safeguards incorporated in this monitor, observe the following basic rules for its installation, use, and servicing.

  • Page 7: On Installation

    Keep children from dropping or pushing objects into the monitor's cabinet openings. Some internal parts carry hazardous voltages. Do not add accessories that have not been designed for this monitor. During a lightning storm or when the monitor is to be left unattended for an extended period of time, unplug it from the wall outlet.

  • Page 8: Installing The Tilt/Swivel Base

    Installing the Tilt/Swivel Base Turn Off the equipment and all attached options. Carefully set the monitor face-down with the underside facing you. Installation 1. Align the hooks on the tilt/swivel stand with the matching slot on the base (underside of the monitor). The open hooks of the stand should face the front of the monitor.

  • Page 9: Installation

    Installation The supply voltage is marked on the ID label located on the rear panel of the monitor. If your local voltage is different, do not use the monitor and contact your supplier before using the display. Connections To connect your monitor after the video adapter is properly installed: 1.

  • Page 10: Control Layout And Descriptions Front View

    Control Layout and Descriptions Front View Speaker Speaker Earphone Jack Power Indicator Power 0n/off Button Image Control Icons Rear View ID Label AC Power Connector Signal Cable Audio In Jack...
  • Page 11 Image Control Panel Power ON/OFF Button This Button is used to turn the power On or Off. Power Indicator The power indicator lights when the power is On, and indicates the operating status of the display Contrast Adjust the display to the contrast desired. Move the thumbwheel located beneath this indicator to increase or decrease the display contrast.
  • Page 12 Image Control Icons Listed below are the icons, icon names, and icon descriptions of the items. icon Description Horizontal To move picture image left and right. Position - Moves the screen image left. + Moves the screen image right. Horizontal To adjust image width.

  • Page 13: General Operation

    General Operation After following the installation instructions and getting familiar with the controls, you are ready to operate the monitor. 1. Turn on the monitor, PC and other peripherals you plan to use. 2. After the PC has booted (powered up and finished self-testing), enter a software application that uses the full screen display.

  • Page 14: Power Management System

    Power Management System When used in conjunction with a PC having power saving circuitry, or a PC running screen blanking software this monitor automatically reduces its power consumption when the computer is not in use.The monitor has power-saving states, indicated by the light-emitting diode (LED) on the front panel.These power-saving states exceed the Environmental Protection Agency (EPA) Energy Star requirements using the methodology for Display Power Management Signals(DPMS).

  • Page 15: Audio Features

    Audio Features A major feature of this monitor is its built-in audio system. This conveniently integrates a stereo audio amplifier and speakers without taking up any more space. Because the monitor is designed like this, you can easily upgrade to audio capable multimedia applications by attaching your PC with sound card to the back of this monitor.

  • Page 16: Video Memory Modes

    Video Memory Modes Factory Preset Timing Signal Chart Video Sync Mode1 Mode2 Mode3 Mode4 Mode5 Mode6 Polarity Frequency 31.469 43.269 31.470 37.880 53.674 48.360 Total Period 31.778 23.111 31.780 26.400 18.631 20.680 Data Period 25.422 17.778 25.420 20.000 14.222 15.750 Blanking 6.356 5.333...

  • Page 17: Troubleshooting

    Troubleshooting Symptom: The power LED is amber Possible causes: Display power management mode. These is no sync signal. The signal cable is not fastened securely. Check the computer power and graphics adapters configuration. The frequency of the sync input is outside the operating range of the monitor.

  • Page 18: Service

    Service 1. Unplug the monitor from the wall outlet and refer servicing to alified service personnel when : The power cord or plug is damaged or frayed. Liquid has been spilled into the monitor. The monitor has been exposed to rain or water. The monitor does not operate normally following the operating instructions.

  • Page 19: Specifications

    Specifications Sync Signal type Type H. sync V. sync Separate sync H. sync V. sync Signal Connector Pin Assignment Separate Sync Green Blue Ground Self-Test Red Ground Green Ground Blue Ground Ground Ground Horiz.Sync Vert.Sync...
  • Page 20 16.4 x 15.0 x 15.4 inches/417 x 380 x 391 mm(with tilt/swivel stand) Weight ( net ) 31.3 lbs (14.2 kg) Information in this document is subject to change without notice and does not represent a commitment on the part of LG Electronics Inc.
