- Page 1 Form P6031 03524832 Edition 12 January 2011 Air and Gas Powered Starter Series 150BMG Installation and Maintenance Information Save These Instructions...
-
Page 2: Model Coding
Size Starter Type Starter Gas Sealed (Dwg. TPD1732) For specifi c models or special applications, contact your nearest Ingersoll-Rand Distributor or Ingersoll-Rand Engine Starting Systems, Box 8000, Southern Pines, NC 28387 (910) 692-8700. Installation NOTICE For maximum performance, read this manual prior to installation or operation of Series 150BMG Starters. - Page 3 03524832_ed12 Relay Valve Location Ingersoll-Rand recommends that the Relay Valve be mounted on the air tank. As an alternate location, the Relay Valve can be mounted on the starter. Mounting on the starter gives better control of the air supply closer to the point of use and provides more starts per tank of air.
- Page 4 When repairing a gas-operated starter or when converting a starter from air operation to gas operation, it is necessary to use Ingersoll-Rand No. MBA31 Plastic Gasket, as directed, and the following procedures for assembly and testing must be explicitly followed.
- Page 5 150BMG Series Air and Gas Starters Dimensional Drawing 03524832_ed12...
- Page 6 150BMG Series Air and Gas Starters Typical Installation Starter control Valve SMB-G6618 1 1/2” NPT Ingersoll Rand Part Number The performance of the Starter is dependent on the pressure at the inlet of the starter. This pressure is effected by the pressure drop between the Air Receiver Tank and the Starter. The most significant pressure drops will occur in fittings (Valves, Tees, Elbows, etc.) The next significant source of pressure drop is the hose.
- Page 7 150BMG Series Air and Gas Starters Sectional View (Dwg. TPA61-7) 03524832_ed12...
- Page 8 150BMG Series Air and Gas Starters Exploded View (Dwg. TPA683-2) 03524832_ed12...
-
Page 9: Part Description
150BMG Series Air and Gas Starters Parts List Item Part Description Motor Housing Cover Assembly Housing Cover End Plug (3) Nameplate Nameplate Screw (3) Motor Housing Cover Cap Screw (4) Cover Cap Screw Washer (4) † 7 Motor Housing Cover Gasket †... - Page 10 Maintenance Section Always wear eye protection when operating or performing any maintenance on this Starter. Always turn off the air or Gas supply and disconnect the air supply hose before installing, removing or adjusting any accessory on this Starter or before performing any maintenance on this Starter. Note: When reading the instructions, refer to exploded diagrams in parts Information Section when applicable.
- Page 11 Inspection of Parts 1. Discard all O-rings and gaskets. These should not be reused. 2. Check all grease seals. If they appear worn or distorted, remove them from their parent member and discard. NOTICE Discard any grease seal that was removed during disassembly of the starter.
-
Page 12: Testing The Starter
12. Set the Front End Plate (39), crescent grooved side fi rst, onto the Cylinder so that the Cylinder Dowel passes through the dowel hole in the End Plate. Make sure that all notches and ports are in alignment. 13. Install the Front Rotor Bearing (37) onto the splined shaft of the Rotor until it seats against the Front End Plate. -
Page 13: Troubleshooting Guide
Troubleshooting Guide Trouble Probable Cause No air supply Damaged motor assembly Foreign material in motor and/or piping Blocked exhaust system Motor will not Defective Control Valve or Relay Valve Low air pressure to Starter Restricted air supply line. Relay Valve malfunctioning Exhaust fl ow restricted Worn motor parts Loss of Power... - Page 14 Notes:...
- Page 15 Notes:...
- Page 16 www.ingersollrandproducts.com © 2011 Ingersoll Rand...
