Introduction
The FLATRON LCD 575MM Flat Panel Monitor has an active matrix TFT
(Thin-Film Transistor) LCD (Liquid Crystal Display).
This monitor is designed for use in small working areas or for those who need
more working space on the desk.
Features
FLATRON LCD 575MM
The
micropro-cessor based monitor.
Digitally controlled auto-scanning is done with the micro-processor for horizontal
scan frequencies between 31 and 69kHz, and vertical scan frequencies
between 56 - 85Hz.
This monitor provides audio function.Thanks to built in audio function in the
speaker,you can easily separate speakers from the monitor and place them
where you want.
We accomplished to adapt the advanced design and technology to the monitor.
Soft touch buttons on the front panel are simple and allow you to conveniently
adjust a variety of image controls. The absolute flat screen and screen surface
treatment eliminate distracting glares.
It supports resolutions up to 1024x768, and has a wide viewing angle of ±60
degrees horizontal and ±45 degrees vertical.
Plug and play capability if supported by your system.
This monitor has DDC 2B function.*
Compliant with the following regulated specifications :*
- FCC Compliance Statement
- CE Conformity Notice
- EPA E
S
NERGY
TAR
- Swedish MPR II
- Swedish TCO'99
is a 15-inch (15 inches viewable) intelligent
*
For detailed information, please refer to the Reference Guide provided .
A1
Advertisement
Table of Contents
Related Manuals for LG FLATRON 575MM
Summary of Contents for LG FLATRON 575MM
- Page 1 Introduction The FLATRON LCD 575MM Flat Panel Monitor has an active matrix TFT (Thin-Film Transistor) LCD (Liquid Crystal Display). This monitor is designed for use in small working areas or for those who need more working space on the desk. Features FLATRON LCD 575MM is a 15-inch (15 inches viewable) intelligent...
-
Page 2: Connecting The Monitor
Connecting the Monitor To set up the monitor, ensure that the power is turned off to the monitor, computer system, and other attached devices, then follow these steps: Power off both the monitor and computer. Slightly press and pull the latch on Stand cover. Connect one end of the monitor signal cable to the input connector on the rear panel of the monitor. - Page 3 Connecting the Monitor Connection the Audio Connect the speaker as described in below picture. Connect the one end of Audio DC power cable,which is attached on the speaker to AUDIO DC OUT connector and the other end to DC 24V connector on the back of the speaker.Then connect the audio cable port which is directly connected to the speaker to AUDIO L-OUT port...
-
Page 4: Location And Function Of Controls
Location and Function of Controls Front View Speaker SOUND SOUND Power Button Power Indicator OSD Button Buttons AUTO/SET Button Rear View Audio DC Power Cable Audio Cable Stand cover Audio Buttons... -
Page 5: Front Panel Controls
Control Panel Function Front Panel Controls AUTO/SET Button OSD Button Power Button Button Power Indicator Control Function OSD Button Use this button to enter or exit the on screen display. Use these buttons to choose or adjust items in the on Button screen display. -
Page 6: On Screen Display (Osd) Control Adjustment
On Screen Display (OSD) Control Adjustment Making adjustments to the image size, position and operating parameters of the monitor are quick and easy with the On Screen Display Control system. A quick example is given below to familiarize you with the use of the controls. Following section is an outline of the available adjustments and selections you can make using the OSD. - Page 7 On Screen Display(OSD) Selection and Adjustment You were introduced to the procedure of selection and adjusting an item using the OSD system. Listed below are the icons, icon names, and icon descriptions of the items that are shown on the Menu. OSD Adjust Description Brightness...
-
Page 8: On Screen Display(Osd) Selection And Adjustment
On Screen Display(OSD) Selection and Adjustment OSD Adjust Description CLOCK To minimize any vertical bars or TRACKING stripes visible on the screen background.The horizontal screen CLOCK size will also change. PHASE To adjust the focus of the display. PHASE This item allows you to remove any horizontal noise and clear or sharpen the image of characters. -
Page 9: Video Memory Modes
Video Memory Modes The monitor has 26 memory locations for display modes, 16 of which are factory preset to popular video modes. Display Modes (Resolution) Display Modes (Resolution) Horizontal Freq.(kHz) Vertical Freq.(Hz) 31.47 640 x 350 31.47 720 x 400 31.47 640 x 480 35.00... -
Page 10: Troubleshooting
Troubleshooting Check the following before calling for service. Display Position is incorrect. Push the AUTO/SET Button. If the results are unsatisfactory, adjust the image position using the H position and V position icon in the on screen display. On the screen background, vertical bars or stripes are visible. Push the AUTO/SET Button. -
Page 11: Specifications
Humidity 10% to 80% non-condensing Storage condition Temperature -20˚C to 60˚C Humidity 5% to 95% non-condensing NOTE Information in this document is subject to change without notice and does not represent a commitment on the part of LG Electronics Inc.
