SERVICE MANUAL

AIR-CONDITIONER
OUTDOOR UNIT
<DIGITAL INVERTER>
RAV-SM2244AT8-E
RAV-SM2244AT8Z-E
RAV-SM2244AT8ZG-E RAV-SM2804AT8ZG-E
RAV-SM2244AT7
RAV-SM2244AT7Z
RAV-SM2244AT7ZG
R410A
SPLIT TYPE
RAV-SM2804AT8-E
RAV-SM2804AT8Z-E
RAV-SM2804AT7
RAV-SM2804AT7Z
RAV-SM2804AT7ZG
PRINTED IN JAPAN, Jun, 2009 ToMo
FILE NO. A09-004
