Connecting the Display

Using the Computer

1.
Connect the signal cable. When attached, tighten the thumbscrews to secure
the connection.
2.
Connect the power cord into a proper power outlet that is easily accessible and
close to the display.
NOTE
This is a simplified representation of the rear view.
This rear view represents a general model; your display
may differ from the view as shown.
*
Wall-outlet type
PC-outlet type
MAC
Power Cord
*
PC
Mac adapter
For Apple Macintosh use, a separate plug adapter is needed to
change the 15 pin high density (3 row) D-sub VGA connector
on the supplied cable to a 15 pin 2 row connector.
A4
Signal Cable
Analog signal
*
D-sub
* Varies according to model.
