Summary of Contents for Data Video ITC-100
- Page 1 8 WAY INTERCOM TALK BACK SYSTEM ITC-100 Instruction Manual w w w . d a t a v i d e o . c o m...
- Page 2 INTERCOM TALK BACK SYSTEM Welcome to the ITC-100 Instruction Manual Thank you for choosing a Datavideo product, please visit the support pages on our website for the latest version of the instruction manual. http://www.datavideo.info/Intercom+Systems/ITC-100 Don’t forget to register your product online to qualify for an additional free one year extension to the standard warranty, and to receive information from Datavideo on service &...
-
Page 3: Table Of Contents
Using the ITC-100 with the SE-500 Using the ITC-100 with the SE-2000 Using the ITC-100 with the SE-2800 Using the ITC-100 with the SE-3000 ITC-100 Tally Input - Pin Cross Reference Tally A Input Tally B Input Specifications Service & Support Disclaimer of Product and Services The information offered in this instruction manual is intended as a guide only. -
Page 4: Warnings And Precautions
INTERCOM TALK BACK SYSTEM Warnings and Precautions 1.Read all of these warnings and save them 11.Never push objects of any kind into this unit through the case ventilation slots, for later reference. 2.Follow all warnings and instructions as they may touch dangerous voltage points or short out parts that could result marked on this unit. -
Page 5: Packing List
ITC-100 Packing List Product Overview The ITC-100 is a 19” Rack Mount 8 Way Item Description ITC-100 Base Unit Intercom / Talkback System. It incorporates ITC-100SL Belt Packs tally indicators for each channel and ITC-100SL Carry Cases individual channel call buttons as well as a CB-3 20m Cables 5pin XLR to XLR call all channels button. -
Page 6: Base Unit Front Panel
TERMINAL Connections and Controls Panel On / Off Switch Powers the ITC-100 On / Off. Red LED indicates that unit is switched on. Channel Input / Output XLR Sockets Each of the 8 channels has an XLR connector that carries bi- directional signals between the ITC-100 and ITC-100SL. -
Page 7: Headphone Socket
SPEAKER Sounds audible alert when a channel is paging and provides audio during talkback conversations. Speaker is mute when headphones or mic / headset are connected to the ITC-100 12V Light Socket LIGHT 12V 12V Powered light socket for gooseneck light (supplied). -
Page 8: Itc-100Sl Belt Pack
Connects the ITC-100SL to the The ITC-100SL has both a 3.5mm MIC/ HEADPHONE ITC-100 Base Unit. Power, tally and 2.5mm Mic / Headset socket. and bi-directional audio are all A standard 3.5mm Mic / Headset carried through the same CB-3 can be used, or a Motorola type cable. -
Page 9: Cable Assignments Headset, Jack Plug And 5Pin Xlr
Datavideo already sell pre-manufactured XLR cabling for doing this in 20m (CB-3) and 50m (CB-4) lengths. Please ask your local dealer for price and availability of additional CB-3 and CB-4 cables. Pin Assigment for ITC-100 XLR Cable Cable Assignment Tally Red Black Tip (Talk &... -
Page 10: Using The Itc-100 With The Se-500
By using Datavideo G07690150018 cable, the Tally output from the SE-500 connects to the ITC-100 Tally Input A. Tally Input A provides tally information to channel 1 ~ 4. When the camera is live the cameraman will see a tally light in red, when the camera is cued up, the cameraman will see a tally light in amber. -
Page 11: Using The Itc-100 With The Se-2000
By using Datavideo G07690150018 cable, the Tally output from the SE-2000 connects to the ITC-100 Tally Input A. Tally Input A provides tally information to channel 1 ~ 4. When the camera is live the cameraman will see a tally light in red, when the camera is cued up, the cameraman will see a tally light in amber. -
Page 12: Using The Itc-100 With The Se-2800
By using Datavideo G07690250002 cable, the, the Tally output from the SE-2800 connects to the ITC-100 Tally Input A & Tally Input B. Tally Input A provides tally information to channel 1 ~ 4, Tally Input B provides tally information to channel 5 ~ 8. When the camera is live the cameraman will see a tally light in red, when the camera is cued up, the cameraman will see a tally light in amber. -
Page 13: Using The Itc-100 With The Se-3000
1 ~ 4, Tally Input B provides tally information to channel 5 ~ 7, ITC-100 channel 8 connects to ITC-200E channel 1 by XLR Cable, So ITC-100 channel 8 and ITC-200E channels1~8 are the same signal. When the camera is live the cameraman will see a tally light in red, when the camera is cued up, the cameraman will see a tally light in amber. -
Page 14: Itc-100 Tally Input - Pin Cross Reference
ITC-100 Tally Input - Pin Cross Reference If you are using the ITC-100 with a Datavideo product you do not need to worry about tally information, as it is automatically sent to the ITC-100. If you are using the ITC-100 with other equipments the following tables may help explain the pin configurations of the ITC- 100 Tally A and Tally B input. -
Page 15: Specifications
ITC-100 Specifications ITC-100 Base Unit Specification INPUTS POWER 12V / 1A (8W) / OUTPUTS TALLY 2 x 15 Pin D-Sub Sockets for Tally A and Tally B MIC / HEADSET 3.5mm Stereo Jack Socket for combination Headphone / Microphone Headset Impedance 8~600 ohms 100mW(min) HEADPHONE ¼”... -
Page 16: Service & Support
Service & Support It is our goal to make your products ownership a satisfying experience. Our supporting staff is available to assist you in setting up and operating your system. Please refer to our web site www.datavideo.com for answers to common questions, support requests or contact your local office below.
