- Page 1 SX-L3WD SERVICE MANUAL SPEAKER SYSTEM SX-L3WD Area Suffix Continental Europe Other Areas Contents Safety Precautions Disassembly method Standard schematic diagram No.20879 COPYRIGHT 2000 VICTOR COMPANY OF JAPAN, LTD. Nov. 2000...
- Page 2 SX-L3WD Safety precaution Burrs formed during molding may be left over on some parts of the chassis. Therefore, pay attention to such burrs in the case of preforming repair of this system.
- Page 3 SX-L3WD Holder Disassembly method Front net Removing the front net (See Fig. 1) Remove the front net from the four holders that are fixing the front net. Removing the tweeter (See Fig. 2&3) Removing the front net. Remove the three screws A attaching the tweeter using a hexagon wrench.
- Page 4 SX-L3WD Standard schematic diagram L1 0.56 mH C2 4.7 F/50V SP-11 LE10014-010A INPUT R1 3.3 /5W C1 2.2 F/50V SP-21 L2 0.33 mH LE10003-006A VICTOR COMPANY OF JAPAN, LIMITED AUDIO & COMMUNICATION BUSINESS DIVISION PERSONAL & MOBILE NETWORK BUSINESS UNIT. 10-1,1Chome,Ohwatari-machi,Maebashi-city,371-8543,Japan Printed in Japan No.20879...
