InFocus LP 420TM User Manual

INTRODUCTION
The In Focus LP 420™ is specifically designed for the mobile pre-
senter. It packs SVGA graphics with 16.7 million colors into a
small, 6.8 pound package. It generates crisp, clear images using
Digital Light Processing™ (DLP) technology. The LP 420 is easy
to connect, easy to use, and easy to maintain.
Image Resolution
The SVGA resolution of the 420's projected image is 800x600.
Screen resolutions between 800x600 and 1024x768 are com-
pressed to 800x600. The 420 cannot compress screen resolutions
above 1024x768. If your computer's screen resolution is higher
than 1024x768, reset it to a lower resolution before you connect
the 420.
Compatibility
The projector is compatible with a wide variety of computers and
video devices, including:
IBM-compatible computers, including laptops, up to 1024x768
•
resolution.
Apple Macintosh and PowerBook computers up to 1024x768
•
resolution.
Most standard VCRs, camcorders and laser disc players.
•
Unpacking the Projector
The projector comes with the items shown in Figure 1. Check to
make sure all are included. Contact your In Focus dealer imme-
diately if anything is missing.
If you are experienced in setting up presentation systems, use the
LP 420 Quick Start card that was included in the shipping box. For
complete details on connecting and operating the projector, refer
to this User's Guide. User's Guides are also available for down-
load from our website at www.infocus.com.
NOTE: The 420 automatically
expands 640x480 images to
800x600. You can display these
images at 640x480 by turning off
the Auto Resize feature. See "Auto
Resize" on page 20 for more infor-
mation.
NOTE: The 420 ships standard
with computer and audio cables. If
you want mouse control of your
computer, you must order the
optional CableWizard and remote.
1
