  • Page 1 SatKing DVBS-100HD Instruction Manual...
  • Page 3 SAFETY Safety Precaution The IRD is complied with international safety standards. Please read these simple guidelines carefully before using this device. Power Supply 90–250V AC 50/60Hz. Do Not Dismantle Do not attempt to dismantle the IRD. Opening the cabinet may cause malfunction or electric shock.
  • Page 4 CLEANING Disconnect the STB from the wall outlet before cleaning. Use dry cloth to Dust the STB. Avoid Object and Liquid Entry Do not insert any kinds of small objects, such as a coin, into the IRD as it may result in short circuit.

  • Page 5: Table Of Contents

    CONTENTS HOW TO USE THIS MANUAL This manual provides complete instructions for installing and using this receiver. SAFETY INSTRUCTIONS 1．Before You Begin 1.1 Features ......................4 1.2 Accessories ....................4 2．Controls and Functions 2.1 Front Panel..................... 5 2.2 Remote Control Unit ..................6 2.3 Rear Panel (The actual production will have difference.) ......

  • Page 6: Before You Begin

    1. Before You Begin 1.1 Features 1.1.1 Common Part Easy Graphic MENU Interface Supports DiSEqC 1.0/1.2,13/18V, 22Khz Tone RCA Connector Multi-language Function (Menu, Audio) Last Channel Memory OSD: Transparency &Blending, 256 Palette Colors Front Panel Buttons &IR Remote Controller User Interface Editing Functions (TV or Radio Channel, Channel Name, Favorite Name, Satellite Name) EPG for On Screen Channel Information...

  • Page 7: Front Panel

    2. Controls and Functions 2.1 Front Panel Display (4-digits 7-segments / 2LED) The 4-digits displays channel information. The green LED lights up when the channel is locked in. CH▲/CH▼ Move the cursor up/down in Menu state. Change the current program to the previous/next program in No-Menu state.

  • Page 8: Remote Control Unit

    2.2 Remote Control Unit All features of the set-top box can be controlled with the remote controller. : Press to switch between Operation and Standby modes. MUTE : Press to temporarily cut off the sound. NUMBER BUTTONS (0~9): Press to input Channel, Password, PID code and etc. TV/RADIO: Press to select the TV/RADIO mode.

  • Page 9: Rear Panel (The Actual Production Will Have Difference.)

    2.3 Rear Panel (The actual production will have difference.) RS232 Serial Port For firmware update, serial communication port (RS-232). LNB IN Connect the digital signal from your LNB of your satellite dish to this connector. LNB OUT Give you the possibility to connect an extra receiver (analogue or digital). Provide for the mobile storage.

  • Page 10: Connections

    3. Connections 3.1 Connecting to TV Connect the satellite signal from the LNB to the LNB IN connector. Connect the RCA connector at the back of the receiver to the RCA-in connector on your TV set. 3.2 Connecting to Dish Connecting a fixed satellite dish to your receiver Make your choice of which satellite you want to receive your signals from, and have your dealer aim your dish at the requested satellite.

  • Page 11: Setting And Operations

    4. Setting and Operations 4.1 Before Setting Starting up for the First Time Turn on your TV and receiver. If it is the first time using a receiver, you should set parameters for system configuration. After displaying the login screen, press the MENU button. The aside screen will be appeared.
  • Page 12 4.2.2 Language Setting In this menu, you can set the language parameters, such as menu language, subtitle language and so Use the ▲/▼ keys to select the item and the ◄/► keys to change the settings. Press EXIT to save your changes and exit the menu.
  • Page 13 4.2.5 Schedule Setting You can program the STB to perform a certain event at a specified time using the Schedule Settings. Use the ▲/▼button to select the item, and change the parameters using ◄/► button. Schedule: Select the timer that you want to modify.

  • Page 14: System

    4.3 System Press OK on System in the main menu, it will turn to the System menu. In this menu you can see the detailed system information, or return the system to the initial status in the Factory Default sub-menu. When a USB2.0 Storage device is inserted, the USB Function menu will be appeared.
  • Page 15 <ALL> You can see all the files in the USB storage device. The method of operation refers to the clue on the screen. Select files by ▲/▼, and then operating by the clue. Red: Press to play or view the selected file. Green: Press to sort the files.

  • Page 16: Setup

    Note:The detailed method of operation refers to the clue appear on the screen. That only MP3 audio files, JPEG or BMP images and recordings made on the USB device can be viewed, any other format is not supported. (Might not be compatible with all devices.
  • Page 17 list. If you completed setting, use Red button to Save, Blue button to Save & Exit. Use Red button to enter the menu of Edit Sat. Antenna: If you press OK in Antenna, the satellites’ list is displayed. Move the cursor to a satellite and press OK to select the satellite and have the list disappeared, or press the EXIT on the remote controller to cancel the setting and have the list disappeared.

  • Page 18: Edit Channels

    4.4.5 TP list In this menu you can edit the TP Frequency information. Show TP of the designated satellite. Signal power and quality is checked on the base of current TP value. If you want to change to other TP in the Frequency item use ◄/►...

  • Page 19: Program Guide

    Press Red buttom to select a channel, and press ▼/▲ to up/down, press OK button to stop move. Press Green button to lock a channel or unlock. If Channel is in the locked status, you must enter password code to view channel. Press Yellow button to skip the channel you choose.

  • Page 20: Pvr Functions

    Press the Red button to alter the program window. Press the ▼/▲ to select program. Press Yellow button to show the detailed information of the selected programs. If you press the Blue button，the highlighted program will be saved for reserve. If you have reserved some programs, you can book to record the programs by your purpose.
  • Page 21 In the menu of Video/stream, select files by ▲/▼, press OK or PVR► button to play. And then press ◄/► to choose the item under the screen, OK to operate. Or you can press PVR buttons to control. <PVR Remote Control Buttons> ◄◄: Fast reverse.

  • Page 22: Tv Menu At The Normal Mode

    4.8 TV menu at the normal mode At normal mode（no menu state）, various menus are displayed on the screen with remote control action. You can change the current status and mode with various buttons including the ▲/▼, SAT, i, and EPG button. The follow screen shows the banner displayed when you press the i button.

  • Page 23: A1 Trouble Shooting

    A1 Trouble Shooting There may be various reasons for the abnormal operation of the receiver. Check the receiver according to the procedures shown below. SYMPTOM CAUSE REMEDY The LED doesn ’t The power cord is not Check that the power cord is light up plugged in.

  • Page 24: A2 Specifications

    A2 Specifications 1 Tuner &Channel <Digital Part> Type .......……..1×F-type,IEC169-24 Female Frequency Range ....950MHz to 2150MHz Input Impedance ....75 ohm unbalanced Signal Level ....…..-25 to 65 dBm LNB Power ....…..13.5/18.5Vd 5%, 0.5Amax, Overload protected ± 22kHz Tone ....…..Frequency: 22k Hz 2kHz Amplitude: 0.6V 0.2V ±...
  • Page 25 4 A/V &Data In/Out TV/VCR Scart Output ..…..RGB, CVBS, L, R Output with Volume Control (optional) RCA Output ...…...…... CVBS, L, R Output (Yellow, White, Red Jack) ......………..…..with Volume Control 5 Power Supply Input Voltage ....…..….AC 90~250V, 50/60Hz Power Consumption ..…..Max. 20W Protection ....…….…...Separate Internal Fuse ......…………..The Input shall have the lighting protection 6 Physical Specification...

  • Page 26: A3 Glossary Of Terms

    A3 Glossary of Terms C band 3.7~4.2 GHz Frequency. DiSEqC Digital Satellite Equipment Control. Ku band 11~18GHz Frequency. LNB (Low-Noise Block Converter) The LNB is an electronic unit mounted on the satellite dish. It receives the signals reflected by the dish and converts them to signals that can be used by Satellite receiver.
