- Page 1 Zuvo Water Filtration System 150 Series IMPORTANT SAVE THIS BOOKLET Includes: • Safety Warnings • Warranty • Operating Instructions • Troubleshooting Guide • Accessories Owner’s Manual Page 1...
-
Page 2: Table Of Contents
• Always unplug an appliance from an outlet when not in use, microbiological contaminates. before putting on or taking off parts and before cleaning. • Read and observe all of the important notices on the appliance. Please note the following use restrictions: • Extension Cords: Use only extension cords that have an electrical rating not less than the rating of the product. Do not use 1. Water entering the unit must be free of sediment and damaged extension cords. Examine extension cords before using and replace if damaged. Do not abuse extension cords loose scale or rust. If your water does not meet these and do not yank on the cord to disconnect it from the receptacle. requirements, it must be pre-filtered prior to entering the Keep the cord away from heat and sharp edges. Always unit. disconnect the extension cord from the receptacle before disconnecting the product from the extension cord. WARNING: to reduce the risk of electrocution, keep all connections 2. For optimum performance, the unit must be monitored dry and off the ground. Do not touch the plug with wet hands. periodically to ensure proper operation. • Do not operate unit without it being fully assembled, as the ultraviolet (UV) light is harmful to eyes when directly exposed. • Do not use an appliance for anything other than its intended use. The use of attachments not recommended or sold by Zuvo Water may cause unsafe conditions. For Household Use Only SAVE THESE INSTRUCTIONS Page 2... -
Page 3: Warranty, Parts List, Troubleshooting Guide
Warranty Parts List The Zuvo Water Filtration System has a one (1) year limited To assist you in identifying components of your Zuvo Water warranty to the original user, to be free from defect in Filtration System, the parts have been numbered as follows: material and workmanship, from the date of purchase. This 1 Top Cap unit is designed for non-commercial applications. Use in 2 Sealing Clamps commercial applications will void this product warranty. Supplier liability under this warranty is strictly limited to 3 UV Lamp repairing or replacing (at supplier’s option), without charge, 4 Lamp Replacement / Tubing Disconnect Tool FOB supplier’s authorized service facility, the unit or units. 5 Filter (supplied inside the unit) Both Zuvo Water and your supplier will not will not be held liable for any costs of removal, installation, transportation to an authorized service center, or any other charges which may arise in connection with a warranty. Both Zuvo Water and your supplier will not be held liable for damage or wear to products caused by abnormal operating conditions, accident, abuse, misuse, unauthorized alteration or repair, or if the unit was not installed in accordance with printed installation and operating instructions. This warranty does not cover replacement filters. Replacement of lamp assemblies is limited to a period of one (1) year from the date of purchase. -
Page 4: General Operating Instructions
COLD water to flow through the system according to the operating instructions 2 beeps Change filter soon below before drinking or using the water. Never 3 beeps Change filter immediately flush or operate the Zuvo system with hot water. 4 beeps Flush new filter The Zuvo system includes a filter and will alert you that an initial filter flush is needed by beeping FOUR times 5 beeps System problem every 30 seconds until the Zuvo faucet is turned ON. - Page 5 Startup System Trouble Found When the Zuvo Water Filtration System is initially plugged in it will beep ONE time. If system trouble is found, the Zuvo system will beep FIVE times every 30 seconds. Once the Zuvo system is plugged in and has beeped ONE time, the system needs to be flushed with COLD Action Possible Problem water prior to drinking or using the water. The system Unplug system and plug system back System needs to be rebooted will beep FOUR times every 30 seconds until the Zuvo Unplug system, remove filter, rotate ¼ turn, reinstall Filter unknown faucet is turned ON to remind you that the system needs to be flushed prior to use. While the Zuvo faucet is turned ON during flushing, the system will beep ONE time every 10 seconds. Once the Zuvo system stops beeping every 10 seconds, the system is ready and the faucet can be turned OFF. The system is ready for operation and you can enjoy the benefits of healthy, great-tasting water. Normal Operation When there is more than two weeks (typical use) of filter capacity remaining, the Zuvo system will beep ONE time whenever the Zuvo Beverage Faucet is turned ON. Less than Two Weeks or Approximately 40 Gallons...
-
Page 6: How To Replace Filter
4. Pull both locking WARNING tabs down. It is extremely important that the unit be unplugged. The Zuvo Water Filtration System contains a high-intensity ultraviolet (UV) light that can damage tissues in the eye. The UV light cannot travel through the plastic housing. However, removing the filter requires that the top cap be removed, exposing the lamp. -
Page 7: How To Replace Uv Lamp
How To Replace UV Lamp 4. Pull the module straight out of the unit. The lamp should be replaced whenever it fails to light during operation. The Zuvo Water Filtration System uses a high-intensity ozone generating UV bulb module which can be obtained from your supplier. For proper unit operation, use only lamp modules supplied by your supplier. Simply follow the steps below: 1. Always unplug the unit 5. Ensure the lamp and the protective O-ring are before servicing. completely out of the unit. Failure to do so can result in exposure to harmful UV light. 6. Carefully insert replacement module, ensuring that protective O-ring remains in place. 2. Using the plastic screwdriver, break the paper label at the ‘X’ and unscrew the single screw. 7. Position module and replace screw. 3. Carefully loosen and begin to pull out the lamp/ballast cord module. Page 7... -
Page 8: Specifications
The Zuvo Water Filtration System Specifications General description Self-contained filtration/UV/ozone under-counter or countertop water filtration system Minimum/Maximum Water Temperatures 40–100º F (4–38º C) Contaminant Reduction Lead 99%, cysts 99.98%, chlorine taste/odor 99% Non-Pathogenic Microorganism Reduction 99.9% UV Exposure Intensity Class B (16 mJ/cm Physical Dimensions (W x D x H) 4.75 in. x 4.5 in. x 16 in. (120 mm x 120 mm x 400 mm) Weight 1.9 lbs (0.8 Kg) dry and empty Filter Life Rating 500 gallons (1,900 liters) or 6 months depending on use conditions Particulate Reduction Class I UV Lamp Life Up to 10,000 + on/off cycles (approximately 3 years) depending on use conditions Flow Rate 0.4 gal/min ( 1) The Zuvo Water Filtration System has been tested against NSF/ANSI Standards 42, 53 and 55 Class B for lead, cyst and particulate reduction, and for UV performance. - Page 9 Zuvo Water Filtration System Serie 150 IMPORTANTE GUARDE ESTE FOLLETO Incluye: • Advertencias de seguridad • Garantía • Instrucciones de funcionamiento • Guía para solucionar problemas • Accesorios Manual del usuario...
- Page 10 Cuándo reemplazar el filtro ......Página 12 IMPORTANTE: No utilice cualquier grifo que no sea un grifo suministrada por Zuvo Water. Si no sigue estas instrucciones, se puede anular la Para reemplazar el filtro ......Página 14 garantía o dañar la unidad Zuvo.
- Page 11 Garantía Guía para la solución de problemas ADVERTENCIA El Zuvo Water Filtration System tiene un (1) año de garantía limitada para el usuario original, siempre que no tengan DESENCHUFE EL CABLE DEL TOMACORRIENTE ANTES DE REPARARLO defectos de materiales ni mano de otra, desde la fecha de compra. Esta unidad no está diseñada para uso comercial. PROBLEMA ÁREAS A CONTROLAR FUENTE POSIBLE El uso comercial anula la garantía de este producto. La UNIDAD CON Comprobar que el tubo esté Tubo sin ajuste firme y/o FILTRACIONES EN LA(S) conectado de forma apropiada anillo de seguridad del tubo obligación del proveedor bajo esta garantía se limita CONEXIÓN(ES) DEL TUBO y que el anillo de seguridad esté...
- Page 12 El sistema no funcionará si el mismo filtro gastado es eliminado y volver a insertarse al sistema Zuvo. Para instalaciones sobre encimeras, después de instalar el Zuvo Water Filtration System o Guía rápida reemplazar el filtro de agua siempre permiten agua FRÍA fluya a través del sistema de acuerdo con el...
- Page 13 Inicio Problema del Sistema encontrados Cuando el Zuvo Water Filtration System se conecte Si un problema se encuentra en el sistema, el por primera vez se emitirá un zumbido UNA vez. sistema Zuvo emitirá un zumbido CINCO veces cada 30 segundos. Una vez que el sistema de Zuvo está enchufado y ha zumbado una vez, el sistema debe ser enjuagado con Acción Posible Problema agua fría antes de beber o de usar el agua. El sistema Desconecte el sistema y vuelva a conectarla Sistema necesita ser reiniciado emitirá un zumbido CUATRO veces cada 30 segundos...
- Page 14 Para reemplazar el filtro ADVERTENCIA 4. E mpuje las presillas de seguridad hacia Es de suma importancia que la unidad se encuentre abajo. desenchufada. Sistema contiene la luz ultravioleta (UV) de alta intensidad que puede dañar los tejidos oculares. La luz UV no puede pasar a través del contenedor de plástico.
- Page 15 Para reemplazar la lámpara UV La lámpara debe reemplazarse cuando se apague y el dispositivo esté en funcionamiento. El Zuvo Water 4. T ire el módulo Filtration System utiliza una bombilla UV que genera directamente ozono de alta intensidad, la cual se puede adquirir de hacia afuera de un proveedor. Para un funcionamiento adecuado, utilice la unidad. sólo módulos de lámpara que venda su proveedor. Simplemente siga los pasos a continuación: 1. S iempre desenchufe la unidad antes de repararla. Si no lo 5. Asegúrese de hace puede que la lámpara exponerse y la junta tórica a la luz UV. de protección estén completamente fuera de la unidad.
- Page 16 El Zuvo Water Filtration System Especificaciones Descripción general Contiene un sistema de filtración de agua de UV/Ozono por uso debajo de la encimera o un unidad por uso sobre la encimera. Temperatura de agua mínima/máxima 40 º F – 100 º F (4 º C – 38 º C) Reducción de contaminantes Plomo 99%, partículas 99,98%, sabor/olor a cloro 99% Reducción de Microbios no Pathógenos 99,9% Intensidad de exposición a UV Clase B (16 mJ/cm Dimensiones físicas (A x D x A) 4.75" x 4.5" x 16" (120 mm x 120 mm x 400 mm) Peso 1.9 lbs (0,8 Kg) seco y vacío...
