NAD C 521BEE Service Manual page 24

Reference No.
LIVE ASSY
PC BOARD
*AH
*CE
SWITCH
M802
PC BOARD
MISCELLANEOUS
C800
M801,M803,M806
M804 *CE
M805 *AH
M810 *CE
MAIN ASSY
PC BOARD
CAPACITOR
C101-C103,C207,C208,C210,
C213,C217,C222,C227,C228,
C304,C386,C521
C105-C110,C230,C522
C111
C201,C202,C204,C205
C203,C216,C221,C303,C387
C206,C352,C353
C209,C223
C211,C212
C214,C215
C218
C219,C220
C226
C301,C302
C305
C307,C309
C308,C320,C321,C323-C325,
C332,C334
C310,C508,C525
C322,C326,C327,C380,C381,
C417,C501-C526,C528,C531,
C532,C534,C535,C537,C540-C543
C328,C329
C330
C362,C363
C366,C367
C368,C369,C375,C376
C377-C379,C382
C383
C384
Part No.
PCB-N0A60C-LIVE
PCB-N0A61C-LIVE
5200-3151-0-01
1725-221A-0102
8910-0049-0
4132-1071-0
4132-1071-0
4132-1071-0
1806-2170-0
PCB-N0A60C-MAIN
150F-104K-2-FC
157D-107M-5-IU
157F-225M-5-IUNK
150F-221K-2-FC
150F-103K-2-FC
150F-331K-5-GE
153F-152J-5-JM
15CH-270J-5-GG
150F-471K-2-FC
150F-101K-2-FC
150F-474M-5-II
157F-334K-5-IU
15CH-330J-5-IG
157D-227M-5-OMK
157C-476M-5-IU
157B-106M-5-EI
157C-108M-5-S5
157B-106M-5-EI
15CH-200J-5-GG
153F-103J-5-IM
153F-472J-5-KM
158F-681J-5-KW
157E-226K-5-IU
153F-224J-5-MIB
157C-226M-5-IU
150F-102K-2-FC
- 24 -
Description
PCB ASSY LIVE N0A60C
PCB ASSY LIVE N0A61C
POWER SWITCH
PCB MAIN N0A10C C521I
CAP400V 4700P
TERMINAL PIN
TERMINAL PIN
TERMINAL PIN
EMI FILTER TLN12UA
PCB ASSY MAIN N0A60C
CC 50V 0.1µF 10% AT 3.5x2
CE 16V 100µF 20% RL 5x11
CE 50V 2.2µF 20% RL 5X11
CC 50V 220pF 10% AT 3.5x2
CC 50V 0.01µF 10% AT 3.5x2
CC 50V 330pF 10% RL 4x3
CM 50V 1500PF 5% RL 5.8x7
CTC 0/60 27pF 5% RL 4x4
CC 50V 470pF 10% AT 3.5x2
CC 50V 100pF 10% AT 3.5x2
CC 50V 0.47µF 20% RL 5X5
CE 50V 0.33µF 10% RL 5x11
CTC 0/60 33pF 5% RL 5x4
CE 16V 220µF 20% RL 8x7
CE 10V 47µF 20% RL 5x11
CE 6.3V 10µF 20% RL 3x5
CE 10V 1000µF 20% RL 10x16
CE 6.3V 10µF 20% RL 3x5
CTC 0/60 20pF 5% RL 4x4
CM 50V 0.01µF 5% RL 5X7
CM 50V 4700pF 5% RL 6x7
CP 50V 680pF 5% RL 6x12
CE 25V 22µF 10% RL 5x11
CM 50V 0.22µF 5% RL 7x5
CE 10V 22µF 20% RL 5x11
CC 50V 1000pF 10% AT 3.5x2
