M1709Z 17.3-Inch Digital Photo Frame

Got a Question or Need Help?

Email our technical support team at: support@miccatron.com for

personalized assistance with the setup and use of this product. Please visit

our product information website www.miccatron.com for the following:

- Firmware Updates

- User's Manuals

- Troubleshooting Wizard

- Technical Support Request

When contacting technical support, be sure to include your order information,

product model, and serial number from the bottom of the player.

This manual may not be reproduced in whole or in part without

With 8GB Micro USB Storage

permission for any purpose other than personal use.

Owner's Manual

Table of Contents

Need help?

Do you have a question about the M1709Z and is the answer not in the manual?

Questions and answers

Summary of Contents for Micca M1709Z

Page 1 When contacting technical support, be sure to include your order information, product model, and serial number from the bottom of the player. Copyright © 2009-2013 Micca, Ltd. All rights reserved. This manual may not be reproduced in whole or in part without permission for any purpose other than personal use.
Page 3 Thank you very much for purchasing this digital photo frame. We hope you will enjoy using it to view your treasured photos. This photo frame has the following features: 1.1.1 Highlights M1709Z: 17.3-Inch 1600x900 high resolution LCD screen 16:9 widescreen ratio for dramatic movie-like display effect Included 8GB micro USB storage drive Slim profile with curved back case design for modern appearance 1.1.2 Features...
Page 4: Precautions And Maintenance
Please power off the unit before inserting or removing a memory card or USB drive. Do not put the unit near water or a high-moisture environment to prevent the risk of electric shock. Copyright © 2009-2013 Micca, LTD. All rights reserved.
Page 5: Connections And Buttons
Note: Only use the AC adapter that is provided with the digital photo frame. Using a different AC adapter may damage the unit. The Mini USB port is optional and may not be present. Copyright © 2009-2013 Micca, LTD. All rights reserved.
Page 6: Remote Control
Zoom in when viewing a photo (slideshow must be paused) Previous Go to previous file during music or video playback Next Go to next file during music or video playback Rotate Rotate a photo 90 degrees (slideshow must be paused) Copyright © 2009-2013 Micca, LTD. All rights reserved.
Page 7: Getting Started
USB jack on the photo frame, turn the photo frame on, and the photos will automatically begin displaying. Mac OS users, please see additional instructions in the troubleshooting section at the end of this manual. Copyright © 2009-2013 Micca, LTD. All rights reserved.
Page 8 To select a storage device, press the “Menu/Return” button repeatedly until the storage selection screen is shown. Highlight the desired storage device and press “Play/Pause/Enter” to select it. Copyright © 2009-2013 Micca, LTD. All rights reserved.
Page 9: Viewing Photos
Press to pause current song, press again to resume playing Fast Forward Press to fast forward current song, press again to resume playing Shuffle/Loop Press to toggle between different shuffle and loop playback Copyright © 2009-2013 Micca, LTD. All rights reserved.
Page 11 Be sure to properly set the date and time in the settings menu so that the information displayed is correct. The photo frame will automatically begin playing a slideshow using photos found on the selected storage device. Copyright © 2009-2013 Micca, LTD. All rights reserved.
Page 12: Detailed Settings
Changes the display parameters of the LCD screen. The default values are optimal for most conditions. Volume Sets the speaker volume during music and video playback. Version Display the current firmware version information Copyright © 2009-2013 Micca, LTD. All rights reserved.
Page 13: Photo Setup
Photos will be displayed in their normal sequence alpha- numerically based on file name. Random Photos will be displayed in random sequence. Background Music Enable or disable background music when viewing photo slideshows. Available Values: On, Off Copyright © 2009-2013 Micca, LTD. All rights reserved.
Page 14: Calendar Setup
Available Values: 12 Hours, 24 Hours Time Set the current time in the format of Hour, Minute, and Second. Available Settings: Hour, Minute, Second Alarm Status Enable or disable the alarm function Available Settings: On, Off Copyright © 2009-2013 Micca, LTD. All rights reserved.
Page 15 Setting Description Once Feature is active only once. Every Day Feature is active every day. Mon. to Fri. Feature is active Monday through Friday Weekend Feature is active on Saturday and Sunday Copyright © 2009-2013 Micca, LTD. All rights reserved.
Page 16: Video Setup
A single music file will be looped continuously. Sequence Music files will be looped continuously in their normal sequence alpha-numerically based on file name. Random Music files will be played continuously in random sequence. Copyright © 2009-2013 Micca, LTD. All rights reserved.
Page 17: Troubleshooting Guide
Irfanview. Doing so typically fixes issues caused by corrupted image files. Irfanview comes with detailed instructions on how to reprocess JPG files in batch mode. Copyright © 2009-2013 Micca, LTD. All rights reserved.
Page 18: Specifications
Music Format: MP3 up to 320kbps Video Format: AVI MP4 Files, MPEG1/2/4 for video and MP3 for audio LCD Screen: M1709Z Size 17.3-Inch TFT Resolution 1600x900 Aspect Ratio 16:9 Brightness 250-500cd/m2 Contrast 500-1000:1 Response Time 20ms Copyright © 2009-2013 Micca, LTD. All rights reserved.
Page 20 Information in this manual is believed to be accurate and reliable but Micca Ltd assumes no responsibility for its use nor for any infringement of patents or other rights of third parties which may result from the use of this manual or the product.
