Infinity Sterling Series SS 2001 SS 2001 Technical Manual

Technical Manual
SS-2001
Sterling Series 2-Way Speaker

SPECIFICATIONS

ACOUSTIC & ELECTRICAL SPECIFICATIONS:
Nominal Impedance:
Power Rating:
Sensitivity:
Crossover Frequencies:
Frequency Response:
PRODUCTION HISTORY
Introduced in 1993
Discontinued 1996
Original Retail Price: $159.00/pair

TECHNICAL INFORMATION

INPUT
REV A 8-98
INFINITY SYSTEMS INC., 250 Crossways Park Drive, Woodbury, New York 11797
8 ohms
10-60 watts
90dB
4500Hz
74Hz-20kHz +/-3dB
POLYCELL
TWEETER
#902-2226
R1 1.0 . 5W
L1
0.60mH
PHYSICAL SPECIFICATIONS:
1x - 1/2" (1.27cm) Polycarbonate Tweeter
1x - 5-1/4" (16.3cm) Polycarbonate
Dimensions: 9"H x 11-5/8"W" x 6-5/8"D
XXXXXXXXX 22.8cm(H) x 13.3cm(W) x 16.8cm(D)
Cabinet
Grille
Crossover
Logo
5-1/4" WOOFER
#902-5233
C1
2.5 F
NPE
C2
6.8 F NPE
Woofer
XXXXXXXXXXX
Not Sold
#026-6728
#A015-6738
#716-6722
12" BLUE
.205" FEMALE CLIP
TWEETER
12" BLU/BLK,
.110" FEMALE CLIP
9" RED
.250" FEMALE CLIP
WOOFER
9" RED/BLK
.205" FEMALE CLIP
