LG DLE5932S Owner's Manual

Electric and gas dryer
Hide thumbs Also See for DLE5932S:
Table of Contents

Advertisement

Quick Links

See also: Service Manual , User Manual

Advertisement

Table of Contents
loading

Related Manuals for LG DLE5932S

Summary of Contents for LG DLE5932S

  • Page 2 Electric and Gas Dryer MANUAL DEL PROPIETARIO Secadora de Eléctrica y Gas Gracias por comprar una secadora Completamente Automática LG. Por favor lea su manual del propietario cuidadosamente, ya que le proveerá de instrucciones sobre la segura instalación, manejo y mantenimiento. Consérvelo para futuras referencias, archive...

  • Page 3: Table Of Contents

    Please read this manual. It will help you install and operate Use the space below to record the model number your new LG dryer in the safest and most economical way. and serial number of your new LG dryer. If you need more information about the care and operation of Model No.

  • Page 4: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USING. WARNING! For your safety, the recommendations in this manual must be followed. To reduce the risk of fire or explosion, electric shock, or to prevent property damage, personal injury, or death when using your appliance, follow basic precautions, including the following. Do not store or use gasoline or other Installation and service must be flammable vapors and liquids in the...
  • Page 5 IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS WARNING - To reduce the risk of fire, electric shock, or 8) Do not repair or replace any part of the appliance or attempt any servicing unless specifically recommended in injury to persons when using your appliance, follow basic the user-maintenance instructions.

  • Page 6: Lg Dryer Warranty

    If you do need service, you can relax knowing help is only a phone call away. A list of toll-free customer service numbers is included in the back section. In the U.S., you can always call the LG Answer Center.

  • Page 7: Installation Instructions

    INSTALLATION INSTRUCTIONS Installation clearances Closet installation - Dryer only Closet installation The location must be large enough to fully open the dryer door. Dryer Dimensions 3" 14" max (7.6 cm) (35.6 cm) 48" 18" (45.72 cm) (310 cm 43" (109.22 cm) 24"...

  • Page 8: Installing The Dryer

    INSTALLING THE DRYER Step 1 : Position and Level the Dryer DO NOT use plastic or thin foil ducting. For further assistance refer to section on Location Locate dryer so exhaust duct is as short as Requirements. possible. Be certain old ducts are cleaned before installing Place the dryer in position, and adjust the legs until the your new dryer.
  • Page 9 INSTALLING THE DRYER Step 3 : Connect Gas Supply Pipe (Gas Dryer ONLY) For further assistance, refer to section on Gas Requirements. 1. Make certain your dryer is equipped for use with the 3. Connect to gas supply pipe using a new flexible type of gas in your laundry room.

  • Page 10: Heat Source Check

    Step 4: (Electric Dryer Only) Connect Heat Source Check Electrical Plug Electric Dryers For further assistance refer to section on Electrical Requirements. Close the loading door and start the dryer in a heat setting (refer to the Operating Instructions supplied with IMPORTANT : Use only a new U.L.

  • Page 11: Door Reversal Procedure

    DOOR REVERSAL PROCEDURE The door on this dryer is completely reversible. Remove screw & exhaust duct. To reverse door proceed as follows: Detach and remove the bottom, left or right side knockout as desired. Reconnect the new duct[11 in(28cm)] to the blower housing, and Fixing the duct to the base.

  • Page 12: Manufactured (Mobile) Home Installation

    MANUFACTURED (MOBILE) HOME INSTALLATION IMPORTANT : Installation must conform to the Manufactured Home Construction and Safety Standards, Title 24 CFR, Part 32-80 or Standard CAN/CSA-Z240 MH. Dryer exhaust duct MUST NOT terminate under the The dryer can be installed in a manufactured (mobile) mobile home.

  • Page 13: Electrical Requirements - Electrical Dryer

    ELECTRICAL REQUIREMENTS - ELECTRICAL DRYER Electric Dryers The dryer has its own terminal block that must be connected to a separate branch, 60 Hertz, single phase (120V/240 Volt, 60 Hertz, 3-Wire Installation) circuit, AC (alternating current) circuit, fused at 30 (120V/208 Volt, 60 Hertz, 3-Wire Installation) Amperes (the circuit must be fused on both sides of NOTE : The wiring diagram is located inside the...
  • Page 14 Electrical Connection Options 1. Remove center terminal block screw. 2. Remove appliance ground wire (green) from external If your home has: And you will be Go to Section ground connector screw. Fasten it under center, silver connecting to colored terminal block screw. 4-wire receptacle A UL listed, 120/240 4-wire connection:...
  • Page 15 ELECTRICAL REQUIREMENTS - ELECTRICAL DRYER When connecting to the terminal block, place the hooked 3-wire connection: Power supply cord end of the wire under the screw of the terminal block (hook facing right), squeeze hooked end together and tighten Use where local codes permit connecting screw.
  • Page 16 3-wire connection: Direct wire Optional 3-wire connection Use where local codes permit connecting Use where local codes permit connecting cabinet-ground conductor to neutral wire. cabinet-ground conductor to neutral wire. Direct wire cable must have 5 ft (1.52 m) of extra 1.

  • Page 17: Electrical Requirements - Gas Dryer

    ELECTRICAL REQUIREMENTS - GAS DRYER NOTE : A qualified electrician should check the Gas Dryers polarity of the wall receptacles. If a voltage reading is (120 Volt, 60 Hertz, with 3-Prong Grounding Plug) measured other than that illustrated, the qualified electrician should correct the problem.

  • Page 18: Grounding Instructions

    Grounding Instructions The dryer must be grounded. In the event of malfunction or breakdown, grounding will reduce the risk of electric shock by providing a path of least resistance for electric current. The dryer is equipped with a cord having an equipment-grounding conductor and a three prong grounding plug.

  • Page 19: Gas Requirement

    GAS REQUIREMENTS Gas Dryers NOTE : The gas service to a gas dryer must conform When a rigid pipe is used it should be 1/2 inch IPS. with the local codes and ordinances or, in the absence When acceptable to the gas supplier and local codes, 3/8- of local codes and ordinances, with the latest edition inch approved tubing may be used for lengths under 6.1 of the National Fuel Gas Code ANSI Z223.1/NFPA...

  • Page 20: Exhaust Requirements

    EXHAUST REQUIREMENTS Exhaust System Materials WARNING Exhaust system materials are not supplied with the dryer. A clothes dryer produces combustible lint. Exhaust duct must be four inches (10.2 cm) in diameter To reduce the risk of fire or gas having no obstructions. Rigid metal duct is accumulation, the dryer MUST be recommended.
  • Page 21 EXHAUST REQUIREMENTS Weather Hood Type Number of 90° Elbows Use Only for Short Run Installations Recommended 4” 4” 2-1/2” (10.2 cm) (10.2 cm) (6.35 cm) Maximum length of 4” (10.2 cm) diameter rigid metal duct 65 feet (19.8 m) 55 feet (16.8 m) 55 feet (16.8 m) 47 feet (14.3 m) 47 feet (14.3 m)

  • Page 22: Exhaust System Maintenance

    Exhaust System Maintenance Dryer Airflow The dryer interior and the complete exhaust system Efficient dryer operation requires proper dryer airflow. should be inspected after one year of use and cleaned if Proper dryer airflow can be evaluated by measuring the necessary.

  • Page 23: Operation Instructions

    USER MAINTENANCE Lubrication Cleaning the Lint Screen All moving parts are sealed in a permanent supply of lubricant or are equipped with oilless bearings. Every load cleaning Additional lubrication will not be necessary. The lint screen is located in the door opening of the Care of Your Dryer dryer.

  • Page 24: Features And Benefits

    FEATURES AND BENEFITS WARNING - To reduce the risk of fire, electric shock, or injury to person, read the IMPORTANT SAFETY INSTRUCTIONS before operating this appliance. DLE5911W / DLG5911W DLE2511W / DLG2511W DLE5932W / DLG5932W / DLE5932S / DLG5932S DLE2532W / DLG2532W...

  • Page 25: Starting Your Dryer

    FEATURES AND BENEFITS Starting Your Dryer WARNING WARNING Explosion Hazard Fire Hazard Keep flammable materials and vapors, No washer can completely remove oil. such as gasoline, away from dryer. Do not dry anything that has ever had any Do not dry anything that has ever had type of oil on it (including cooking oils).

  • Page 26: Stopping Your Dryer

    Press and hold RACK DRY and ANTI BACTERIAL for 2 DLE5932W/G5932W DLE2532W/G2532W seconds. A single BEEP Tone is heard, and CL is DLE5932S/G5932S displayed. To unlock, press and hold RACK DRY and ANTI BACTERIAL for 2 seconds. The indicator light To use a Manual Dry Cycle turns off.

  • Page 27: Cycle Descriptions

    FEATURES AND BENEFITS Cycle Descriptions Sensor Dry Preset Cycle Settings Select the drying cycle that matches the type of Sensor Dry Temp. Time*(Minutes) load you are drying. Cycles Load (See Sensor Dry or Manual Preset Cycle Settings Type charts.) HEAVY DUTY High Heavyweight, jeans Sensor Dry Cycles allow you to match the cycle to the...
  • Page 28 Modifiers Manual Preset Cycle Settings Use Modifiers to select temperatures for the Manual Manual Dry Temp. Default Time* Cycles. Press TEMP. CONTROL until the desired Cycles Load (Minutes) temperature setting glows. Temperature modifiers Type cannot be used with the Sensor Dry Cycles. High SPEED DRY SMALL LOADS...

  • Page 29: Before You Call For Service

    FEATURES AND BENEFITS RACK DRY ANTI BACTERIAL The dryer rack is shipped in place in your dryer. This option can only be used with the HEAVY DUTY, COTTON/TOWELS and NORMAL cycles. Remove and discard any packing material before use. This option reduces certain types of bacteria. The ANTI BACTERIAL process produces high Use the RACK DRY for items that you do not want to tumble dry, such as sweaters.

  • Page 30: Troubleshooting Tips

    BEFORE YOU CALL FOR SERVICE Troubleshooting Tips Save time and money! Review the charts on the following pages first and you may not need to call for service. Problem Possible Causes What To Do Dryer doesn’t start Dryer is unplugged •...

  • Page 31: Customer Service

    Problem Possible Causes What To Do C l o t h e s t a k e t o o l o n g t o Improper sorting • Separate heavy items from lightweight items d r y (generally, a well-sorted washer load is a well-sorted dryer load).

  • Page 32: Lg Dryer Limited Warranty

    LG DRYER LIMITED WARRANTY - USA...
