- Page 1 CR Series CD-R/RW Drives INSTALLATION MANUAL VERSION 5.1...
- Page 2 Mitsumi Internal CD-ReWritable Quick Installation Guide 1. Start by shutting down the computer along with the monitor and any other peripherals. 2. Unplug the power cord from the computer. 3. Remove the computer case cover. 4. Remove the cover from an empty drive bay.
-
Page 3: Power Cable
Rear View of the Drive Power Cable Audio Cable 40-pin Interface Cable Pin #1 Power Cable - Supplies power to the CD-R drive from a standard PC AT power supply. 40-pin Interface Cable - Connection for 40-pin ribbon IDE interface cable. Audio Cable - Provides stereo audio output to a sound card. - Page 4 Mitsumi External CD-ReWritable Quick Installation Guide 1. Using an audio cable, connect your drive to your speakers. 2. Next, connect the power cable and plug into a power source. 3. Turn the power of the External CD-R/RW Drive on. 4. Connect the USB cable to the PC.
-
Page 5: Power Switch
Rear View of the Drive Audio Out Power Switch USB Connector Power Cable Power Cable - Supplies power to the external CD-R/RW drive . USB Connector - Connection for USB interface cable. Audio Out - Provides stereo audio output to a speaker. Power Switch - Power on/off... -
Page 6: Safety Information
Safety Information Please follow all safety warnings and instructions printed in this manual and on the CD-R/RW drive to avoid damaging your drive or harming yourself. Never attempt to service the drive yourself. No user serviceable parts are inside the unit. Opening or removing the cover can expose you to dangerous voltage levels, laser beams, and other hazards. - Page 7 Federal Communications Commission (FCC) Information This unit generates and uses radio frequency energy and if it is not installed and used properly in strict accordance with the manufacturer’s instructions, it may cause interference with radio and television reception. This unit has been tested and found to comply with the limits for a class B computing device, in accordance with the specifications in Part 15 of the FCC rules which are designed to provide reasonable protection against such interference in a...
-
Page 8: Fcc Declaration Of Conformity
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, includ- ing interference that may cause undesired operation. MITSUMI Electronics Corp. 5808 W.Campus Circle Dr. Irving, TX. 75063 Tel. - Page 9 CR-4802TE Specifications Supported Disc Formats CD-ROM Mode 1; CD-DA; CD-i; Video CD; CD-Extra (CD Plus) CD-ROM XA Mode 2 Form 1 and Form 2; Photo CD Writing Methods Disc-at-Once, Track-at-Once, Multisession, Packet Writing Disc Diameters 12 cm, 8 cm Interface ATAPI specification SFF-8020i/8080 Data Transfer Rate (Average) Read:...
- Page 10 CR-4802TU Specifications Supported Disc Formats CD-ROM Mode 1 and 2; CD-DA; CD-i; Video CD; CD-Extra (CD Plus) CD-ROM XA Mode 2 Form 1 and Form 2; Photo CD (read), CD UDF Writing Methods Disc-at-Once, Track-at-Once, Multisession, Packet Writing Disc Diameters 12 cm, 8 cm Interface USB Interface...
- Page 11 CR-4803TE Specifications Supported disc formats CD-ROM Mode 1; CD-DA; CD-i; Video CD; CD-Extra (CD plus) CD-ROM XA Mode 2 Form 1 and Form 2; Photo CD Writing Methods Disc-at-Once, Track-at-Once, Multisession, Packet Writing Disc diameters 12 cm, 8 cm Interface ATAPI specification SFF-8020i/8080 Data transfer rate Read:(MAX)
- Page 12 CR-4804TE Specifications Supported disc formats CD-ROM Mode 1; CD-DA; CD-i; Video CD; CD-Extra (CD plus) CD-ROM XA Mode 2 Form 1 and Form 2; Photo CD Writing Methods Disc-at-Once, Track-at-Once, Multisession, Packet Writing Disc diameters 12 cm, 8 cm Interface ATAPI specification SFF-8020i/8080 Data transfer rate Read:(MAX)
- Page 14 Licenses and Trademarks: Product names mentioned in this manual are trademarks or registered trademarks of their respective companies and are hereby acknowledged. Informa- tion in this manual is subject to change without notice and does not represent a commitment on the part of the vendor.
