Gas Griddle Toaster
M o d e l C T 6
I N S T A L L A T I O N A N D O P E R A T I O N M A N U A L
228009-6

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Cobra CT6 and is the answer not in the manual?

Questions and answers

Related Manuals for Cobra Cobra CT6

Summary of Contents for Cobra Cobra CT6

  • Page 1 Gas Griddle Toaster M o d e l C T 6 I N S T A L L A T I O N A N D O P E R A T I O N M A N U A L 228009-6...
  • Page 2 The reproduction or copying of any part of this manual by any means whatsoever is strictly forbidden unless authorized previously in writing by the manufacturer. In line with policy to continually develop and improve its products, Moffat Ltd. reserves the right to change the specifications and design without prior notice.

  • Page 3: Table Of Contents

    Contents CT6 Gas Griddle Toaster Part 1 Introduction ..................2 Part 2 Specifications ................. 3 Part 3 Installation ..................5 Part 4 Operation ..................8 Part 5 Cleaning and Maintenance ............9 Part 6 Gas Conversion ................11 Part 7 Replacement Parts List ..............

  • Page 4: Part 1 Introduction

    Part 1 Introduction We are confident that you will be delighted with your Cobra Series Gas Griddle Toaster and it will become a most valued appliance in your commercial kitchen. To ensure you receive the utmost benefit from your new Cobra Series Appliance, there are two important things you can do.

  • Page 5: Part 2 Specifications

    Part 2 Specifications Model Covered in this Specification - - All Other Markets: Gas Griddle Toaster. LP Gas LP Gas / Butane (Propane) General Input Rating 42 MJ/hr 42 MJ/hr (N.H.G.C.) A commercial heavy-duty gas fired griddle toaster, Supply Pressure 2.75 - 4.50 kPa 2.75 - 4.50 kPa having two tubular burners heating a griddle plate...
  • Page 6 Part 2 Specifications Dimensions Gas Griddle Toaster (600mm)

  • Page 7: Part 3 Installation

    Part 3 Installation Installation Requirements  Check that the following parts have been supplied with the appliance: NOTE: It is most important that this appliance is installed Enamelled Crumb Tray correctly and that operation is correct before use. Toasting Rack Installation shall comply with local, gas, health and Toasting Rack Tray (St/Steel) safety requirements.
  • Page 8 Part 3 Installation Assembly NOTE: The gas pressure regulator provided with this appliance is convertible between Natural Gas and This model is delivered completely assembled. LPG as per the ‘Gas Conversion Section’ in this Ensure that the legs are securely attached. manual.
  • Page 9 Part 3 Installation Commissioning The following commissioning checks must be carried out before the Gas Griddle Toaster handed over for use, to ensure that the unit operates correctly and the operator(s) understand the correct operating procedure. 1. Before leaving the new installation; a.

  • Page 10: Part 4 Operation

    Part 4 Operation Operation Guide Lighting the Pilot Burners 1. Depress the gas control knob and rotate anti- clockwise to the ‘PILOT’ position. AUTI ON 2. Whilst holding the control knob depressed, press  This appliance is for professional use and the piezo ignition button adjacent to the gas is only to be used by qualified people.

  • Page 11: Cleaning And Maintenance

    Part 5 Cleaning and Maintenance General 1. Clean the griddle with a scraper tool to remove any food debris. 2. Always ensure that the scraper tool blades are AUTI ON changed regularly to ensure that the scraper tool works efficiently and prevents damage to Always turn off the gas at the main gas the griddle plate surface.

  • Page 12: Part 5 Cleaning And Maintenance

    Part 5 Cleaning and Maintenance Griddle Plate Periodic Maintenance NOTE: NOTE: In order to prevent the forming of rust on the griddle All maintenance operations should only be carried plate, ensure that all detergent and cleaning out by a qualified service person. material has been entirely removed after each cleaning process.

  • Page 13: Part 6 Gas Conversion

    Part 6 Gas Conversion Gas Conversion Procedure 3. Re-connect the following:-  Gas supply tube to pilot burner.  AUTI ON Tighten gas supply tube at gas control end.  Refit piezo igniter. Ensure that the unit is isolated from the gas ...
  • Page 14 Part 6 Gas Conversion Gas Regulator NOTE: The gas regulator supplied is convertible between Natural Gas and LP Gas, but it’s outlet pressure is fixed ex-factory and is NOT to be adjusted. - NAT Gas / LPG / Butane Only. NOTE, Pin rotated for Natural Gas NOTE, Pin rotated...

  • Page 15: Gas Specifications

    Part 6 Gas Conversion Gas Specifications - Australia: Nat Gas LP Gas (Propane) Main Burner Injectors Ø 2.10mm Ø 1.30mm Pilot Burner Injectors 0.35 0.23 Low Fire Adjustment 1 turn out (ccw) ½ turn out (ccw) Burner Operating Pressure (*) 1.0 kPa (*) 2.5 kPa (*) Main Burner Aeration Shutter...
  • Page 16 Part 6 Gas Conversion - All Other Markets: Natural Gas Town Gas (**) Main Burner Injectors Ø 2.10mm Ø 3.80mm Pilot Burner Injectors 0.35 0.60 Low Fire Adjustment 1 turn out (c.c.w.) 2 turns out (c.c.w.) Burner Operating Pressure (*) 1.0 kPa (*) 0.63 kPa (*) Main Burner Aeration Shutter...

  • Page 17: Part 7 Replacement Parts List

    Part 7 Replacement Parts List Replacement Parts List IMPORTANT: Only genuine qualified replacement parts should be used for the servicing and repair of this appliance. The instructions supplied with the parts should be followed when replacing components. For further information and servicing instructions, contact your nearest qualified service branch (contact details are as shown on the reverse of the front cover of this manual).
