Gas Griddle Toaster
M o d e l C T 6
I N S T A L L A T I O N A N D O P E R A T I O N M A N U A L
For use in GB & IE
228009-5

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CT6 and is the answer not in the manual?

Questions and answers

Related Manuals for Cobra CT6

Summary of Contents for Cobra CT6

  • Page 1 Gas Griddle Toaster M o d e l C T 6 I N S T A L L A T I O N A N D O P E R A T I O N M A N U A L For use in GB &...
  • Page 2 MANUFACTURED BY Moffat Limited Christchurch New Zealand INTERNATIONAL CONTACTS AUSTRALIA Moffat Pty Limited E.Mail: vsales@moffat.com.au Main Office: (tel): +61 (03) 9518 3888 (fax): +61 (03 9518 3833 Service: (tel): 1800 622 216 Spares: (tel): 1800 337 963 Customer Service: (tel): 1800 335 315 (fax): 1800 350 281 CANADA Serve Canada...

  • Page 3: Table Of Contents

    Contents CT6 Gas Griddle Toaster Part 1 Introduction ..................2 Part 2 Specifications .................. 3 Part 3 Installation ..................4 Part 4 Operation ..................7 Part 5 Cleaning and Maintenance ............8 Part 6 Gas Conversion ................10 Part 7...

  • Page 4: Part 1 Introduction

    Part 1 Introduction We are confident that you will be delighted with your Cobra Series Gas Griddle Toaster, and it will become a most valued appliance in your commercial kitchen. To ensure you receive the utmost benefit from your new Cobra Series Appliance, there are two important things you can do.

  • Page 5: Part 2 Specifications

    Part 2 Specifications Model Covered in this Specification - Gas Connection Gas Griddle Toaster. Gas supply connection point is located 130 mm from the right hand side of the appliance, 32 mm General from the rear and 655 mm from the floor and is entered from beneath the appliance.

  • Page 6: Part 3 Installation

    Location Cobra Series Gas Griddle Toasters are designed to provide years of satisfactory service and correct Installation must allow for a sufficient flow of installation is essential to achieve the best fresh air for the combustion air supply.
  • Page 7 ALL GAS FITTING MUST ONLY BE CARRIED OUT BY A QUALIFIED SERVICE PERSON. NOTE: A Manual Isolation Valve must be fitted to the 1. Cobra Series Gas Griddle Toasters do not require individual appliance supply line. an electrical connection, they function totally on the gas supply only.
  • Page 8 Part 3 Installation Commissioning The following commissioning checks must be carried out before the Gas Griddle Toaster handed over for use, to ensure that the unit operates correctly and the operator(s) understand the correct operating procedure. 1. Before leaving the new installation; a.

  • Page 9: Part 4 Operation

    5. ‘FULL’ flame can now be achieved by rotating the gas control knob anti-clockwise to the first 1. Cobra Gas Griddle Toasters have been stop. designed to provide simplicity of operation and 6. ‘LOW’ flame can be achieved by depressing 100% safety protection.

  • Page 10: Cleaning And Maintenance

    Part 5 Cleaning and Maintenance General 1. Clean the griddle with a scraper tool to remove any food debris. 2. Always ensure that the scraper tool blades are AUTI ON changed regularly to ensure that the scraper tool works efficiently and prevents damage to Always turn off the gas at the main gas the griddle plate surface.

  • Page 11: Part 5 Cleaning And Maintenance

    Part 5 Cleaning and Maintenance Griddle Plate Periodic Maintenance NOTE: NOTE: In order to prevent the forming of rust on the griddle All maintenance operations should only be carried plate, ensure that all detergent and cleaning out by a qualified service person. material has been entirely removed after each cleaning process.

  • Page 12: Part 6 Gas Conversion

    Part 6 Gas Conversion Pilot Burners Gas Conversion Procedure 1. Disconnect pilot supply and thermocouple tubes from the gas control valve. AUTI ON 2. Undo the 2 screws securing the pilot assembly to Ensure that the unit is isolated from the gas the griddle toaster main frame.
  • Page 13 Part 6 Gas Conversion Gas Regulator NOTE: The regulator supplied is convertible between Natural Gas and LPG, but it’s outlet pressure is fixed ex-factory and is NOT to be adjusted. NOTE, Pin rotated for Natural Gas NOTE, Pin rotated for LPG 1.

  • Page 14: Gas Specifications

    Part 6 Gas Conversion Gas Specifications - Non UK Only: Natural Gas LP Gas (Propane) Main Burner Injectors Ø 2.10 mm Ø 1.30 mm Pilot Burner Injectors 0.35 0.23 Low Fire Adjustment 1 turn out (ccw) ½ turn out (ccw) Operating Pressure 1.0 kPa (*) 2.5 kPa (*)

  • Page 15: Part 7 Replacement Parts List

    Part 7 Replacement Parts List Replacement Parts List IMPORTANT: Only genuine qualified replacement parts should be used for the servicing and repair of this appliance. The instructions supplied with the parts should be followed when replacing components. For further information and servicing instructions, contact your nearest qualified service branch (contact details are as shown on the reverse of the front cover of this manual).
