INSTALLATION, OPERATION AND MAINTENANCE MANUAL
Please read carefully before proceeding with installation. Your failure to follow any attached instructions or
operating parameters may lead to the product's failure and possible damage to property.
Refer to enclosed warranty for operating parameters to ensure proper use with your water supply.
Watts Premier, Inc.
Phone: 800-752-5582
Manual #: 199334
System Tested and certified by NSF International against ANSI/NSF
Standard 53 for the reduction of claims specified on the performance
data sheet.
8716 W Ludlow Drive Suite #1
www.premierH2o.com
Warning
MODEL
Ultra-UV-R
Peoria, AZ 85381
Fax: 623-866-5666
Manual Date:8/06/05
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Premier Ultra-UV-R
Summary of Contents for Premier Ultra-UV-R
- Page 1 Standard 53 for the reduction of claims specified on the performance data sheet. Refer to enclosed warranty for operating parameters to ensure proper use with your water supply. Watts Premier, Inc. 8716 W Ludlow Drive Suite #1 Peoria, AZ 85381 Phone: 800-752-5582 www.premierH2o.com...
-
Page 2: Table Of Contents
Thank you for your purchase of a UV-R system. With proper installation and maintenance, this system will provide you with high quality water for years to come. All of Watts Premier’s water enhancement products are rigorously tested by independent laboratories for safety and reliability. -
Page 3: Mainteance Record
Using the mounting hole on the bracket, mark the location for the mounting screws on the cabinet wall under the sink. Screw the (2) screws into the wall at the marked location. The Ultra-UV-R bracket is designed to be mounted without removing the screws. Hang the Ultra-UV-R-2 module on the screws using the mounting holes in the bracket. -
Page 4: Faucet Installation
A. Remove faucet kit from plastic bag and locate each of the following parts (as shown in Figure A) Note: Remove plastic tubing from faucet body before inserting long reach spout into faucet body. Figure A: Faucet tube connection Note: If using existing hole (sprayer or soap dispenser) go to Step G. -
Page 5: Adapt A Valve Installation
Step 3. Installation of Upgraded Adapta Valve #134007 For 3/8” Plumbing For ½” Plumbing Hot water supply Cold water supply line line Step 1 Turn off the cold water supply to the faucet by turning the angle stop valve off. Step 2 Attach the Adapta Valve as illustrated in the photo above. -
Page 6: Uv Lamp Replacement
Replacement filters for this and many other filtration systems can be purchased directly from Watts Premier. Ordering options include mail order, telephone ordering, and online filter replacement. Additionally, Watts Premier sells filtration and reverse osmosis systems suitable for almost any individual or commercial application. -
Page 7: Uv-R Diagrahm
Figure E: UV Tube Assembly & Exploded View It em P art # Des c ript ion It em P art # Des c ript ion 134008 Easy Tap Adapter Faucet Body 131017 Insert Brass 114" 116032 L/R Spout 131012 Sleeve Delrin 114" 137046 UV- Bracket 131002 Nut Brass 114"C 146001 #10-3/4"... -
Page 8: Preformance Data
Peoria, AZ 85381 – USA Performance Data Sheet for specific claims to NSF Std-53. CT-1, UC-1, UC-2 & Ultra-UV-R GENERAL USE CONDITIONS: 1: System to be used with municipal or well water sources treated and tested on regular basis to insure bacteriological safe quality. -
Page 9: Limited Warranty
For warranty service, call 1-800-752-5582 for a return authorization number. Then, ship your unit to our factory, freight and insurance prepaid, with proof of date of original purchase. Please include a note stating the problem. Premier will repair it, or replace it, and ship it back to you prepaid. - Page 10 Watts Premier, Inc. 8716 W Ludlow Drive Suite #1 Peoria, AZ 85381 Phone: 800-752-5582 www.premierH2o.com Fax: 623-866-5666...
