- Page 1 GE Consumer Home Services Training TECHNICAL SERVICE GUIDE Wizard Extra Large Capacity Washer MODEL SERIES: WPSE7003A0 WNCD2050A0 PUB # 31-9058 08/00...
- Page 2 If grounding wires, screws, straps, clips, nuts, or washers used to complete a path to ground are removed for service, they must be returned to their original position and properly fastened. GE Consumer Home Services Training Technical Service Guide Copyright © 2000 All rights reserved.
-
Page 3: Table Of Contents
Table of Contents Washer Nomenclature ..........2 Warranty Information . -
Page 4: Washer Nomenclature
Washer Nomenclature Model Number W P S E 7 0 0 3 A 0 W W Product Exterior Color W = GE Washer WW = White on White Model Engineering Revision P = Profile 0 = None Basket Size A = Year... -
Page 5: Warranty Information
Any part of the washer that fails due to a defect in materials or workmanship. During this One Year full one-year warranty , GE will also provide, free of charge , all labor and in-home service From the date of the to replace the defective part. -
Page 6: Installation Highlights
Installation Highlights Location • Washer must be installed on firm flooring. Concrete flooring is best, but wood base is sufficient providing floor support meets FHA 60 sq. in. (387.1 sq. cm) standards. • Washer should not be installed on rugs or exposed to the weather. - Page 7 Notes – 5 –...
-
Page 8: Operating Characteristics
Operating Characteristics Basic Washer Operation fault is triggered, the display will show a 1, the PerfecTemp LED will flash, and the The typical washer cycle progresses as washer will be in the PAUSE mode. follows: If the user changes the water temperature •... - Page 9 Other Functions Unsuccessful samples of the electrical current readings could be an indicator of a 2nd Rinse pump motor that is blocked, or a standpipe The extra rinse selection provides a complete that is too high, and water in the tub. second rinse to the cycle.
-
Page 10: Cycle Chart
Factory Presets Agitation time at fast speed Spin Time Rinse Wash Spray Agitation Extra Rinse Spray Soil Level LED (Time Rinse Time (incl. Wash Rinse Final Extended Rinse Features & Cycles WPSE7003A WNCD2050A Load in Minutes) Temp Speed Stain Wash Heavy Normal Light... -
Page 11: Electronic Controls
The L3 washer offers the convenience of starting your wash loads with easy one-touch cycles. One simple selection automatically sets your Load Size, Soil Level, Wash/Rinse Temperature, and Wash/Spin Speed. Then just press Start. Model WPSE7003A0 Model WNCD2050 GEA00539 Description... - Page 12 Error Code Table Field Service Mode The Field Service Mode is entered by simul- taneously pressing and holding the Whites/ Hot and the Start/Pause buttons for 3 seconds. As soon as the test cycle is en- tered, the DSSD displays the letters Fd (Field t s i Service Diagnostics).
- Page 13 Field Service Mode Entrance/Exit To Enter Field Service To Exit Field Service Diagnostic Mode Diagnostic Mode Field Service Begin Mode Simultaneously 30-Min. Loss of press and hold the Press the Start Whites Stop Timeout Power to button. from Start Control buttons for 3 seconds.
-
Page 14: Control Settings
Control Settings Easy One-Touch Cycles The L3 washer offers the convenience of starting your wash loads with easy one-touch cycles. Make one simple selection, and your Load Size, Soil Level, Wash/Rinse Termperature, and Wash/Spin Speed are automatically set. Then all you have to do is press Start. OUCH Quick Start Guide •... -
Page 15: One Touch Selections
One Touch Selections PRESS... AUTOMATICALLY SELECTS... THEN PRESS... For heavy to lightly soiled cottons, household linens, work and play clothes. For heavy to lightly soiled cottons, household linens, work and play clothes. For non-colorfast cottons and blends, and items that are labeled cold wash by the fabric manufacturer. - Page 16 About Clothes Care Cycles Stain Wash (on some models) STAIN WASH (on some models) For heavily soiled or stained items. Adds an extra agitation and soak at the beginning of For heavily soiled or stained items. Adds an extra agitation and soak at the beginning the wash cycle.
- Page 17 DRAIN & SPIN Drain & Spin DRAIN & SPIN any cycle at any time. Drain & Spin any cycle at any time. Automatic DRAIN & SPIN setting: CUSTOM 1 and CUSTOM 2 (on some models) Custom 1 and Custom 2 (on some models) Set up your favorite combination of settings and save them here for one-touch recall.
- Page 18 About Control Features START/PAUSE Start/Pause After you have selected a new cycle, press once to start the cycle. • After you have selected a new cycle, press once to start the cycle. Press twice to select the last cycle used and start the washer. •...
- Page 19 About Cycle Options BEEPER Beeper Alerts you when the cycle is complete. Alerts you when the cycle is complete. You can turn off the end-of-cycle beeper by pressing this pad. You can turn off the end-of-cycle beeper by pressing this pad. Second Rinse 2ND RINSE Adds a second rinse to any cycle.
- Page 20 About Washer Features Liquid Bleach Dispenser Liquid Bleach Dispenser The dispenser dilutes liquid chlorine bleach before it reaches into your wash The dispenser dilutes liquid chlorine bleach before it reaches into your wash load. load. Check clothing care labels for special instructions. 1.
-
Page 21: Removal And Replacement
Removal and Replacement Remove Electronic Control Board Remove 4 Screws 1. Remove 4 screws from the top of the backsplash and rotate the top forward. 2. Remove 4 harness connections. Remove and retain the model selector harness plug for reassembly. 3. -
Page 22: Schematics And Strip Circuits
Schematics and Strip Circuits WARNING POWER MUST BE DISCONNECTED BEFORE SERVICING THE APPLIANCE. RED W/WHITE (L1) DARK BLUE WHITE YELLOW 1 3 56 89 1112 PURPLE W/WHITE YELLOW W/RED BLACK ORANGE PURPLE YELLOW WHITE DARK BLUE BLACK YELLOW WHITE WHITE W/RED (N) GEA00524 Note: The numbers in the drawing of the PCB above corre- SPOT... -
Page 23: Lid Switch
Strip Circuits Lid Switch Main Power and Drain Pump Motor CN 1 RED W/WHITE ORANGE RED W/BLACK CN 2 YELLOW W/RED PUMP CN 2 BLACK SWITCH GEA00527 GEA00529 Water Level Switch Water Temp Sensor WHITE BLACK WATER DARK BLUE TEMP CN 2 SENSOR WATER... -
Page 24: Troubleshooting Flowcharts
Troubleshooting Flowcharts Component Operation Troubleshooting Initiate field service mode by Start pressing and holding Whites buttons. DSSD output displays Colors Press button 3 times. DSSD output displays . Hot water valve is activated. Colors Press button. DSSD output displays . Cold water valve is activated. - Page 25 Error Code Troubleshooting Washer Note: If control is operating, it House fuse, Proper voltage to is likely that the control is not breaker, or wall Washer. faulty. Record all the error outlet problem. codes and recheck error message at the component level.
- Page 26 Spin Speed Troubleshooting Note: Rather than just spinning up right away, the control enters this sequence after pumpdown to reduce suds lock. The pump stops, then starts for a few seconds, then it begins to spin up. – 24 –...
- Page 27 No Fill Troubleshooting No Fill Turn ON hot Is water and cold water. turned ON? Press START. Is machine timed out? (With extremely low ("1" displays, PerfecTemp pressure, press + PAUSE lights flash) START again.) Are screens Check for clogged clogged? screens and replace.
- Page 28 Washer Pauses During Agitation Troubleshooting Washer pauses during agitation. Adds extra Is Stain Wash agitation and soak option chosen? to wash level. It gives 3 minutes of agitation, Washer will adjust 12 minutes of soak, Is Super Load size water level option chosen? then cycle selected.
-
Page 29: Troubleshooting Guide
Troubleshooting Guide PERFECTEMP Possible Causes What To Do PerfecTemp wash The washer is in a cold rinse cycle • This is normal. The PerfecTemp feature is designed not temperature is incorrect to activate during a cold rinse cycle so that the coldest water available is used. -
Page 30: Troubleshooting
Troubleshooting PERFORMANCE (cont.) Possible Causes What To Do Pilling • While this is not caused by the washer, you can slow the Result of normal wear on poly-cotton blends and pilling process by washing garments inside out. fuzzy fabrics Snags, holes, tears, rips Pins, snaps, hooks, sharp •... - Page 31 Troubleshooting WATER Possible Causes What To Do Too many suds • Switch to a lower sudsing detergent brand and follow Type of detergent instructions on package. Very soft water • Try less detergent. • Measure your detergent carefully. Use less soap if you Too much detergent have soft water, a smaller load, or a lightly soiled load.
- Page 32 Troubleshooting NOISE Possible Causes What To Do Washer is noisy Washer is uneven • To level the front of the washer, adjust the front leveling legs by rotating the individual leg in the proper direction for up or down. To level back of washer, lift back of machine 4s (11 cm) and set down.
-
Page 33: Illustrated Parts Breakdown
Illustrated Parts Breakdown Parts List Exploded parts views and list for Model WPSE7003A0. Refer to microfiche for specific model information. – 31 –... - Page 34 Exploded parts views and list for Model WPSE7003A0. Refer to microfiche for specific model information. – 32 –...
-
Page 35: Parts List
Parts List Exploded parts views and list for Model WPSE7003A0. Refer to microfiche for specific model information. – 33 –... - Page 36 Exploded parts views and list for Model WPSE7003A0. Refer to microfiche for specific model information. – 34 –...
- Page 37 Parts List Exploded parts views and list for Model WPSE7003A0. Refer to microfiche for specific model information. – 35 –...
- Page 38 Parts List Exploded parts views and list for Model WPSE7003A0. Refer to microfiche for specific model information. – 36 –...
-
Page 39: Quiz
Quiz 5. The Wizard Washer control checks the 1. How do you get into the Field Service Mode for thermistor during operation. If the sensor is the Wizard Washer? shorted or open, the control will complete the a) Press & hold “Start/Pause” button for 3 cycle and sets an “E2”... - Page 40 – 38 –...
