IBM 15” Service Manual SERVICE MANUAL 15” LCD Monitor IBM L150 / L150P THESE DOCUMENTS ARE FOR REPAIR SERVICE INFORMATION ONLY. EVERY REASONABLE EFFORT HAS BEEN MADE TO ENSURE THE ACCURACY OF THIS MANUAL; WE CANNOT GUARANTEE THE ACCURACY OF THIS INFORMATION AFTER THE DATE OF PUBLICATION AND DISCLAIMS RE LIABILITY FOR CHANGES, ERRORS OR OMISSIONS.
Operating Temp: 5°C to 35°C Environmental Storage Temp.: -20°C to 60°C Considerations Operating Humidity : 20% to 80% 6.3 kg , 13.89 lbs for L150 Weight (N. W.) Packaged 6.8 kg , 14.99 lbs for L150P 4.8 kg , 10.58 lbs for L150 Unpackaged 5.3 kg , 11.69 lbs for L150P...
IBM 15” Service Manual 2. LCD MONITOR DESCRIPTION The LCD MONITOR will contain an main board, an inverter/power board, keypad board and internal adapter which house the flat panel control logic, brightness control logic and DDC. The power board will provide AC to DC Inverter voltage to drive the backlight of panel and the main board chips each voltage.
IBM 15” Service Manual 3. OPERATING INSTRUCTIONS 3.1 GENERAL INSTRUCTIONS Press the power button to turn the monitor on or off. The other control buttons are located at front panel of the monitor. By changing these settings, the picture can be adjusted to your personal preferences.
Page 8
IBM 15” Service Manual Contrast Adjusts over all screen brightness. Brightness Adjusts difference between light and dark areas. Horizontal Position Moves image left or right. Vertical Position Moves image up or down. Automatic Optimizes image(size, position, phase and clock). Clock Clock Adjusts picture Clock.
IBM 15” Service Manual 4. Input/Output Specification 4.1 Input Signal Connector PIN NO. DESCRIPTION PI N NO. DESCRIPTION Green Detect Cable Blue Ground DDC-Serial Data Ground H-Sync R-Ground V-Sync G-Ground DDC-Serial Clock B-Ground VGA connector layout 4.2 Factory Preset Display Modes:...
Page 10
IBM 15” Service Manual Addressability Vt. Frequency (Hz) 640 x 350 640 x 480 640 x 480 640 x 480 640 x 480 720 x 400 800 x 600 800 x 600 800 x 600 1024 x 768 1024 x 768...
IBM 15” Service Manual 4.3 Power Supply Requirements 4.3.1 Input Requirements PARAMETER RANGE CONDITION Input Voltage 100 to 240VAC RMS Universal input full range Input Frequency 60Hz @ 100VAC to 50Hz @ 240VAC Input voltage 100 VAC RMS ; 60 Hertz.
IBM 15” Service Manual 4.4.4 Parameter guide line for CCFL Inverter INVERTER MAX BRINGTHNESS (Vadj:5.0v), LOAD=120KΩX4 (ROOM TEMPERATURE 25℃ ±4℃) ITEM SYMBOL MIN. TYP. MAX. UNIT REMARK Input voltage 10.8 13.2 Input current 2250 2500 FOR 4 LOAD Output Current...
Page 19
IBM 15” Service Manual 1) MCU initialize. 2) Is the eeprom blank ? 3) Program the eeprom by default values. 4) Get the PWM value of brightness from eeprom. 5) Is the power key pressed ? 6) Clear all global flags.
IBM 15” Service Manual 6. Schematic 6.1 Main Board CN101 RX2-IN RX2- A_GND RX2+IN RX2+ SGND Connect two grounds at one single point only. SCL_IN R510 1/16W DDCCLK SDA_IN R511 1/16W DDCDAT A_VSYNC RX1-IN AGND RX1- RX1+IN RX1+...
Page 24
IBM 15” Service Manual 3.3V_DDDS FB201 FB202 600 OHM C223 600 OHM C225 +3.3V C222 C224 22uF/16V 0.1uF/16V 22uF/16V 0.1uF/16V Close to respective power Pins +2.5V +3.3V C201 C202 C203 C204 C205 C206 C207 C208 C209 C210 +3.3V 3.3V_SDDS C221 22uF/16V 0.1uF/16V...
IBM 15” Service Manual 8. Maintainability 8.1 Equipments and Tools Requirement 1、Voltmeter. 2.、Oscilloscope. 3、Pattern Generator. 4、DDC Tool with a IBM Compatible Computer. 5、Alignment Tool. 6、LCD Color Analyzer. 7、Service Manual. 8、User Manual.
IBM 15” Service Manual 8.2 Trouble Shooting 8.2.1 Main Board 1.NO SCREEN APPEAR Check CN504 pin 10 = 2.5 V? Check Correspondent component. Check CN504 pin 8 = 3.3 V? Is there any shortage or cold solder? Check CN504 pin 4 = 5 V? Check Power Board.
Page 34
IBM 15” Service Manual 2.PANEL POWER CIRCUIT check R507 should have response Check the PPWR panel power relative circuit, Q501, Q502 from 0V to 3.3V In normal operation, when LED =green, R507 should =0 v, When we switch the power switch from...
Page 35
IBM 15” Service Manual 4.U203-DATA OUTPUT NG , no transition Measured DCLK DVS, DHS (pin 117,116 from U203 ) Is the waveform ok? Replace GM5115 /2115 DCLK around 40 MHz , DVS=60.09Hz , DHS (U203) or replace Main around 80 KHz ?(refer to input signal= board.
IBM 15” Service Manual 8.2.2 Power/Inverter Board 1.) No power Check to CN102 pin2 = 5V Check Interface board Check AC line volt 120V or 220V Change F901 , check BD901,Q903,IC901 Check the voltage of C905(+) Check bridge rectified circuit cFailure point...
Page 37
IBM 15” Service Manual 2.) W / LED , No Backlight Check C201(+) =12V Change F902 Check D201/Q209/Q210 Check ON/OFF signal Check Interface board Check U201 pin9=12V Change Q201 or Q202 Check the pin1 of U201 have sawtooth wave Change U201 Check D201(-) have the output of square wave at short time.
IBM 15” Service Manual 8.2.3 KeyPad Board OSD is unstable or not working Connect KeyPad Board Is KeyPad Board connecting normally ? Replace Button Switch Is Button Switch normally ? Replace KeyPad Board Is KeyPad Board Normally ? Check Main Board...
IBM 15” Service Manual 9. White-Balance, Luminance adjustment Approximately 30 minutes should be allowed for warm up before proceeding white balance adjustment. Before started adjust white balance ,please setting the Chroma-7120 MEM. channel 9 to 6500 color, MEM. Channel10to 7200 color, and MEM. channel 11 to 9300 color ( our 9300 parameter is x = 283 ±10, y = 297 ±10, Y = 190 ±10 cd/m...
IBM 15” Service Manual 4、Adjust the RED of color2 on factory window until chroma 7120 indicator reached the value R=100 5、adjust the GREEN of color2 on factory, until chroma 7120 indicator reached G=100 6、adjust the BLUE of color2 on factory, until chroma 7120 indicator reached B=100 7、repeat above procedure ( item 5,6,7) until chroma 7120 RGB value meet the...
Page 41
IBM 15” Service Manual 10.2. D-SUB Connector (Digital) 4D 51 0D 01 EA 71 1C 4F AF EE 00 FD 00 112 00 4D 4C 31 4C 31 Note: Byte 0C, 0D, 0E, 0F means Serial No. Byte 10, 11 means Manufacture Time. Byte...
IBM 15” Service Manual 11. BOM List Part List for L150 Level Location Number Specification Quantity Uni. ============================================================================ *** T560KHDHKII5N ============================================================================ *** CBPC560KHDI5 CONVERSION BOARD 1.00000 KEPC560KI3 KEY BOARD 1.00000 PWPC5216A1I1 POWER BOARD 1.00000 12L 404 1 RUBBER SCREW 4.00000...
Page 44
IBM 15” Service Manual Level Location Number Specification Quantity Uni. ============================================================================ *** PWPC5216A1I1 *** POWER BOARD ============================================================================ *** PWPC5216A1AI LCD POWER ASS'Y FOR AI 1.00000 PWPC5216A1SMT LCD POWER ASS'Y FOR SMT 1.00000 2 L904 73L 253 91 LS CHOKE BY LI SHIN 0.00000...
Page 45
IBM 15” Service Manual Level Location Number Specification Quantity Uni. ============================================================================ *** PWPC5216A1I1 *** POWER BOARD ============================================================================ *** 2 BD901 93L 50460 8 BRIDGE 2KBP06M 2A 400V 1.00000 2 D912 93L3006 1 S.B.DIODE 3A/60V IR/31DQ06 1.00000 2 D910 93L3010 1 S B D 31DQ10/IR 31DQ10/I.R...
Page 46
IBM 15” Service Manual Level Location Number Specification Quantity Uni. ============================================================================ *** AIC560KHDI5 *** CONVERSION BOARD AUTO INS. ============================================================================ *** 3 CN501 33L8019 40 CONNECTOR 40P 1.00000 3 CN502 33L8019 40 CONNECTOR 40P 1.00000 55L 23520 0.06000 3 U203 56L 562 25 GM2115 CG BY GENESIS 1.00000...
Page 56
IBM 15” Service Manual Part List for L150p Level Location Number Specification Quantity Uni. ============================================================================ *** T560KHDHKII5N ============================================================================ *** CBPC560KHCI5 CONVERSION BOARD 1.00000 KEPC560KI3 KEY BOARD 1.00000 PWPC5216A1I1 POWER BOARD 1.00000 12L 404 1 RUBBER SCREW 4.00000 15L5908 1 AC SOCKET BRACKET 1.00000...
Page 57
IBM 15” Service Manual Level Location Number Specification Quantity Uni. ============================================================================ *** T560KHDHKII5N ============================================================================ *** 89L1748LAA 3 DVI CABLE 1.00000 89L402A18NVLM POWER CORD 1.00000 M1L 140 10 47 SCREW M4X10 4.00000 M1L 325 4120 SCREW M2.5X4 4.00000 M1L 330 4128 SCREW M3X4 1.00000...
Page 58
IBM 15” Service Manual Level Location Number Specification Quantity Uni. ============================================================================ *** PWPC5216A1I1 *** POWER BOARD ============================================================================ *** PWPC5216A1AI LCD POWER ASS'Y FOR AI 1.00000 PWPC5216A1SMT LCD POWER ASS'Y FOR SMT 1.00000 2 L904 73L 253 91 LS CHOKE BY LI SHIN 0.00000...
Page 59
IBM 15” Service Manual Level Location Number Specification Quantity Uni. ============================================================================ *** PWPC5216A1I1 *** POWER BOARD ============================================================================ *** 2 BD901 93L 50460 8 BRIDGE 2KBP06M 2A 400V 1.00000 2 D912 93L3006 1 S.B.DIODE 3A/60V IR/31DQ06 1.00000 2 D910 93L3010 1 S B D 31DQ10/IR 31DQ10/I.R...
