- Page 1 USERS GUIDE ASP-CTH Composite / S-Video to HDMI Converter Manual Number: 110901...
-
Page 2: Safety Instructions
Power outlet: To prevent electric shock, be sure the electrical plug used on the product power cord matches the electrical outlet used to supply power to the Aurora product. Use only the power adapter and power connection cables designed for this unit. -
Page 3: Table Of Contents
User Guide TABLE OF CONTENTS PACKAGE CONTENTS ......................1 INTRODUCTION ........................2 About............................... 2 Features ............................2 Front & Rear Panel .......................... 3 QUICK START ........................... 4 APPENDIX 1 Troubleshooting ..................... 5 APPENDIX 2 Technical Specifications................6 APPENDIX 3 Warranty ......................7... -
Page 4: Package Contents
User Guide PACKAGE CONTENTS Please make sure the following items are included within your package. Contact your dealer if any items are missing or damaged. ASP-CTH x 1 Power Adapter x 1 Note: Go to www.auroramultimedia.com for latest manual and firmware... -
Page 5: Introduction
The unit is selectable for 720p 60Hz or 1080p 60Hz at a touch of a button. The composite video and s-video are also selectable via button and the ASP-CTH will retain the settings even if it loses power. Legacy equipment can now be more easily integrated into today’s digital systems with the ASP-CTH. It works great with HDMI splitters, extenders, matrixes, and switchers. -
Page 6: Front & Rear Panel
User Guide Front & Rear Panel ①. S-VIDEO: S-Video Input ②. CVBS/L/R: Composite and Audio ③. DC 5V: Connect to 5V Supply ④. Power Indicator ⑤. CVBS/S-VIDEO: Button Source Select ⑥. 720/1080P: Button Resolution Select ⑦. AUDIO: 3.5mm Stereo Output ⑧. -
Page 7: Quick Start
User Guide QUICK START • Unpack the ASP-CTH from its carton making certain everything is included. • Connect the video, s-video and audio accordingly. • Connect the HDMI from the ASP-CTH to the display device. • Connect the 5v power connection. -
Page 8: Appendix 1
User Guide APPENDIX 1 Troubleshooting Problem Solution a. Check that the power plug is properly inserted into a functioning power outlet. b. Make certain source is on. 1. No Video Signal. c. Make certain s-video or video is selected accordingly. d. -
Page 9: Appendix 2 Technical Specifications
User Guide APPENDIX 2 Technical Specifications Front Panel Yellow RCA Phono Composite 4 Pin Mini Din S-Video Stereo Audio L/R White & Red Phono Rear Panel Type A [19-pin female] HDMI Output Strereo Audio Output 3.5mm TRS 720p/1080p Button Momentary CVSB / S-Video Button Momentary Power LED... -
Page 10: Appendix 3 Warranty
Limited 3 Year Warranty Aurora Multimedia Corp. (“Manufacturer”) warrants that this product is free of defects in both materials and workmanship for a period of 3 years as defined herein for parts and labor from date of purchase. This Limited Warranty covers products purchased in the year of 2009 and after. - Page 11 User Guide This product warranty extends to the original purchaser only and will be null and void upon any assignment or Aurora Multimedia Corp. 205 Commercial Court Morganville, NJ 07751 Phone: 732-591-5800 Fax: 732-591-6801...
