Instructions for use Italiano, 1 English, 19 Français, 37 Deutsch, 55 Nederland, 73 Espanol, 91 Portuges, 109 MWI 14IX MICROWAVE OVEN COMBINED WITH GRILL Index General Description of the oven Description of the control panel Building-in Important safety warnings Technical data...
Chapter general Description of the oven A Grill heating element B Control panel C Microwave outlet cover D Turntable spindle E Inside of door F Wire rack G Turntable H Turntable support Description of the control panel Combined microwave + grill: Set the knob at turn off and you will hear a buzzing signal.
280 cm2 large for this purpose. 2. Remove the 2 screws (x) from the fastening bar under the microwave oven. 3. Fit the fastening bar (B) at the correct position in the recess. Make sure that there is the same amount of free space at each side of the fastening bar.
4. Open the lid of the smoke discharge (C) fully (if fitted) 5. Slide the appliance into the recess. Keep sliding it until the front of the oven (G) is resting against the cupboard and the holes (D) under the oven are aligned with the holes (E) in the fastening bar (B).
13)Before using this oven, check to be certain that the utensil and containers chosen are suitable for microwave oven use (see the section on "Glassware and Similar Items"). 14)The temperature of the door or the outer surface may be high when the appliance is operating.
and closes properly. 4) Place the support (H) in the centre of the circular groove and fix the turntable (G) to it. The spindle (D) should be inserted in the corresponding groove in the centre of the turntable. 5) After the installation has been performed, the power supply cable and the power socket must be easy to access.
How to get the best results from your oven What do I want to do? • Keep food warm • Defrost • Soften chocolate & icing • Melt butter and soften cheese • Heat pastry goods • Cook stew, chicken breasts •...
6) The lower the temperature at which a foodstuff is placed in a microwave oven, the longer the cooking time required. Food having a room temperature will cook more quickly than food having a refrigerator temperature.
Using the controls and setting the modes Microwave-only function This function is suitable for: • Keeping food hot • Defrosting • Heating • Cooking stew, white meats, fruit, vegetables, rice, soup and fish • To brown the foods, to bake pastry and fruit Turning the oven on using only microwave function...
Page 10
Further information, including on other performance tests according to Regulation 60705, is given in the table on page 2. Using the microwave only function to re-heating Heating food in a microwave oven is much quicker and energy efficient than traditional methods. •...
Page 11
follow the cooking times listed with great caution; remember that under certain conditions the timings given must be lengthened • Frozen foods must be defrosted before the heating process begins. The lower the food’s initial temperature, the longer the time needed for heating.
The advantage of preparing a risotto dish in a microwave oven lies in the fact that you do not have to stir the rice constantly (two or three times is enough).
Page 13
Cooking times Type Power level Quantity Fish • Filleted 300 gr • Slices 300 gr • Whole 500 gr • Whole 250 gr • Cut-up fish 400 gr • Crayfish 500 gr Greens and vegetables • Asparagus 500 gr • Artichokes 300 gr •...
Combined microwave + grill function This function is suitable for: • Quick preparation of roasts, poultry, skewered meat and potatoes. page 33 • Au gratin dishes (e.g., lasagne, vegetables au gratin, macaroni) page 33 Turning the oven on with the microwave + grill function Put the food in a receptacle made for microwave cooking...
Page 15
Using the combined microwave + grill function to cook This setting is ideal for all those dishes which have to be “au gratin” or must be given a certain colour. You must keep the following in mind. • Do not spunkle seasonings in general (use only 1/2 cup of water to keep meat tender).
Grill-only function This function is suitable for: • All types of traditional grilling (e.g., chops, hamburgers, frankfurters, toast, etc.) Turning the oven on with the grill-only function Pre-heat the grill as follows: Turn the thermostat knob to the Set the reheating time desired by turning the timer knob in a clockwise direction.
Care and cleaning Cleaning Always switch off at the power socket, disconnect the plug and wait for the appliance to cool down, before any cleaning and maintenance is carried out. The internal cavity of your oven is covered with a special non-stick finish to which splashes and food particles do not stick, making cleaning particularly simple.
Maintenance Before calling Service for assistance, check through the following list, there may be nothing wrong: PROBLEM The appliance does not work Condensation on the work surface, inside the oven or around the door. Sparks inside the oven The food does not heat or cook properly The food burns The food does not cook evenly NOTE: The oven may be used safely even if the light...
