Page 1: Ifs Poe302-Ex User Manual
IFS POE302-EX User Manual P/N 1072690 • REV A • ISS 23OCT13... - Page 2 Copyright © 2013 United Technologies Corporation Interlogix is part of UTC Climate Controls & Security, a unit of United Technologies Corporation. All rights reserved. Trademarks and The IFS POE302-EX name and logo are trademarks of United Technologies. patents Other trade names used in this document may be trademarks or registered trademarks of the manufacturers or vendors of the respective products.
-
Page 3: Table Of Contents
IFS POE302-EX User Manual TABLE OF CONTENTS I FS POE302-EX USER MANUAL ..................1 I NTRODUCTION ......................4 1 .1 Package Contents ..........................4 1 .2 Key Features............................4 1 .3 Technical Specification ........................5 H ARDWARE DESCRIPTION ...................7 2 .1 Product Outlook ...........................7 2 .2 Ports Connection ..........................8 2 .3 LED Definition: .............................8... -
Page 4: Introduction
IFS POE302-EX User Manual Introduction 1.1 Package Contents Thank you for purchasing the IFS POE302-EX IEEE 802.3at Power over Gigabit Ethernet Extender, your Power over Gigabit Ethernet Extender package contains the following contents: Check the contents of your package for following parts: IEEE 802.3at Power over Gigabit Ethernet Extender x1... -
Page 5: Technical Specification
IFS POE302-EX User Manual 1.3 Technical Specification Model POE302-EX Interfaces 1 x 10/100/1000Base-T Ethernet with IEEE 802.3at / 802.3af PoE LAN IN “Data + DC” in Auto MDI/MDI-X, Auto-negotiation RJ-45 connector 1 x 10/100/1000Base-T Ethernet with IEEE 802.3at / 802.3af PoE LAN OUT “Data + DC”... - Page 6 IFS POE302-EX User Manual Environment Temperature: -10 ~ 60 Degree C Operating Relative Humidity: 5 ~ 95% (non-condensing) Temperature: -40 ~ 85 Degree C Storage Relative Humidity: 5 ~ 95% (non-condensing) Distance will often be shorter due to power delivery voltage-drop on the wire. The maximum distances will...
-
Page 7: Hardware Description
IFS POE302-EX User Manual Hardware Description 2.1 Product Outlook... -
Page 8: Ports Connection
IFS POE302-EX User Manual 2.2 Ports Connection Connect the PoE IN port from following 802.3at / 802.3af PSE device through a CAT-5/5e/6 UTP cable: • PoE injector IN Port • PoE Injector Hub • PoE Ethernet Switch • Previous POE302-EX Connect the PoE OUT port to following 802.3at / 802.3af PD device through a... -
Page 9: Hardware Installation
IFS POE302-EX User Manual Hardware Installation This product provides three different running speeds – 10Mbps, 100Mbps and 1000Mbps in the same device and automatically distinguishes the speed of incoming connection. This section describes the hardware features of POE302-EX. Before connecting any network device to the POE302-EX, read this chapter carefully. -
Page 10: Connect Poe302-Ex To The Powered Device (Pd)
IFS POE302-EX User Manual 3.3 Connect POE302-EX to the Powered Device (PD) Step 3: Connect the additional Cat.5/5e/6 cable that will be used to connect to the remote Powered Device (PD) to the “OUT” port of POE302-EX. Step 4: The "OUT" port is also the power injectors which transmit DC Voltage to the Cat.5/5e/6 cable and transfer data and power simultaneously between the PSE and PD. - Page 11 IFS POE302-EX User Manual Per POE302-EX will take 3.2 Watts maximum for the system itself, please check the total power consumption of your IEEE 802.3at / 802.3af PD and the POE302-EX before you make the daisy-chain connection. If the overall power consumption is overloaded, the local PSE could shutdown the whole power system.
- Page 12 IFS POE302-EX User Manual 3.5 Optional - DIN-Rail Mounting There are two DIN-Rail holes on the left side of the POE302-EX that allows the converter can be easily installed with DIN-Rail mounting. The IFS optional DIN-Rail mounting Kit – RKE-DIN can be order separately. When need to replace the wall mount application with DIN-Rail application on the POE302-EX, please refer to following figures to screw the DIN-Rail on the converter.
- Page 13 IFS POE302-EX User Manual Step 3: Check the DIN-Rail is tightly on the track. You must use the screws supplied with the mounting brackets. Damage caused to the parts by using incorrect screws would invalidate your warranty.
-
Page 14: Contacting Technical Support
IFS POE302-EX User Manual Contacting Technical Support Contact technical support if you encounter any difficulties during this installation. Please make sure you have the requested diagnostic or log files ready before you contact us by phone or go to www.interlogix.com/customer-support.
