- Page 1 POC252 Series User's Manual P/N 1073047 • REV A • ISS 27AUG15...
- Page 2 Copyright © 2015 United Technologies Corporation Interlogix is part of UTC Building & Industrial Systems, Inc. a unit of United Technologies Corporation. All rights reserved. Trademarks and The POC252 name and logo are trademarks of United Technologies. patents Other trade names used in this document may be trademarks or registered trademarks of the manufacturers or vendors of the respective products.
-
Page 3: Table Of Contents
TABLE OF CONTENTS INTRODUCTION ..............................4 1.1............................4 ACKAGE ONTENTS 1.2..................5 NTRODUCING EACH OWER OVER THERNET 1.3............................6 RODUCT EATURES 1.4..........................7 RODUCT PECIFICATIONS 1.4.1. POC252-1CXP-1T Specifications ......................7 1.4.2. POC252-1CX-1P Specifications ......................9 HARDWARE DESCRIPTION ........................... 11 2.1. -
Page 4: Introduction
1. INTRODUCTION Thank you for purchasing IFS PoE over Coaxial the POC252-1CXP and POC252-1CX, consisting of the POC252-1CXP and POC252-1CX. The descriptions of the two models are as follows: POC252 Power over Coax POC252-1CXP-1T 1-Port 10/100TX PoE PD + 1-Port Coax Long Reach PoE Injector POC252-1CX-1P 1-Port 10/100TX PoE PSE + 1-Port Coax Long Reach PoE Extender (Camera End) “POC252-1CXP/POC252-1CX”... -
Page 5: Introducing Long Reach Power Over Ethernet
1.2. Introducing Long Reach Power over Ethernet IFS POC252 series PoE over Coaxial Extender is designed to extend IP Ethernet transmission and inject power over an existing coaxial cable or for distance up to 1000m (3280ft) to PoE IP camera, PoE Wireless AP and any 802.3at device that complies with powered device (PD). -
Page 6: Product Features
1.3. Product Features Physical Port 1 coaxial interface for output power and 1 10/100BASE-TX port supports IEEE 802.3at PoE PD (POC252-1CXP) 1 power jack supports 56V DC Power input (POC252-1CXP) 1 coaxial interface for input and 110/100BASE-TX port supports IEEE 802.3at PoE PSE (POC252-1CX) Power over Ethernet ... -
Page 7: Product Specifications
1.4. Product Specifications 1.4.1. POC252-1CXP-1T Specifications Model POC252-1CXP-1T / Long Reach PoE Injector Hardware Specifications 1 x 10/100BASE-TX RJ45 Copper Auto-negotiation/ Auto-MDI/MDI-X IEEE 802.3at PoE PD (Powered Device) Power over Input Range: 56V DC Ethernet Supports both Mid-Span and End-Span PSE Ethernet Data Rate 100/100Mbps... - Page 8 4 x LEDs LED Indicators POC LNK PoE In-use LNK/ACT ESD Protection 2KV DC EFT Protection Enclosure Metal case Installation Wall mount or DIN rail with optional kit Dimensions (W x D x H) 94 x 70 x 26 mm Weight 200g ...
-
Page 9: Poc252-1Cx-1P Specifications
1.4.2. POC252-1CX-1P Specifications POC252-1CX-1P / Long Reach PoE Extender Model Hardware Specifications 10/100BASE-TX RJ45 Copper Auto-negotiation/ Auto-MDI/MDI-X PoE Standard IEEE 802.3at PoE PSE (Power Source Equipment) PoE Output 48~56V DC, 600mA max. PoE Budget Up to 25 watts PoE Mode End-span, RJ45 Pin 1/2(+), 3/6(-) Ethernet Interface... - Page 10 4 x LEDs LED Indicators PoE In-use LRP LNK LNK/ACT ESD Protection 2KV DC Enclosure Metal case Installation Wall mount or DIN rail with optional kit Dimensions (W x D x H) 94 x 70 x 26 mm Weight 375g ...
-
Page 11: Hardware Description
2. HARDWARE DESCRIPTION 2.1. POC252-1CXP (Injector) 2.1.1. POC252-1CXP Physical Dimensions POC252-1CXP-1T dimensions (W x D x H): 94 x 70.3 x 39.2 mm 2.1.2. POC252-1CXP-1T Front Panel / Rear Panel Figure 2-1 Figure 2-2 show the front / rear panels of the POC252-1CXP Long Reach PoE over Coaxial Injector. -
Page 12: Poc252-1Cxp Led Indicators
2.1.3. POC252-1CXP LED Indicators System Color Function Power ON: PoE+ / PoE power input from RJ45 PoE PD port Power ON: 48~56V DC power input from DC jack Green Power Off LRP Coaxial Interface Color Function Lit: indicates that the coaxial link is established. Green Off: indicates that the coaxial link is down. -
Page 13: Poc252-1Cx
2.2. POC252-1CX (Extender) 2.2.1. POC252-1CX-1P Physical Dimensions POC252-1CX-1P dimensions (W x D x H): 94 x 70.3 x 39.2 mm... -
Page 14: Poc252-1Cx Front Panel / Rear Panel
2.2.2. POC252-1CX Front Panel / Rear Panel Figure 2-3 and Figure 2-4 show the front / rear panels of the POC252-1CX Long Reach PoE over Coaxial Extender. Figure 2-3: POC252-1CX Front Panel Figure 2-4: POC252-1CX Rear Panel 2.2.3. POC252-1CX LED Indicators ... -
Page 15: Installation
3. INSTALLATION This section describes the functionalities of the POC252-1CXP/POC252-1CX components and guides you to how to install it on the desktop. Basic knowledge of networking is expected. Please read this chapter completely before continuing. 3.1. Installation Precautions As the POC252-1CXP is power over coaxial injector, it only can work with IFS power over coaxial extender, the POC252-1CX. -
Page 16: Power Options
3.2. Power options: POC252-1CXP Injector There are two ways to power the POC252-Injector Powered via PoE Powered via DC adapter POC252-1CX The POC252-Extender must be powered by the POC252-Injector or POE Switch POC252-1CX must be powered by the POC252-1CXP or POC2502 POC switch over the coaxial cable. -
Page 17: Applications Of Poc252-Kit With Coaxial Cable
3.3. Applications of POC252-KIT with coaxial cable Type 1 – One POC252-1CXP with PoE power input and one POC252-1CX with PoE power output The POC252-Injector is powered via IEEE 802.3at PoE. An IEEE 802.3at compliant PoE PD will automatically be powered by the POC252-Extender via UTP. POC252 Injector POC252 Extender Functions... - Page 18 Type 2 – One POC252-1CXP with 56V power adapter and one POC252-1CX with PoE power output The POC252-Injector is powered via the external power adapter. The IEEE 802.3at compliant PoE PD will automatically be powered by the POC252-Extender via UTP. LRP Injector LRP Extender POC252-1CXP...
- Page 19 Type 2 – One POC252-1CXP with 56V power adapter and two POC252-1CX with PoE power output for two cameras.
-
Page 20: Optional - Din-Rail Mounting
3.4. Optional - DIN-Rail Mounting There are two DIN-Rail holes on the left side of the POC252-1CXP/POC252-1CX that allow the device can be easily installed with DIN-Rail mounting. The PLANET optional DIN-Rail mounting Kit – RKE-DIN can be order separately. When need to replace the wall mount application with DIN-Rail application on the POC252-1CXP/POC252-1CX, please refer to following figures to screw the DIN-Rail on the converter. -
Page 21: Troubleshooting
4. TROUBLESHOOTING This chapter contains information to help you solve issues. If the POC252-1CXP/POC252-1CX is not functioning properly, make sure the POC252-1CXP/POC252-1CX is set up according to instructions in this manual. The maximum distance support by POC252-1CXP/POC252-1CX Solution: The POC252-1CXP/POC252-1CX supports maximum distance of 1km (Data plus Power transmission). -
Page 22: Appendix A: Networking Connection
APPENDIX A: NETWORKING CONNECTION A.1 Switch’s RJ45 Pin Assignments 10/100Mbps, 10/100BASE-TX RJ45 Connector pin assignment Contact MDI-X Media Dependant Media Dependant Interface Interface-Cross Tx + (transmit) Rx + (receive) Positive (VCC+) Tx - (transmit) Rx - (receive) Positive (VCC+) Rx + (receive) Tx + (transmit) Negative (VCC-) 4, 5... - Page 23 SIDE 2 Figure A-1: Straight-through and Crossover Cable Please make sure your connected cables are with the same pin assignment and color as the above picture before deploying the cables into your network. Information on FAQ: WWW.Interlogix.com Customer Support: WWW.Interlogix.com/support...
