Installation and Operating Instructions for
VENT FREE REMOTE CONTROLLED SYSTEM
Model: SCVFR18L, SCVFR18N, SCVFR24L, SCVFR24N, VFMR24NG
FAILURE TO FOLLOW THESE INSTRUCTIONS CAREFULLY AND WITHOUT ERROR, OR FAILURE TO HEED ANY
AND ALL WARNINGS IN THESE INSTRUCTIONS CAN RESULT IN AN EXPLOSION, FIRE OR THE PRODUCTION
OF CARBON MONOXIDE GAS WHICH CAN CAUSE PROPERTY DAMAGE, BODILY INJURY OR DEATH.
Sure Heat
Manufacturing
1861 West Oak Parkway
Marietta, GA 30062
Tel: (770) 422-8008
Fax: (770) 424-3842
NOTE: THIS UNIT CANNOT BE CONVERTED TO DIFFERENT GAS TYPES.
WARNING: If the information in this manual is not followed exactly, a fire or explosion may
- Do not store or use gasoline or other flammable vapors or liquids in the vicinity of this or any
other appliance.
- WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance
• Do not touch any electrical switch.
• Do not touch any telephone in your building.
• Immediately call your gas supplier from a neighbor's telephone.
• Follow the gas suppliers instructions.
• If you cannot reach your gas supplier, call the fire department.
- Installation and service must be performed by a qualified installer, service agency or the
gas supplier.
This is an unvented gas-fired heater. It uses air (oxygen) from the room in which it is
installed. Provisions for adequate combustion and ventilation air must be provided.
THIS APPLIANCE MAY BE INSTALLED IN AN AFTERMARKET MANUFACTURED (MOBILE) HOME, WHERE NOT PROHIBITED
BY STATE OR LOCAL CODES. INSTALL ONLY IN A SOLID-FUEL BURNING FIREPLACE OR APPROVED VENTLESS FIREBOX
ENCLOSURE (MANUFACTURED UNVENTED FIREPLACE) AS SPECIFIED BY THESE INSTRUCTIONS.
* AFTERMARKET: COMPLETION OF SALE, NOT FOR PURPOSE OF RESALE, FROM THE MANUFACTURER.
THIS APPLIANCE IS ONLY FOR USE WITH THE TYPE OF GAS INDICATED ON THE RATING LABEL ATTACHED TO THE
APPLIANCE. THIS APPLIANCE IS NOT CONVERTIBLE FOR USE WITH OTHER GASES. THIS UNIT IS CONSTRUCTED IN
ACCORDANCE WITH ANSI Z21.11.2B-2004.
SURE HEAT
NATURAL & L.P. GAS
result causing property damage, personal injury or loss of life.
DANGER:
Advertisement
Table of Contents
Related Manuals for Sure Heat SCVFR18L
Summary of Contents for Sure Heat SCVFR18L
- Page 1 Installation and Operating Instructions for NATURAL & L.P. GAS VENT FREE REMOTE CONTROLLED SYSTEM Model: SCVFR18L, SCVFR18N, SCVFR24L, SCVFR24N, VFMR24NG DANGER: FAILURE TO FOLLOW THESE INSTRUCTIONS CAREFULLY AND WITHOUT ERROR, OR FAILURE TO HEED ANY AND ALL WARNINGS IN THESE INSTRUCTIONS CAN RESULT IN AN EXPLOSION, FIRE OR THE PRODUCTION OF CARBON MONOXIDE GAS WHICH CAN CAUSE PROPERTY DAMAGE, BODILY INJURY OR DEATH.
- Page 2 IMPORTANT INFORMATION This appliance is designed as an unvented room heater when installed in a non-combustible fireplace with the flue damper closed. This appliance may be used as a heating appliance only if unvented heating appliances are permitted by local state and city codes.
-
Page 3: Fireplace Preparation
Unpack the appliance carefully and inspect for missing parts or damages that may have occurred during shipping. If any part of the appliance is missing or damaged, please notify Sure Heat Manufacturing at (800) 229-8647. An incomplete or damaged appliance may be hazardous. DO NOT INSTALL A DAMAGED OR INCOMPLETE APPLIANCE. -
Page 4: Fireplace Clearances
GAS PIPING AND GAS PRESSURE REQUIREMENTS Check the type of gas that is supplied to your fireplace. Use only the gas type indicated on the heater's rating plate. If the gas listed on the plate is not your type of gas supply, DO NOT INSTALL THE SYSTEM. Contact your dealer for the proper model. - Page 5 BURNER SYSTEM LOCATION The Burner system should be located towards the back and centred in the combustion chamber of the fireplace. The burner system should be centred from left to right, with about an inch of space on either side. CONNECTING GAS SUPPLY TO BURNER PAN AND LOG GRATE PLACEMENT 1.
-
Page 6: Log Placement
LOG PLACEMENT 1. The largest log is placed in the front part of the grate with the notches facing upwards (see Figure 1 and Figure 2). NOTE: The front log should be as far to the front of the grate as possible. 2. -
Page 7: For Your Safety Read Before Lighting
FINAL CHECKPOINTS BEFORE OPERATION . Before setting the logs in place, turn the gas on and check each joint in the gas line with a soap and water solution for leaks. Bubbles indicate leaks. Repair any leaks and recheck before proceeding. DANGER: DO NOT USE OPEN FLAME TO TEST FOR LEAKS! 2. -
Page 8: Remote Control
REMOTE CONTROL THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: TECHNICAL DATA TECHNICAL DATA (1) This device may not cause harmful interference, AND Remote Control (2) This device must accept any interference received, including Supply voltage: interference that may cause undesired operation. -
Page 9: Match Lighting Instructions
LIGHTING INSTRUCTIONS 1. STOP! Read the safety information label found on the unit. 2. Make sure the switch (Not the pilot control knob) is turned to "OFF". (See Figure 4) 3. Turn off all electrical power to the unit. 4. Push in pilot control knob slightly and turn clockwise to "OFF". 5. -
Page 10: Maintenance Of The System
MAINTENANCE OF THE SYSTEM - Under normal use, this unit will require only limited cleaning. - To clean the unit, first turn the pilot control knob to "OFF" and allow the system to cool down. - The logs and grate can get very hot. Handle only when the system is cool. - Keep the control valve, logs and burner area clean by vacuuming or brushing at least twice a year. -
Page 11: Troubleshooting
TROUBLESHOOTING Problem Cause Corrective Action • No Pilot ignition - pilot valve not on - turn valve to "PILOT" and depress, keep match near pilot burner until ignition. - gas line not clear - inspect supply lines for tube kinks or obstructions. -
Page 12: Warranty
It is agreed that any repair or replacement is the exclusive remedy from Sure Heat Manufacturing. In no case shall Sure Heat be liable for any consequential damage or breach of this or any other warranty expressed or implied whatsoever.
