DIGITAL TTL POWER ZOOM FLASH
INSTRUCTION MANUAL
Type N
Thank you for purchasing a Nissin product
Before using this flash unit, please read this instruction manual and refer
your camera owner's manual carefully to get a better understanding of
proper operation to enjoy flash photography.
Nissin MG8000 Extreme type Nikon is designed for Nikon digital SLR, with the
latest TTL flash control system, and features Nissin's original rotating color
display, easily guiding its operations.
It works automatically with Nikon i-TTL auto-flash systems.
Please note that MG8000 Extreme type N is not usable with other branded
cameras for TTL operation.
UNIQUE FUNCTION
1
The color display automatically rotates
to allow for easy operation in both the
horizontal and vertical positions.
Nissin Japan Ltd., Tokyo
http://www.nissin-japan.com
Nissin Marketing Ltd., Hong Kong
http://www.nissindigital.com
Design and Specifications are subject to change without prior notice.
SIMPLE OPERATION
When attaching MG8000 to the camera, the basic flash exposure operation is
fully controlled by the camera. It is the same idea as when you use the built-in
camera flash but placed on the hotshoe.
SPECIAL FEATURES
MG8000 is featuring exetreme high heat resistance to obtain more than 1000
times continuum emitting with full power without overheating problems.
Assorting with Nissin Power Pack PS300 is suggested, enables blazing fast
and maximizes the extreme performance.
In additon, MG8000 provides many advanced flash functions, such as Wireless
TTL off camera flash technology, high speed shutter synchronization, frequent
repeat-flash system, External Av priority setting, etc. are supported.
Compatible cameras
Please refer Nissin's compatibility chart shown in its home page for details and
recent updates: http://www.nissin-japan.com or http://www.nissindigital.com
MG0412N REV. 1.2
2
Advertisement
Table of Contents
Related Manuals for Nissin MG8000 Extreme
Summary of Contents for Nissin MG8000 Extreme
- Page 1 SPECIAL FEATURES Nissin MG8000 Extreme type Nikon is designed for Nikon digital SLR, with the MG8000 is featuring exetreme high heat resistance to obtain more than 1000 latest TTL flash control system, and features Nissin’s original rotating color times continuum emitting with full power without overheating problems.
-
Page 2: Safety Instructions
Nomenclature SAFETY INSTRUCTIONS These safety instructions refer to important information on how to use this product safely and properly. Please read the following instructions before using X-terminal the product. Flash head/ USB service port Wireless transmitter WARNING External service This sign refers the danger or serious damage. Sub-Flash The flash unit contains high voltage electric parts. -
Page 3: Basic Operation
BASIC OPERATION MG8000 has energy saving double power off function. Inserting batteries Usable batteries - Alkaline batteries, Lithium batteries, NiMH batteries. The power is automatically turned off (to stand-by mode), in about 30 seconds of idle use on the camera or after the last setting is made. To Remove the battery magazine and insert save the battery energy, you can select the display-off setting from the 4 x size AA batteries as shown in the... - Page 4 The flash illumination coverage of MG8000 responds to the lens focal length of TTL Flash Exposure Value Compensation 24mm to 105mm (full size format / film camera standard). With the latest TTL flash control system, the flash power level is always automatically controlled by the camera for the most appropriate exposure.
- Page 5 Manual Zoom Setting Manual Power Opertion The reflector position of MG8000 can be set manually. To get an illumination area different from the picture frame either wider or The mode to be set on the camera: narrower field, manual zoom setting makes sense. When using MG8000 with Flash Power can be adjusted manually.
- Page 6 Setting of Master and Slave flash: Av. Mode Operation Setting Master flash: The master flash to be set is one unit only. The mode to be set on the camera: Place the master flash on the camera and switch it on, and set to Manual The flash light is automatically controlled by the photo sensor built-in the flash function mode or set to the camera’s built-in flash on.
-
Page 7: Wireless Remote Flash Mode
Slave flash sensor is provided behind the front panel of MG8000 at the A = Group A Power Ratio at M mode name of Nissin DIGITAL. The sensor’s sensing angle to respond to the B = Group B (1/1, 1/2, 1/4, 1/8, 1/16, incoming light is about 100 degree. -
Page 8: Custom Settings
A variety of custom settings enable you to customize your MG8000. Firmware A firmware upgrade service is available for the Switch Lock MG8000 Extreme, which provides a USB service From 6 icons, select Custom setting mode and set terminal (By local service/ local dealer) to upload the latest software. -
Page 9: Other Features
MG8000 has the latest high heat power pack with Flash times Flash Interval resistance system which can achieve up to Nissin Power Pack PS 300 (at full power) MG8000 latest 1000 times continuous flash at full power. 1-200 3 seconds... - Page 10 Wireless Master mode Off-camera shoe cord (Optional) Wireless Remote mode MG8000 can be used together with Nissin SC-01 (Off Camera Shoe Slave flash function at external auto-exposure Cord). The cord provides a TTL hot shoe at main body. Slave to digital pre-flash system...
