Using the self-cleaning oven.
The oven door must be closed and all controls set correctly for the cycle to work properly.
Before a Clean Cycle
We recommend venting your kitchen
with an open window or using a
ventilation fan or hood during the first
self-clean cycle.
Remove the shelves, broiler pan, broiler
grid, probe, all cookware and any
aluminum foil from the oven.
The oven shelves and convection roasting
Wipe up heavy soil on the oven
bottom.
rack can be self-cleaned, but they will
darken, lose their luster and become
hard to slide.
Soil on the front frame of the range and
outside the gasket on the door will need
to be cleaned by hand. Clean these areas
with hot water, soap-filled steel-wool pads
or cleansers such a Soft Scrub®
with clean water and dry.
How to Set the Oven for Cleaning
Touch the SELF CLEAN pad.
Using the number pads, enter the
desired clean time, if a time other
than 4 hours, 30 minutes is needed.
Clean cycle time is normally 4 hours, 30
minutes. You can change the clean time
to any time between 3 hours and 5 hours,
depending on how dirty your oven is.
Touch the START pad.
The door locks automatically. The display
will show the clean time remaining. It will
not be possible to open the oven door
until the temperature drops below the
lock temperature and the LOCKED DOOR
light goes off.
Do not clean the gasket. The fiberglass
material of the oven door gasket cannot
withstand abrasion. It is essential for the
gasket to remain intact. If you notice it
becoming worn or frayed, replace it.
Wipe up any heavy spillovers on the oven
bottom.
Make sure the oven light bulb cover is in
place and the oven light is off.
IMPORTANT: The health of some birds is
extremely sensitive to the fumes given off
during the self-cleaning cycle of any
range. Move birds to another well
ventilated room.
. Rinse well
When the LOCKED DOOR light is off, open
the door.
The oven shuts off automatically when
the clean cycle is complete.
The words LOCK DOOR will flash and
the oven control will signal if you set
the clean cycle and forget to close the
oven door.
To stop a clean cycle, touch the
CLEAR/OFF pad. When the LOCKED
DOOR light goes off indicating the
oven has cooled below the locking
temperature, open the door.

Cleaning the glass cooktop.

Clean the glass surface with cleaning cream before you use the cooktop for the first time. Also, clean
the glass surface after each use. This helps protect the top and makes clean-up easier.
To clean the cooktop seal around the edge of the glass, let a wet cloth rest on it for a few minutes, then wipe clean.
Use a mild detergent if needed.
Do not use a knife or any sharp object on the seal because it will cut or damage it.
Normal Cleaning
Use only a recommended cleaning cream,
such as Cerama Brite or another cooktop
cleaning cream, on the glass cooktop.
To maintain and protect the surface of
your new glass cooktop follow these steps.
Before you use the cooktop for the
first time, clean it with cleaning
cream. This helps protect the top
and makes clean-up easier.
For Heavy, Burned-On Soil...
Allow the cooktop to cool.
Apply a few drops of the cleaning
cream to the (cool) soiled area.
Using a damp paper towel, rub the
cream into the burned-on area. As
with any burned-on spill, this may
require some effort.
Carefully scrape soil with razor
scraper. Hold scraper at a 30˚ angle
against the glass cooktop.
Be sure to use a new sharp razor scraper. Do not
use a dull or nicked blade.
Special Care
Be sure to use a new sharp razor scraper. Do not
use a dull or nicked blade.
Sugary spillovers (such as jellies, fudge,
candy syrups) or melted plastics can
cause pitting of the surface of your
cooktop (not covered by the warranty)
unless the spill is removed while still hot.
Using a razor scraper will not
Special care should be taken when
damage the surface if the 30˚ angle
is maintained.
removing hot substances.
Turn off all surface units affected by
the spillover. Remove hot pans.
Wearing an oven mitt, hold the razor
scraper at a 30˚ angle to the cooktop.
Scrape the hot spill to a cool area
outside the surface unit.
Clean the surface with the cleaning
cream after each use.
Rub a few drops (less is better) of the
cleaning cream onto soiled area
using a damp paper towel. Buff with
a dry paper towel until all soil and
cream are removed.
If any soil remains, repeat the steps
listed above. For additional
protection, after all soil has been
removed, polish the entire surface
with the cleaning cream.
Buff with a dry paper towel.
To order more cream and/or scrapers for
cleaning your glass cooktop, please call
our toll-free number:
National Parts Center . . . . . . . . .800-626-2002
Cleaner . . . . . . . . . . . . . . . . . . . . . .# WX10X300
Scraper . . . . . . . . . . . . . . . . . . . . .# WX5X1614
Cream & scraper kit . . . . . . . . .# WB64X5027
With the spill in a cool area, use a dry
paper towel to remove any excess.
Any spillover remaining should be
left until the surface of the cooktop
has cooled. Do not continue to use
the soiled surface unit until all of the
spillover has been removed. Follow
the steps under Heavy Burned-On Soil
to continue the cleaning process.
NOTE: If pots with a thin overlay of aluminum,
copper or enamel are allowed to boil dry, the
overlay may bond with the glass cooktop and
leave a black discoloration. This should be
removed immediately before heating again
or the discoloration may be permanent.
