BH Fitness P360 Treadmill
P360 Folding Treadmill
OWNER'S MANUAL
ASSEMBLY OPERATION
MAINTENANCE
WARRANTY
PARTS ORDERING
CAUTION:
Exercise of a strenuous nature, as is customarily done on this equipment, should not be
undertaken without first consulting a physician. No specific health claims are made or implied as they
relate to the equipment.
I MPORTANT:
Read all instructions carefully before using this product. Retain this owner's
manual for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P360 and is the answer not in the manual?

Questions and answers

Summary of Contents for BH FITNESS P360

  • Page 1 BH Fitness P360 Treadmill P360 Folding Treadmill OWNER’S MANUAL ASSEMBLY OPERATION MAINTENANCE WARRANTY PARTS ORDERING CAUTION: Exercise of a strenuous nature, as is customarily done on this equipment, should not be undertaken without first consulting a physician. No specific health claims are made or implied as they relate to the equipment.
  • Page 2: Table Of Contents

    Attachment - D - Training…......5 Assembly Instructions…………………..9 Installation…………………….......14 Treadmill Operations……………....17 Additional Maintenance…………….....20 Storage……………………......21 Troubleshooting……..……………………….22 Exploded View ……….........23 Parts List …………………......24 Warranty……..………………………....29 P360 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.bhnorthamerica.com • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 3: Attachment - A- Safety

    We assume no responsibility for personal injury or property damage sustained by or through the use of this product. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE P360 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.bhnorthamerica.com • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 4 25. Use suitable clothing and footwear. Make sure all laces/cords are tied correctly. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE P360 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.bhnorthamerica.com • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 5: Attachment - B - Treadmill Lubrication

    0.5~4.0 Miles/day lubricate every 1 year excessive wear and tear. 4.0~7.0 Miles/day lubricate every 6 months 7.0~10.0 Miles/day lubricate every 3 months P360 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.bhnorthamerica.com • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 6: Attachment - Ctarget Heart Rate

    With all Heart Rate Control treadmill, you may use the heart rate monitor feature without using the Heart Rate Control program. P360 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.bhnorthamerica.com • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 7: Attachment - D - Training

    As your fitness level improves, the training threshold should be raised. Working through your program and gradually increasing the overload factor is important. P360 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.bhnorthamerica.com • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 8: Heart Rate

    (b) the pulse count is to approximate your BPM rate at the time you are exercising. Since heart rate slows as you recover, a longer count isn’t as accurate. P360 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.bhnorthamerica.com • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 9 Most people manage with half minute to one minute rest periods P360 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.bhnorthamerica.com • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 10 Pull your feet toward your groin area as far as possible. Hold for 15 counts, then relax. Repeat 3 times. Stretches: Quadriceps and hip muscles. P360 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.bhnorthamerica.com • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 11 ASSEMBLY If you are missing parts or require information on how to operate this product please call 949-206-0330. P360 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.bhnorthamerica.com • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 12: Assembly Instructions

    (139) Combination box wrench; (126) Main cable; (120) Safety key; (98) Lock Washers; (123) Bottle of lubricant; (69) Screw M6*20; (140) Washers. Fig.0 P360 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.bhnorthamerica.com • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 13 Slide left upright onto main frame, attach the upright post to frame with bolt(22) and lock washer(98) using the #5 allen wrench. P360 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.bhnorthamerica.com • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 14 (69) and washers (140) on to the foot rest. Perform the same assembly operation with the other foot rest. P360 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.bhnorthamerica.com • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 15 ATTENTION: Pneumatic cylinder (21) is pressurized so avoid hitting or knocking it or it could become damaged. Once damaged, the operation of the treadmill may be impaired Fig.8 P360 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.bhnorthamerica.com • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 16: Installation

    10. Do not use outdoors 11. Do not use this treadmill in areas with large concentrations of aerosol or pure oxygen sources. P360 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.bhnorthamerica.com • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 17 Regardless of whether your goal is to become more fit, or In addition to sugars and fats, the P360 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.bhnorthamerica.com • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 18 You will see for ITS PRODUCTS WITHOUT PRIOR yourself that it is worth staying in NOTICE. shape with BH. P360 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.bhnorthamerica.com • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 19: Treadmill Operations

    PROGRAM MODE.- indicating that the machine is READY This monitor programs to be used. P360 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.bhnorthamerica.com • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 20 (between 0 to 12), press the independently of all other functions. SPEED▲▼ keys to select the speed Each time that you set switch (L) to P360 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.bhnorthamerica.com • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 21 LEVEL MUST BE AT ITS LOWEST ITS PRODUCTS WITHOUT PRIOR SETTING BEFORE ATTEMPTING NOTICE. TO PUT THE TREADMILL INTO THE FOLDED POSITION. P360 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.bhnorthamerica.com • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 22: Additional Maintenance

    It is strongly recommended that you purchase such a cleaning compound. P360 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.bhnorthamerica.com • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 23: Storage

    (56) rest on the floor. To prevent accidents DO NOT move the treadmill across uneven floors Fig.10. Fig.9 Fig.10 P360 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.bhnorthamerica.com • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 24: Troubleshooting

    Connect the VR and AC wires well.Press the Elevation fault small button on the bottom controller for 3 seconds. Possible motor overload. Lubricate the belt. P360 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.bhnorthamerica.com • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 25: Exploded View

    EXPLODED VIEW (Use key numbers to reference the part numbers.) P360 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.bhnorthamerica.com • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 26: Parts List

    REAR ROLLER GAS SHOCK BOLT ALLEN KEY MOVING WHEEL END CAP SPRING SAFETY KEY PLATE BOLT M10*20 11 SLEEVE CONNECT TUBE P360 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.bhnorthamerica.com • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 27 MOVING WHEEL END CAP GRIP FOAM END CAP FLAT WASHER MOVING WHEEL SAFETY KEY BALL FLAT WASHER DRIVING BELT MOTOR COVER SCREW P360 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.bhnorthamerica.com • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 28 SCREW M5*40 10 SCREW M6*16 SCREW ST4.2*35 SCREW ST4.2*12 SCREW ST2.9*8 SCREW ST4.0*15 SCREW FLAT WASHER SPRING WASHER FLAT WASHER P360 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.bhnorthamerica.com • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 29 EARTH WIRE SAFETY KEY COMPONENT SPEED SENSOR SWITCH BOARD SILICON POWER SWICH BREAKER POWER CABLE RUNNING BOARD DC MOTOR INCLINE MOTOR P360 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.bhnorthamerica.com • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 30 、 WRENCH/SCREW DRIVER S=13 14 15 MONITOR OVERLAY , , BOX WRENCH S=5 13 14 FLAT WASHER SENSOR CONNECT BOARD P360 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.bhnorthamerica.com • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 31: Warranty

    LABOR – 1 Year BH Fitness shall cover the labor cost for the repair of the device for a period of one year from the date of original purchase, as long as the device remains in the possession of the original owner.
  • Page 32: Bh Fitness • 20155 Ellipse • Foothill Ranch • Ca

    The warranty does not cover normal wear BH FITNESS expressly disclaims all other warranties, express or implied, including but not limited to all warranties of fitness for a particular purpose or of merchantability. This warranty gives you specific legal rights and your rights may vary from state to state.
