Sunn Fun 4 Foot Centers Oval Pool 420869-14 Assembly Instructions Manual

4 foot centers
Hide thumbs

Advertisement

Quick Links

Download this manual
Sun n Fun
Pools
GENERAL
Installation of this above ground pool is not extremely hard
or confusing, but it is a big job. The secret to installing a
pool so that it will give you years of pleasure is to take the
time to follow instructions and do things right the first time.
Your pool warranty is void if these instructions are not
followed 100%. Read all instructions including accessories
such as filters, pumps, skimmers, decks, etc. prior to
starting. Before you start, check to see that you have the
correct number of parts. Use your parts list which is broken
down by carton. The manufacturer reserves the right to
revise, change, or modify construction of its pools.
NOTE: If a power drill is used during installation,
it should be a variable speed drill used on low
setting. Torque should not exceed 39 inch pounds.
FAILURE TO COMPLY COULD RESULT IN SCREWS STRIPPING OUT.
4 Foot
Centers
Phone: (732) 574-1500 • Fax: (732) 574-1551
www.sun-n-funpools.com • E-mail: info@sun-n-funpools.com
OVAL
POOL
ASSEMBLY
INSTRUCTIONS
DANGER
DO NOT DIVE OR JUMP
into your pool. Your pool is
approximately 4' deep. It is
not designed for diving
or jumping. If you dive or jump
into your pool you run the risk
of permanent injury or death.
Alert all visitors
out all warning
labels supplied.
ADULT SUPERVISION REQUIRED
Part# 420869-14
and family of
this and point

Advertisement

loading
Need help?

Need help?

Do you have a question about the 4 Foot Centers Oval Pool 420869-14 and is the answer not in the manual?

Questions and answers

Related Manuals for Sunn Fun 4 Foot Centers Oval Pool 420869-14

Summary of Contents for Sunn Fun 4 Foot Centers Oval Pool 420869-14

  • Page 1 Part# 420869-14 Sun n Fun OVAL Pools POOL 4 Foot Centers ASSEMBLY INSTRUCTIONS GENERAL Installation of this above ground pool is not extremely hard DANGER or confusing, but it is a big job. The secret to installing a DO NOT DIVE OR JUMP pool so that it will give you years of pleasure is to take the into your pool.

  • Page 2: Local Codes

    CONTRACT INSTALLATIONS The manufacturer is in no way affiliated with any professional pool installer. Therefore the manufacturer can assume no responsibility for errors in installation by the home owner or said professional installer. If you have your POOL installed by others, please supervise them to be sure they comply with the proper installation techniques shown. Their past expe- rience or short cuts may not cover the latest improvements in our POOLS.
  • Page 3 • During night time pool use, artificial lighting shall be used to illuminate all safety signs, ladders, steps, deck surfaces and walks. • The installer shall follow written instructions provided for operation of the circulation Screwdriver system. • Decks shell meet local codes and comply with ANSI/NSPI-8 1996 “Model Barrier Code for Residential Swimming Pools, Spas and Hot Tubs”...
  • Page 4 INSTALLATION • ASSEMBLY STEPS READ CAREFULLY BEFORE STARTING POOL ASSEMBLY CONSTRUCTION CLOSE-UPS Use the illustrations below as a guide for the assembly of your pool DELUXE POOLS 6” 6” PRINCETON DELMAR with Box Vertical QUANTUM ELAN • OMNI ZENITH • ST. CROIX LEXINGTON POOLS POOLS...
  • Page 5 INSTALLATION • ASSEMBLY STEPS READ CAREFULLY BEFORE STARTING POOL ASSEMBLY CONSTRUCTION CLOSE-UPS Use the illustrations below as a guide for the assembly of your pool 6” 7” XL POOLS EXTRUDED 9” POOLS ALUMINUM POOLS with Column with Box Vertical Vertical Fig.
  • Page 6 INSTALLATION • ASSEMBLY STEPS READ CAREFULLY BEFORE STARTING POOL ASSEMBLY CONSTRUCTION CLOSE-UPS Use the illustrations below as a guide for the assembly of your pool SUPREME POOLS 7” XL POOLS DELUXE POOLS with with Column Vertical with Column Vertical & Wrap Around Covers &...
  • Page 7 PREPARING THE GROUND Your pool must be installed on a solid level surface. After the pool location is selected drive the two end stakes "A" into the ground and mark the center line using string. Using the proper chart below (for your pool size) measure in along the center line from the end of the pool and drive your center stakes "B"...
  • Page 8 LEVELING THE GROUND Using the “CLEARANCE SIZE” chart on page 6, determine the clearance size for your pool. With the use of the leveling device shown and a shovel start leveling the ground, removing all grass and sharp objects such as sticks and stones. Level area to the lowest spot within the clearance radius.
  • Page 9 ASSEMBLING THE BOTTOM STRAPS Unpack and assemble the bottom straps with the buttress bottom plates and brackets as shown using all necessary hardware and tighten securely. Using the chart below determine the quantity of strap assemblies for your pool. The screws joining the straps must be inserted from the top to prevent the screw putting a hole in the liner once the pool is filled with water.
  • Page 10 BOTTOM RAIL AND STRAP LAYOUT Follow the instructions below to properly layout the rail and strap assemblies. BOTTOM RAIL QUANTITIES NEEDED: POOL SIZE 18x12 24x12 24x15 30x15 33x18 39x18 45x18 STRAP ASSEMBLIES 45½” RAILS LONG RAILS TRANSITION RAILS BOTTOM PLATES Transition Transition Rails Rails...
  • Page 11 CLOSING THE WALL 1/4" x 20 x 3/4" 3/8" TRUSS TRUSS HEAD HEAD SCREW 4 CLOSURE SCREW BARS WASHER INSIDE OF POOL View from 1/4" x 20 the top SERRATED FLANGE NUT WASHER 3/8 FLANGE DANGER YOU MUST ASSEMBLE THE Recessed POOL WALL DANGER...
  • Page 12 ASSEMBLE BUTTRESS Light Supports for the inside Heavy Supports with Pre-assemble a Cage Nut into the Top Plates Heavy Supports bottom strap assembly label “Outside Buttress” with label (Note: Cage nuts not needed on all pools). for outside bottom “Outside Buttress” Refer to Step #14 for instructions.
  • Page 13 PROTECT YOUR LINER way from top to bottom of wall. If the filter inlet and WALL INSIDE OF SKIMMER POOL VIEW RETURN FITTING SEAM outlet are not used, cover over the pre-scored areas on the inside of the pool wall with 1 layer of tape. VIEW FROM SKIMMER If your Pool Wall has the...
  • Page 14 THRU-THE-WALL SKIMMER IMPORTANT!! BEFORE CONTINUING WITH THIS STEP YOU MUST KNOW WHICH TYPE OF THROUGH THE WALL SKIMMER YOU WILL BE USING WITH YOUR POOL Your pool wall has cutouts to accomodate both standard size skimmers and deluxe wide mouth skimmers.
  • Page 15 EARTH MOUND Wall guard is optional. Tape wall guard (plastic sheeting) to pool wall 12" up from ground and smooth out on ground 12" from wall. This will OPTIONAL protect your pools metal parts from chemical reactions with WALL the soil used in the earth mound. GUARD Several commercial products can also be used in place of 8”...

  • Page 16: Liner Installation

    LINER INSTALLATION LINER CAUTION YOUR POOL IS DESIGNED TO PROVIDE AN AMPLE SAFETY MARGIN WHEN IT STANDS ON LEVEL GROUND. FOR THIS PURPOSE A SLOPE IN EXCESS OF 2 INCHES IN ANY DIRECTION WALL TO WALL IS CONSIDERED OFF LEVEL YOUR POOL WARRANTY ONLY APPLIES TO POOLS INSTALLED ON LEVEL GROUND AS DEFINED ABOVE.
  • Page 17 EZ HOOK LINER INSTALLATION ATTENTION: An 8 inch cove must be placed all around the inside of the pool 1. Clear all sticks and sharp objects from an area near the pool, OPTIONAL that is as large as the pool itself. Remove the liner from its WALL carton and unfold and open the liner.
  • Page 18 PRE-ASSEMBLY OF TOP PLATES* * NOTE: CAGE NUTS NOT NEEDED ON ALL POOLS - CHECK YOUR PACKING LIST Before the top plates are installed it is necessary to attach the cage nuts* in their appropriate locations as shown in the figures at right. Using a pliers, squeeze together the spring sides of the cage TOP PLATE...
  • Page 19 RAIL Insert two rails into a plate, in No. 12 x 1/2” the same manner and using the Sheet Metal Screw same spacing as you have done on the bottom rail and plate assembly. Push the rails PLASTIC TOP PLATE and plate assembly onto the plastic edging leaving the EDGING far end in the air.
  • Page 20 INSTALLING LEDGES AND PLACEMENT OF WARNING LABELS SCREW HOLE LOCATION GUIDE Refer to the "Construction Close-ups" at the 16x10 18x12 24x12 24x15 30x15 33x18 39x18 45x18 beginning of these Instructions as indicated below: OVAL OVAL OVAL OVAL OVAL OVAL OVAL OVAL B &...
  • Page 21 INSTALLING TOP COVERS FOLLOW THE INSTRUCTIONS BELOW FOR THE COVERS FOR YOUR PARTICULAR POOL 4", 6" & 7" DELUXE TOP COVERS These covers don’t require cage nuts or top cover screws. For pools with the new 1-piece deluxe top covers, simply snap the cover into place, aligning the tab on the bottom of the cover with the slot in the top plate of pool (fig.A only.)
  • Page 22 6" & 7" TWO-PIECE FULL CONTOURED COVER Slide inside cover (the cover which will be closest to the inside of the pool) into position and place outside cover onto top of inside cover aligning the holes together with cage nut attached to the top plate and secure using the 1/4”-20 x 3/4”...
  • Page 23 7" AND 9” TWO-PIECE WRAP AROUND COVER AND PEDESTAL Slide the inside cover (the cover which will be closest to the inside of the pool) into position and align the hole in the cover with the cage nut attached to the top plate. Secure using the 1/4”-20 x 3/4”...
  • Page 24 7" XL TWO-PIECE WRAP AROUND COVER AND PEDESTAL 1 - Insert the logo into the cover. 2 - Slide the outside cover into position and align the hole in the cover with the cage nut attached to the top plate. Secure using the 1/4”-20 x 3/4” screw provided. 3 - Insert the front of the top cover into the hole in the front of the outside cover.

  • Page 25: Warning Labels

    WARNING WARNING LABELS Four (4) danger labels have been provided for your safety. Apply these labels to the pool where they are easily visible to all persons using the pool. To do this, simply peel the backing off the label to expose the self stick back and firmly press to a conspicuous and plainly visible surface on the pool.
  • Page 26 SAFETY TIPS - RULES AND REGULATIONS This section is designed to acquaint you with some guidelines as to the safe operation and use of your pool. • Do not dive or jump into your pool. Your pool is approximately 48" or 52” deep. It is not designed for diving or jumping.

  • Page 27: Preventative Maintenance Tips

    PREVENTATIVE MAINTENANCE TIPS • Use clear lacquer or clear nail polish to cover screw heads. • Use clear lacquer or nail polish to cover any scratches on ledges or verticals to prevent rust and corrosion. • Use wax to protect the pool wall and frame from the elements. •...
  • Page 28 HOW TO KEEP WATER CLEAR AND HEALTHFUL Your health, and maximum enjoyment is assured by keeping your pool water in sparkling clear and sanitary clean condition. In order to obtain this condition certain equipment and chemicals available at your pool dealer are necessary. Equipment, such as a filter according to the size of your pool, skimmer and a vacuum cleaner will take care of removing suspended particles, leaves and oils from the water.
