Sun n Fun
Pools
GENERAL
Installation of this above ground pool is not extremely hard
or confusing, but it is a big job. The secret to installing a
pool so that it will give you years of pleasure is to take the
time to follow instructions and do things right the first time.
Your pool warranty is void if these instructions are not
followed 100%. Read all instructions including accessories
such as filters, pumps, skimmers, decks, etc. prior to
starting. Before you start, check to see that you have the
correct number of parts. Use your parts list which is broken
down by carton. The manufacturer reserves the right to
revise, change, or modify construction of its pools.
NOTE: If a power drill is used during installation,
it should be a variable speed drill used on low
setting. Torque should not exceed 39 inch pounds.
FAILURE TO COMPLY COULD RESULT IN SCREWS STRIPPING OUT.
Phone: (732) 574-1500 • Fax: (732) 574-1551
www.sun-n-funpools.com • E-mail: info@sun-n-funpools.com
ROUND
POOL
ASSEMBLY
INSTRUCTIONS
DANGER
DO NOT DIVE OR JUMP
into your pool. Your pool is
approximately 4' deep. It is
not designed for diving
or jumping. If you dive or jump
into your pool you run the risk
of permanent injury or death.
Alert all visitors
out all warning
labels supplied.
ADULT SUPERVISION REQUIRED
Part# 420363-16
and family of
this and point

Advertisement

loading
Need help?

Need help?

Do you have a question about the ROUND POOL and is the answer not in the manual?

Questions and answers

Related Manuals for Sunn Fun ROUND POOL

Summary of Contents for Sunn Fun ROUND POOL

  • Page 1 Part# 420363-16 Sun n Fun ROUND Pools POOL ASSEMBLY INSTRUCTIONS GENERAL DANGER Installation of this above ground pool is not extremely hard or confusing, but it is a big job. The secret to installing a DO NOT DIVE OR JUMP pool so that it will give you years of pleasure is to take the into your pool.

  • Page 2: Local Codes

    CONTRACT INSTALLATIONS The manufacturer is in no way affiliated with any professional pool installer. Therefore the manufacturer can assume no responsibility for errors in installation by the home owner or said professional installer. If you have your POOL installed by others, please supervise them to be sure they comply with the proper installation techniques shown. Their past expe- rience or short cuts may not cover the latest improvements in our POOLS.
  • Page 3 • During night time pool use, artificial lighting shall be used to illuminate all safety signs, ladders, steps, deck surfaces and walks. • The installer shall follow written instructions provided for operation of the circulation Screwdriver system. • Decks shell meet local codes and comply with ANSI/NSPI-8 1996 “Model Barrier Code for Residential Swimming Pools, Spas and Hot Tubs”...
  • Page 4 INSTALLATION • ASSEMBLY STEPS READ CAREFULLY BEFORE STARTING POOL ASSEMBLY CONSTRUCTION CLOSE-UPS Use the illustrations below as a guide for the assembly of your pool DELUXE POOLS 6” 6” PRINCETON DELMAR with Box Vertical QUANTUM ELAN • OMNI ZENITH • ST. CROIX LEXINGTON POOLS POOLS...
  • Page 5 INSTALLATION • ASSEMBLY STEPS READ CAREFULLY BEFORE STARTING POOL ASSEMBLY CONSTRUCTION CLOSE-UPS Use the illustrations below as a guide for the assembly of your pool 6” 7” XL POOLS EXTRUDED 9” POOLS ALUMINUM POOLS with Column with Box Vertical Vertical Fig.
  • Page 6 INSTALLATION • ASSEMBLY STEPS READ CAREFULLY BEFORE STARTING POOL ASSEMBLY CONSTRUCTION CLOSE-UPS Use the illustrations below as a guide for the assembly of your pool SUPREME POOLS 7” XL POOLS DELUXE POOLS with with Column Vertical with Column Vertical & Wrap Around Covers &...
  • Page 7 PREPARING THE GROUND Your pool must be installed on a solid level surface. Drive a stake into the ground at the center of your pool location. Use a length of string tied to the center stake, see clearance chart for your size pool, and mark the area using a can of spray paint or flour.
  • Page 8 BOTTOM RAILS CENTER STAKE BOTTOM RAIL BOTTOM RAIL VERTICAL BOTTOM PLATE PRE WASHED SAND OR BOTTOM PLATE SIFTED EARTH RECOMMENDED OPTIONAL REQUIREMENT CHART PATIO BLOCK GROUND SHIELD 1/16” 12 ft. 1.4 Tons 1.1 Yards 15 ft. 1.9 Tons 1.5 Yards Ground Shield and Wall Guard are optional.
  • Page 9 CLOSING THE WALL 3/8" TRUSS 1/4" x 20 x 3/4" HEAD SCREW TRUSS HEAD 4 CLOSURE SCREW WASHER BARS INSIDE OF POOL 1/4" x 20 View from SERRATED WASHER FLANGE NUT the top 3/8 FLANGE DANGER YOU MUST ASSEMBLE THE POOL WALL DANGER Recessed...
  • Page 10 PROTECT YOUR LINER way from top to bottom of wall. If the filter inlet and WALL INSIDE OF SKIMMER POOL VIEW RETURN FITTING SEAM outlet are not used, cover over the pre-scored areas on the inside of the pool wall with 1 layer of tape. VIEW FROM SKIMMER If your Pool Wall has the...
  • Page 11 THRU-THE-WALL SKIMMER IMPORTANT!! BEFORE CONTINUING WITH THIS STEP YOU MUST KNOW WHICH TYPE OF THROUGH THE WALL SKIMMER YOU WILL BE USING WITH YOUR POOL Your pool wall has cutouts to accomodate both standard size skimmers and deluxe wide mouth skimmers.

  • Page 12: Liner Installation

    LINER INSTALLATION CAUTION LINER YOUR POOL IS DESIGNED TO PROVIDE AN AMPLE SAFETY MARGIN WHEN IT STANDS ON LEVEL GROUND. FOR THIS PURPOSE A SLOPE IN EXCESS OF 2 INCHES IN ANY DIRECTION WALL TO WALL IS CONSIDERED OFF LEVEL YOUR POOL WARRANTY ONLY APPLIES TO POOLS INSTALLED ON LEVEL GROUND AS DEFINED ABOVE.
  • Page 13 EZ HOOK LINER INSTALLATION ATTENTION: An 8 inch cove must be placed all around the inside of the pool 1. Clear all sticks and sharp objects from an area near the pool, OPTIONAL that is as large as the pool itself. Remove the liner from its WALL carton and unfold and open the liner.
  • Page 14 PRE-ASSEMBLY OF TOP PLATES* * NOTE: CAGE NUTS NOT NEEDED ON ALL POOLS - CHECK YOUR PACKING LIST Before the top plates are installed it is necessary to attach the cage nuts* in their appropriate locations as shown in the figures at right. Using a pliers, squeeze together the spring sides of the cage TOP PLATE...
  • Page 15 RAIL Insert two rails into a plate, in No. 12 x 1/2” the same manner and using the Sheet Metal Screw same spacing as you have done on the bottom rail and plate assembly. Push the rails PLASTIC TOP PLATE and plate assembly onto the plastic edging leaving the EDGING far end in the air.
  • Page 16 INSTALLING LEDGES AND PLACEMENT OF WARNING LABELS SCREW HOLE LOCATION GUIDE Refer to the "Construction Close-ups" at the 12 ft. 15 ft. 18 ft. 21 ft. 24 ft. 27 ft. 30 ft. beginning of these Instructions as indicated below: ROUND ROUND ROUND ROUND...
  • Page 17 INSTALLING TOP COVERS FOLLOW THE INSTRUCTIONS BELOW FOR THE COVERS FOR YOUR PARTICULAR POOL 4", 6" & 7" DELUXE TOP COVERS These covers don’t require cage nuts or top cover screws. For pools with the new 1-piece deluxe top covers, simply snap the cover into place, aligning the tab on the bottom of the cover with the slot in the top plate of pool (fig.A only.)
  • Page 18 6" & 7" TWO-PIECE FULL CONTOURED COVER Slide inside cover (the cover which will be closest to the inside of the pool) into position and place outside cover onto top of inside cover aligning the holes together with cage nut attached to the top plate and secure using the 1/4”-20 x 3/4”...
  • Page 19 7" AND 9” TWO-PIECE WRAP AROUND COVER AND PEDESTAL Slide the inside cover (the cover which will be closest to the inside of the pool) into position and align the hole in the cover with the cage nut attached to the top plate. Secure using the 1/4”-20 x 3/4”...
  • Page 20 7" XL TWO-PIECE WRAP AROUND COVER AND PEDESTAL 1 - Insert the logo into the cover. 2 - Slide the outside cover into position and align the hole in the cover with the cage nut attached to the top plate. Secure using the 1/4”-20 x 3/4”...

  • Page 21: Warning Labels

    WARNING WARNING LABELS Four (4) danger labels have been provided for your safety. Apply these labels to the pool where they are easily visible to all persons using the pool. To do this, simply peel the backing off the label to expose the self stick back and firmly press to a conspicuous and plainly visible surface on the pool.
  • Page 22 SAFETY TIPS - RULES AND REGULATIONS This section is designed to acquaint you with some guidelines as to the safe operation and use of your pool. • Do not dive or jump into your pool. Your pool is approximately 48" or 52” deep. It is not designed for diving or jumping.

  • Page 23: Preventative Maintenance Tips

    PREVENTATIVE MAINTENANCE TIPS • Use clear lacquer or clear nail polish to cover screw heads. • Use clear lacquer or nail polish to cover any scratches on ledges or verticals to prevent rust and corrosion. • Use wax to protect the pool wall and frame from the elements. •...
  • Page 24 HOW TO KEEP WATER CLEAR AND HEALTHFUL Your health, and maximum enjoyment is assured by keeping your pool water in sparkling clear and sanitary clean condition. In order to obtain this condition certain equipment and chemicals available at your pool dealer are necessary. Equipment, such as a filter according to the size of your pool, skimmer and a vacuum cleaner will take care of removing suspended particles, leaves and oils from the water.
