MAF40BKR
WARNING: Use of this mount with a TV weighing over 40 lbs. or with a
screen larger than 27" could cause the mount to fail causing property
damage and/or personal injury.
CAUTION:
This wall mount is intended for use only with the maximum weight of
18 kg/40 lbs. Use with heavier than the maximum weights indicated may
result in instability causing possible injury. Follow the installation and
operation instructions carefully.

Safety precautions

Follow these precautions to ensure safe installation and mounting of your fl at panel TV.
1.
Be sure you have purchased the correct wall mount for your TV. Recheck the
size and weight constraints.
2.
Gather all necessary tools before you begin installation. You will need a #3 bit
Phillips screwdriver, electric drill, drill bit (included), level (integrated level on
product), stud fi nder, and hammer (for brick and concrete installations).
3.
It is essential for the wall mount plate to be attached to wall studs.
(Use a stud fi nder.)
4.
Use the included hardware for mounting purposes. This hardware has been
provided to ensure a safe and secure mount.
5.
Hire a licensed electrician to relocate an electrical outlet, if needed.
6.
Be sure to purchase wires long enough to connect the TV to the audio and
video components in your installation.
7.
We recommend you hire a professional installer, if you have any concerns
about installing the TV wall mount yourself.
Keep your sales receipt to obtain warranty parts and service and for proof of
purchase. Attach it here and record the model number.
Model No. _____________________________________________________________
Purchase Date: _________________________________________________________
Dealer/Address/Phone __________________________________________________
fl at panel solutions
LCD TV Wall Mount

Installation Manual

Fits TVs 13"- 27"
Maximum Load Capacity – 40 lbs. (18 kg)
Thank you for choosing a Universal
Flat Panel TV Wall Mount from RCA.
This mount can be used for all major
brands of 13" - 27" fl at panel TVs,
40 lbs (18 kg) or under. This wall
mount features a 0-15-degree tilt,
180-degree pan and swivel, and
double swing arm extension for easy
viewing. Before attempting to mount
your television set, please remove
all parts from this package and read
the installation instructions carefully.
Attaching wall
Drywall Installation
1.
Use a stud fi nder to loca
NOTE: It is required that
2.
Locate center of stud.
3.
Place the wall mount pla
channel towards the bot
locations on the wall whe
4.
Drill holes at each marke
5.
Secure the wall mount p
completely tighten it yet.
6
. Using the integrated bub
is level.
7.
Insert the remaining scre
Concrete/Brick Installatio
1.
Place the wall mount pla
channel towards the bot
2.
Using the integrated bub
used for securing the mo
3.
Place the wall mount pla
4.
Using an electric drill and
locations.
5.
Remove any excess dus
6.
Insert a concrete anchor
tap each anchor into pla
7.
Once both anchors are in
Using the integrated bub
is level.
8.
Attach the wall mount pl
9.
Make sure all screws are
Attaching the T
1.
Unplug your fl at panel TV
IMPORTANT: NEVER la
viewing surface.
2.
Before attaching the TV
use. Examine the back o
If your TV has a recessed
spacers.
3.
After you have determine
the back of your TV.
NOTE: Be careful not to
Attaching the T
mount plate
