Page 1: Air Conditioner
CPIN_518-2 15/9/04 5:08 PM Page 1 1 HP Refrigerated Portable Air Conditioner Instruction Manual PA9000 IMPORTANT: Please read these instructions carefully before use. Due to continuous research and development the specifications herein are subject to change without notice. -
Page 2: Safety Instructions
CPIN_518-2 15/9/04 5:08 PM Page 2 SAFETY INSTRUCTIONS ENERGY SAVING TIPS • DO NOT use this unit for functions other than • Use the unit in the recommended room size those described in this instruction manual of up to 20m (assuming standard 2.4m ceiling height) •... - Page 3 CPIN_518-2 15/9/04 5:08 PM Page 3 IDENTIFICATION EASY FIT ADAPTOR KIT 1. Air conditioner adaptor 2. Air outlet duct 3. Foam strips – for filling the open window space including hole for connection to air outlet duct 4. Round connector 5.
- Page 4 CPIN_518-2 15/9/04 5:08 PM Page 4 ASSEMBLY Temporary Location The air outlet duct maybe fitted directly into the circular opening of the foam strip Fitting the air outlet duct supplied to provide a temporary type This air conditioner is required to have installation in a window opening.
-
Page 5: Operation
CPIN_518-2 15/9/04 5:08 PM Page 5 OPERATION Setting Temperature Turn the thermostat to regulate the desired temperature from 18 to 32 Control Panel Maximum cooling is obtained when knob is rotated to fully clockwise position. NOTE: The cooling system (compres- sor) will switch off when the ambient temperature becomes lower than the preset temperature. -
Page 6: Maintenance
CPIN_518-2 15/9/04 5:08 PM Page 6 5. Repeat steps 2,3 & 4 until the water is MAINTENANCE completely drained. Important Note: Always unplug the 6. Replace the rubber plug and drain cap. unit from the mains before The Full Water indicator should now be maintenance or cleaning off. -
Page 7: Troubleshooting
CPIN_518-2 15/9/04 5:08 PM Page 7 TROUBLESHOOTING Unit does not operate Is the unit plugged in? Is the power outlet switched on? Is the Full Water indicator on? (If so empty the condensed water) Unit does not seem to cool effectively Is the room too large? Is there direct sunlight onto the unit? (close curtains and pull down blinds) - Page 8 Arlec’s recommendations and within such voltage and current limits as are specified by Arlec in relation to the product. Arlec will at its own option make good, replace with the same or similar product, or provide credit for any product...
