Installation and Operation Instructions
for USA
Models – HF-577DU
Safety Notice: If this solid fuel room heater is not properly installed, a house fire may result. For your
safety and to reduce the risk of fire, follow the installation directions. Contact local building, fire
officials, or the authority having jurisdiction about restrictions and installation inspection
requirements in your area. Kindly save these instructions for future reference.

VERY IMPORTANT

PLEASE READ THIS ENTIRE MANUAL BEFORE YOU INSTALL AND USE YOUR NEW ROOM
HEATER. FAILURE TO FOLLOW INSTRUCTIONS MAY RESULT IN PROPERTY DAMAGE, BODILY
INJURY, OR EVEN DEATH. FAILURE TO READ AND FOLLOW THESE INSTRUCTIONS BEFORE
YOU PROCEED MAY RESULT IN DAMAGE, VOIDING YOUR WARRANTY!
HOT WHILE IN OPERATION. KEEP CHILDREN, CLOTHING, AND FURNITURE AWAY. CONTACT
MAY CAUSE SKIN BURNS.
Please contact the
dealer in your area if
you have any questions about your stove that are not
covered in this manual.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HF-577DU and is the answer not in the manual?

Questions and answers

Related Manuals for Horse Flame HF-577DU

Summary of Contents for Horse Flame HF-577DU

  • Page 1: Very Important

    Installation and Operation Instructions for USA Models – HF-577DU Safety Notice: If this solid fuel room heater is not properly installed, a house fire may result. For your safety and to reduce the risk of fire, follow the installation directions. Contact local building, fire officials, or the authority having jurisdiction about restrictions and installation inspection requirements in your area.

  • Page 2: Table Of Contents

    This instruction manual has been developed to ensure optimum performance from the Horse Flame® stove and fireplace range. It's very important that you thoroughly read and understand all instructions before using your new stove or fireplace.

  • Page 3: Stove Safety

    Stove Safety When properly maintained and operated your stove should give you many years of service. However there are important safety aspects of these products that you need to be aware of when operating a wood stove. 1. Only use solid wood fuel. Never use gasoline, gasoline-type lantern fuel, kerosene, charcoal lighter fluid, naphtha, engine oil, or similar liquids to start or „freshen up‟...

  • Page 4: Before Installing Your Stove

    Check Building Codes When installing, operating and maintaining your stove, follow the guidelines presented in these instructions, and make them available to anyone using or servicing the stove. Your city, town, county or province may require a building permit to install a solid fuel burning appliance. In the U.S., the National Fire Protection Association‟s Code, NFPA 211, Standards for Chimneys, Fireplaces, Vents and Solid Fuel Burning Appliances, or similar regulations, may apply to the installation of a solid fuel burning appliance in your area.

  • Page 5: Installation

    Installation Unpacking and preparing your stove for installation. Remove your stove from the outer packaging and place on floor. Please inspect stove and check that it is not damaged in any way. Never attempt to use a stove that has been damaged.

  • Page 6: The Floor Protection

    Remove hob and lay it upside down on soft surface, remove hob blanking plate from underside of hob by taking out 2 screws, remove flue blanking plate from top outlet and fit to back outlet making sure it is properly sealed with ceramic rope or approved fire cement.

  • Page 7: Installation Clearances

    Installation Clearances It is extremely important that you respect required installation distances and that you respect local installation regulations. This is for your safety! The manufacturer is not responsible for the product, if it is not installed following these recommendations. These clearances may only be reduced by means approved by the regulatory authority.

  • Page 8: Well Sealed Flue System

    Well sealed flue system Only materials and items approved for solid fuel stoves should be used for your stove. Under no circumstances should you use aluminum or galvanized steel pipes for your stove flue. Always fit pipes with the narrow side down, this allow any creosote to run down the inside of the pipe and not to come out and cause an unsightly mess and possible fire hazard.

  • Page 9: Chimney

    This prevents any amount of condensed or liquid creosote from running down the outside of the pipe or the stovetop. All joints, including the flue collar connection must be secured with three sheet metal screws to ensure that the sections do not separate. For the best performance the chimney connector should be as short and direct as possible, with no more than two 90...

  • Page 10: Factory Built Chimney

    Factory Built Chimney When a metal prefabricated chimney is used, the manufacturer‟s installation instructions must be followed. You must also purchase (from the same manufacturer) and install the ceiling support package or wall pass-through and “T” section package, firestops (where needed), insulation shield, roof flashing, chimney cap, etc.

  • Page 11: Masonry Chimney

    Masonry Chimney Ensure that a masonry chimney meets the minimum standards of the National Fire Protection Association (NFPA) by having it inspected by a professional. Make sure there are no cracks, loose mortar or other signs of deterioration and blockage. Have the chimney cleaned before the stove is installed and operated.

  • Page 12: Combustible Wall Chimney Connector Pass-Throughs

    Combustible Wall Chimney Connector Pass-Throughs Method A. 12” (304.8 mm) Clearance to Combustible Wall Member: Using a minimum thickness 3.5” (89 mm) brick and a 5/8” (15.9 mm) minimum wall thickness clay liner, construct a wall pass-through. The clay liner must conform to ASTM C315 (Standard Specification for Clay Fire Linings) or its equivalent.

  • Page 13: Operating Your Stove

    Operating Your Stove Do not use a grate, andiron or other fuel support method. Build fire directly on the hearth. Only open door to fuel/refuel the stove. Excess air can cause the stove to over fire. Do not over fire, if chimney or stove is glowing red you are over firing. Do not build the fire too close to the glass.

  • Page 14: Refueling

    Refueling Before refueling your stove, turn the air supply to high for a few moments until there is a good fire in the stove. This will ensure there is no build-up of harmful gases in the stove when the door is opened and will also get the new fuel burning quickly and not allow it to kill the fire.

  • Page 15: Stove Maintenance

    When you return to your stove, fully open both air controls until you have a good fire and then set to normal operating levels. Do not add fuel until the fire bed is hot and red. Then add a little for the first time and allow that to ignite before adding more. During overnight burning, the stove glass will blacken, but when a hot fire is established again this should burn off.

  • Page 16: Replacement Of Glass

    Do not operate with broken or cracked glass. If the glass does crack when the stove is lit, let the fire die out. Do not open the door until the stove has fully cooled. Replace the glass only with the specified replacement part before re-using the stove. Replacement of glass Remove the door from the stove and place on a flat surface.

  • Page 17: Surface Finish

    1. Hob 2. Top Frame Casting 3. Black Sealing Tape 4. Right-Hang Plate 5. Boiler 6. Adiabatic Felt 7. Back Baffle 8. Black Sealing Tape 9. Glass 10. Glass Holding Frame 11. Right Door 12. Left Door 13. Ash Lip 14.

  • Page 18: Trouble Shooting

    Trouble Shooting Fire not burning A stove not burning is generally caused by either a shortage of air and/or incorrect or damp fuel. If fuel is not the problem check:  That the air controls are opened.  There is no blockage in the flue system. ...

  • Page 19: Chimney Fire

    Chimney fire Chimney fires occur when soot and creosote that have built up in the flue system ignite. If the stove is operated properly and the flue checked and cleaned regularly then chimney fires should not occur. These fires can be very dangerous and must be avoided. Try to maintain good, hot fires in the stove whenever possible and at least once in every firing open the air controls and allow the stove to burn on full for a short while until the entire fire bed is glowing red.

  • Page 20: Horse Flame Warranty

    Horse Flame will repair or replace (parts and labor) at its option, any stove or fireplace insert or part thereof found to be defective.
  • Page 21 Please contact the Horse Flame dealer in your area if you have any questions about your stove that are not covered in this manual. Horse Flame Metal USA, Inc. 111 Larchmont Acres Larchmont, NY 10538 All rights reserved for this booklet which may not be copied in whole or partially without the prior permission of Horse Flame manufacturer.
