- Page 1 Art. 52WS/4 Net Video Server INSTALLATION AND OPERATION MANUAL Product is according to EC Directive 2004/108/CE, 2006/95/CE and following norms. 8/2012 RL.00 Cod. S6I.52W.S4E...
-
Page 2: Table Of Contents
CHAPTER 3 CONFIGURATION VIA WEB BROWSER................11 CHAPTER 4 FREQUENT ASK QUESTIONS..................11 SAFETY FOR THE INSTALLER........................12 Thanks for purchasing the products of Elvox. If you have any requests or questions, please contact us immediately. This manual is applicable to 52WS/4 Net Video Server. -
Page 3: Chapter 1 Introduction
Chapter 1 Introduction 52WS/4 net video server adopts embedded Linux operation system (RTOS) and TI DaVinci processor that is completely independent of PC platform, and efficiently improves system performance. Firmware is burned into the FLASH, making the system more steady and reliable. -
Page 4: Chapter 2 Installation
52WS/4 Chapter 2 Installation Hardware installation 2.1.1 Installation steps 1. Open packing case, and check the integrity; 2. Take out things needed during installation; 3. Connect cables needed (video signal input cable, audio signal input cable, RS485 cable and cable for LAN);... -
Page 5: The Pin Definition Of Physics Interfaces
52WS/4 Back panel: Interface Instruction (From left to Right in return): Power jack is connected with 12V direct current through voltage stabilizer; Please use the stabili- zer power supply correctly; UTP network connector; 4 external alarm input and 2 relay output;... - Page 6 52WS/4 (2) 25-pin to 9-pin converter’s internal connection is like this: 6/12...
- Page 7 52WS/4 (3) If you don’t want to use 25-pin to 9-pin convertor to connect DVS and DTE through RS232 interface, you must use RJ45-DB9 cable. Its internal connection description is: (4) When the RS232 interface of the DVS connects with the DCE (such as MODEM), one end of the cable is the 8-pin RJ45 connector and the other is the DB25 male connector.
-
Page 8: Pin Definition Of Rs485 Serial Interface
52WS/4 2.3.2 PIN definition of RS485 serial interface 2.3.3 PIN definition of Ethernet interface (1) PIN definition of the direct network cable connecting DVS and HUB: (Bianco - Arancio) (Arancio) (Bianco - verde) (Blu) (Bianco - blu) (Verde) (Bianco - Marrone) -
Page 9: Chapter 3 Configuration Via Web Browser
52WS/4 Chapter 3 Configuration via Web browser Before visit the camera via web browser, user should adjust security level. Open the web browser, and enter the menu “Tool/ internet option/Security/Custom level”, then set the security level to Security Level - Low, or enable ActiveX Control and the Plug-in directly. Figure 3.2.1 gives you a visual illustra- tion. - Page 10 52WS/4 The default IP of the camera is 192.0.0.64 with 8000 as the default port, admin as the administrator, and 12345 as the password. The administrator can create up to 15 separate operators with different right le- vels. To login the camera through IE, input the IP address in the address column, and the “Login” dialog box will pop-up as Fig.
-
Page 11: Chapter 4 Frequent Ask Questions
PC, the path to upgrade is incorrect; no permission (usually happened when to upgrade through client-end.) If the above information cannot meet your demand, please not hesitate to contact the provider. Specifications Model 52WS/4 Video compression H.264 Encode/Decode resolution 4CIF/DCIF/2CIF/CIF/QCIF Video input Video input interface BNC (1.0Vp-p, 75Ω), support PAL, NTSC... -
Page 12: Safety For The Installer
200030 Shanghai Cina CERT n° 9110.ELVO ELVOX Costruzioni elettroniche S.p.A. - ITALY Via Pontarola, 14/a - 35011 Campodarsego (Padova) Tel 049 9202511 - Fax 049 9202603 - info@elvox.com www.elvox.com Telefax Export Dept. +39/049 9202601 - elvoxexp@elvox.com UNI EN ISO 9001:2008...
