Page 1
Read all instructions BEFORE assembly and USE of product. KEEP INSTRUCTIONS FOR FUTURE USE. MODEL # 1906CT Patents pending, US Patent# 6,834,915 6,811,216 6,913,313 6,916,066 Shuttle Travel System Instruction Manual Convenience through Innovation and thoughtful design 01.06...
Page 2
4:30 pm Pacifi c Coast Time. Please do not return to the store as once it is returned it cannot be resold and the materials and energy used to make it are wasted. To Contact Us: Baby Trend, Inc. Customer Service Hot Line 1567 S. Campus Ave.
Page 3
PARTS Rear Axle Child Tray Base Locking Cap Rear Wheels Parent Tray Hub Cap Stroller Front Wheels Solid Cap Front Wheels Car Seat Car Seat Rear Wheel Housing TO ENSURE SAFE OPERATION OF YOUR STROLLER, PLEASE FOLLOW THESE INSTRUCTIONS CAREFULLY. RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE. TO ASSEMBLE STROLLER * Remove stroller from box.
Page 4
* To attach the front child tray, push the angled tray onto the post at the end of right armrest, while pressing downward on the snap button, until locked into place. Please see fi gure 7. Rotate the tray downward until latched onto the left armrest.
Page 5
TO SECURE THE CHILD • The shoulder straps of the 5-point harness have 2 attachment positions. Select the position that places the shoulder strap level with, or below the top of the child's shoulder. To access the harness pull apart seat pad. Please see fi...
Page 6
ATTACHMENT OF THE BABY TREND INFANT CAR SEAT * To attach the Baby Trend Infant Car Seat, remove the seat back reclining strap and pass the strap through the loop on the side of the seat, repeat for the opposite side. NOTE: make sure the canopy is pushed forward then rotate each end of the straps to the inside of the canopy frame.
Page 7
FRONT CHILD / CAR SEAT TRAY COVER The cover of the child/car seat tray may be fastened in the closed position after your child outgrows the infant car seat. This will prevent an older child from opening the child tray. To secure the tray cover, remove the tray from the stroller as shown in the to remove front child tray section.
Page 8
CANOPY To open the canopy, push forward on the front frame of the canopy. To Front frame tube close canopy, pull the front edge toward the rear of the stroller until folded. Always fold the canopy prior to folding the stroller frame. Please see fi...
CAUTION: Read the following section completely before folding your stroller! TO FOLD STROLLER * Close the canopy as described in the Canopy section above. Place seat back in fully reclined position by unbuckling recline strap. Pull stroller backward several inches to rotate the front wheels to the front.
Page 10
CLEANING SEAT PAD * The seat pad may be removed for washing. To remove the seat pad, unsnap the two straps on the rear of the seat as shown in fi gure 37. Unfasten the seat belt and pull the waist belts and crotch strap through the cutouts in the pad as shown in fi...
