- Page 1 Read all instructions BEFORE assembly and USE of product. KEEP INSTRUCTIONS FOR FUTURE USE. MODEL # 1836CT Profile Travel System Instruction Manual 08-04 Convenience through Innovation and thoughtful design...
- Page 2 4:30 pm Pacific Coast Time. Please do not return to the store as once it is returned it cannot be resold and the materials and energy used to make it are wasted. To Contact Us: Baby Trend, Inc. Customer Service Hot Line 1567 S. Campus Ave.
- Page 3 PARTS Rear Axle Base Locking Cap Child Tray Rear Wheels Hub Cap Parent Tray Stroller Front Wheels Solid Cap Front Wheels Car Seat Car Seat TO ENSURE SAFE OPERATION OF YOUR STROLLER, PLEASE FOLLOW THESE INSTRUCTIONS CAREFULLY. RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE. TO ASSEMBLE STROLLER * Remove stroller from box.
- Page 4 * To attach the front child tray, push the angled tray onto the post at the end of right armrest, while pressing downward on the snap button, until locked into place. Please see figure 5. Rotate the tray downward until latched onto the left armrest.
- Page 5 Figure 15. ATTACHMENT OF THE BABY TREND INFANT CAR SEAT * To attach the Baby Trend Infant Car Seat, place seat back in the partially reclined position as described in the seat back positioning section following. Please see figure 22 and 23.
- Page 6 FRONT CHILD / CAR SEAT TRAY COVER The cover of the child/car seat tray may be fastened in the closed position after your child outgrows the infant car seat. This will prevent an older child from opening the child tray. To secure the tray cover, remove the tray from the stroller as shown in the to remove front child tray section.
- Page 7 CANOPY To open the canopy, push forward on the front frame of the canopy. To close canopy, pull the front edge toward the rear of the stroller until folded. Always fold the canopy prior to folding the stroller frame. Please see figure 25.
-
Page 8: To Fold Stroller
TO FOLD STROLLER * Close the canopy as described in the Canopy section above. Place seat back in fully reclined position by unbuckling recline strap. Pull stroller backward several inches to rotate the front wheels to the front. Please see figure 28. To fold the stroller slide the red fold lock with your thumb while squeezing the large red fold button in the center of the handle and push downward on the handle. - Page 9 CLEANING SEAT PAD * The seat pad may be removed for washing. To remove the seat pad, unsnap the two straps on the rear of the seat as shown in figure 33. Unfasten the seat belt and pull the waist belts and crotch strap through the cutouts in the pad as shown in figure 34.
