Welltec System Officemate 2D User Manual page 5

Identifying parts
1
Paper Guide
In-feed Pressure
2
adjustment
3
Power
socket
4
2 Fold
nd
Cassette
1
Paper Guide
Load the paper on the guide. (Prepare paper by making edges neat before loading).
2
Press Adjustment
Adjust the pressure for the paper (Adjust sliders to suit paper weight).
3
Power socket
Main power socker located on the back of the machine.
4
2 Fold Cassette
nd
Insert the 2 Cassette on the back of the machine.
nd
5
Roller Cover
Open fold roller cover when jam occurs. (Please turn the Knob in clockwise rotation for unlock).
6
1 Fold Cassette
st
Insert the 1 Cassette for first folding forms.
st
7
Start/Stop
8 Output : Finished forms exit the front of the machine.
9 Stacker
- 5 -
5 Fold Roller Cover
1 Fold Cassette
st
6
7
start/stop
8
Output
9 Stacker
