- Page 1 Dual Phone BTP-0 6L User‘s Guide User‘s Guide User‘s Guide User‘s Guide User‘s Guide - 1 - - 1 - - 1 - - 1 - - 1 - - 1 - XE_BTP-06.ENG.MAN.manual_L.02.A XE_BTP-06.ENG.MAN.manual_L.02.A XE_BTP-06.ENG.MAN.manual_L.02.A XE_BTP-06.ENG.MAN.manual_L.02.A XE_BTP-06.ENG.MAN.manual_L.02.A XE_BTP-06.ENG.MAN.manual_L.02.A XE_BTP-06.ENG.MAN.manual_L.02.A XE_BTP-06.ENG.MAN.manual_L.02.A XE_BTP-06.ENG.MAN.manual_L.02.A XE_BTP-06.ENG.MAN.manual_L.02.A XE_BTP-06.ENG.MAN.manual_L.02.A...
-
Page 2: Table Of Contents
Index Index ................. 2 4. Extended Configuration ........12 4.1 Set-Up and Configuration via PC .........12 1. BTP-06L - Introduction ........2 4.2 Speed dial buttons............13 4.3 Advanced call functions ..........14 1.1 Basic features ..............2 4.4 Bluetooth setting ............14 1.2 Description ..............3 4.5 Phone settings ..............15 2. -
Page 3: Description
1.2 Description New text message indicator Shift key (upper case / lower case) Cellular network signal indicator Cancel (ESC) key Name of currently paired mobile phone Confirm (OK) key Data synchronization in progress Navigation keys Time and date Text messages Mobile phone battery indicator Call history Missed call indicator... -
Page 4: Starting
2. Starting 2.1 Pac�age contents Unpack the phone and check the package contents. ƒ Phone console Phone receiver Connecti ng cord A/C power adaptor USB cable Installati on CD User’s guide Phone cable 2.2 Assembly and po�er up Connect the cord between the receiver and the console. Connect the phone cable to the connector at the ƒ... -
Page 5: Pairing The Btp-06L With Your Mobile Phone
2.3 Pairing the BTP-06L �ith your mobile phone The BTP-06L needs to be connected to your mobile phone by a procedure called pairing. This guide will instruct you in this pairing procedure: Once the BTP-06L is powered up for fi rst ti me (or use Menu > Bluetooth > Add phone ) it automati cally ƒ... -
Page 6: First Use
Please note that the working range for Bluetooth is up to 10 meters. If there are obstructi ons between the BTP-06L and your mobile phone (such as walls, metal objects, etc.) the working range may narrow considerably. Once you have fi nished the pairing, you can use the BTP-06L to make calls instead of your mobile phone. If your mobile phone supports contact and call history synchronizati on, this will start automati cally (as indicated by the symbol BTP-06L... - Page 7 Ꮀ Making a call using your contact list Down RECEIVER Call in progress SPEAKERPHONE - 7 - XE_BTP-06.ENG.MAN.manual_L.02.A...
-
Page 8: Btp-06L Functions
Ꮀ Sending a text message For a plus (+) sign preceding internati onal telephone numbers, press twice. 3. BTP-06L Functions The BTP-06L supports a wide range of Bluetooth profi les: Hands-free profi le ƒ DUN (dial-up networking) ƒ IrMC and SyncML (support for contact synchronizati on) ƒ... -
Page 9: Calls
Main functions Manufacturer Supported mobile phones HP IPAQ 614c, 914c KP500 KE970 Shine, BL-20 Motorola V3 RAZR, KRZR K1, SLVR L7 2700 classic, 5130 XpressMusic, 5310 XpressMusic, 5610 XpressMusic, 5800 XpressMusic, 6300i, 6301, 6500 slide, 6500 classic, 6600i slide, 6700 slide, 7210 Supernova, 7900 Prism, 2323 classic, 2330 classic, 5000, 3720 classic, 6303 classic, 6700 classic, 5630 XpressMusic. -
Page 10: Search Contacts
Ꮀ Synchronized contacts These contacts are copied from your paired mobile phone. If the mobile phone supports contact synchronizati on, you’ll see all of its contacts in the BTP-06L contact list. They’re marked with a mobile phone icon. You cannot add , edit or delete them using the BTP-06L: This is only possible using the mobile phone. -
Page 11: Call History
Please note that the BTP-06L only READS data from your mobile phone’s memory. To prevent any possible unwanted changes in your mobile phone, the BTP-06L never writes anything into your mobile phone‘s memory. To avoid excessive discharging of your mobile phone batt ery, automati c synchronizati on will not be run more than once per hour. -
Page 12: Extended Configuration
4. Extended Configuration 4.1 Set-Up and Configuration via PC Do not connect the BTP-06L to the USB on your computer unti l you have fi nished installing the JabloTool soft ware from the CD! The latest version of the installati on soft ware can be downloaded at www.jablotool.com/download. -
Page 13: Speed Dial Buttons
4.2 Speed dial buttons There are six butt ons on your BTP-06L that can be used for frequently called numbers or emergency numbers. Ꮀ Entering a new number Hold down the selected speed dial butt on for about 2 seconds unti l the phone number: dialog appears. -
Page 14: Advanced Call Functions
4.3 Advanced call functions Some of the advanced call functi ons will not work properly unless they are supported by your provider and paired mobile phone. Ꮀ Call waiting The call waiti ng functi on indicates an incoming call even when another call is in progress. Please check fi... -
Page 15: Phone Settings
Ꮀ Paired phones Shows the list of paired devices and allows you to change the currently acti ve device. Additi onal functi ons (manual synchronizati on, power saving mode acti va- ti on, frequency of synchronizati on ) are available under Options. -
Page 16: Service
4.7 Service The SERVICE menu allows special service actions such as Getting information about the version of hardware and software, MAC address, etc. ƒ Running a special service code ƒ Resetting all internal settings to their factory default values ƒ Activating the internal contact list ƒ... -
Page 17: Technical Specification
6. Technical Specification Dimensions 230 x 220 x 100 mm, weight 900g Display Illuminated graphical LCD 132 x 65 dots, 82 x 40 mm Contacts 500 internal - synchronize with PC, additional 500 entires - synchronize with mobile phone supporting IrMC Sync, SyncML or PBA profiles SMS memory Memory for 100 records of received and sent messages, enabled by mobile phones with DUN profile... -
Page 18: Safety Instructions
6.2 Safety Instructions Read these guidelines. Not following them may be dangerous and/or illegal. You alone are responsible for how you use your device and any consequences of its use. Do not switch the device on wherever the use of a wireless device is prohibited or when it may cause interference or danger. Small Children Do not leave your device and its accessories within the reach of small children or allow them to play with them. -
Page 19: Disposal Information
Do not drop, throw or try to bend your device or its accessories. Do not use harsh chemicals, cleaning solvents, or aerosols to clean the device or its accessories. Do not expose your device or its accessories to extreme temperatures below -10 or above +55 degrees Celsius. Battery and charger handling and safety Use only JABLOCOM approved accessories and batteries. - Page 20 BTP-0 6L Delivery contents: Contact: JABLOCOM s.r.o., Czech Republic support@jablocom.com, www.jablocom.com - 20 - - 20 - - 20 - XE_BTP-06.ENG.MAN.manual_L.02.A XE_BTP-06.ENG.MAN.manual_L.02.A XE_BTP-06.ENG.MAN.manual_L.02.A...
