- Page 1 OWNER’S MANUAL OWNER’S MANUAL OUTDOOR WOOD & COAL FURNACES OUTDOOR WOOD & COAL FURNACES 3000 5,000 5,000e 10,000e 20,000e 3000 5,000 5,000e 10,000e 20,000e Model: Serial #: By; SteelTech., INC. UL 2523 2009 By; SteelTech., INC. UL 2523 2009 UL 391 (1995) UL 391 (1995) Version 2 CAN/CSA B366.1...
- Page 2 MF Series HeatMaster SS Outdoor Furnaces www.heatmasterss.com...
-
Page 3: Table Of Contents
HeatMaster SS Outdoor Furnaces MF Series CONTENTS CONTENTS WARRANTY & SAFETY WARRANTY & SAFETY WARRANTY REGISTRATION AND DELIVERY FORM----------FRONT INSERT WARRANTY-------------------------------------------------------------------1 WATER TREATMENT------------------------------------------------------2 SAFETY PRECAUTIONS--------------------------------------------------3 INSTALLATION & OPERATION INSTALLATION & OPERATION INSTALLATION GUIDE-----------------------------------------------------4 FURNACE CONNECTION-------------------------------------------------6 INTERIOR CONNECTIONS-----------------------------------------------7 OPERATION GUIDE---------------------------------------------------------9 CARE AND MAINTENANCE----------------------------------------------10... - Page 4 MF Series HeatMaster SS Outdoor Furnaces www.heatmasterss.com...
-
Page 5: Warranty
(if the instructions in the owner’s manual for water treatment and maintenance are followed) for The Life of the furnace toward the purchase of a new HeatMaster SS furnace, in the following pro-rated schedule. -
Page 6: Water Treatment
MF Series HeatMaster SS Outdoor Furnaces WATER TREATMENT AND TESTING WATER TREATMENT AND TESTING Water Treatment Policy Water Treatment Policy To qualify for warranty water must be tested a minimum of once per year and water treatment added when necessary. -
Page 7: Safety Precautions
SAFETY PRECAUTIONS Read and understand all precautions before operating the furnace. For Outdoor Installation Only. ATTENTION: A copy of the owner’s manual in French is available by request from Heatmaster ss offices ATTENTION : Save these instructions. Retain this manual as long as you own your HEATMASTER SS furnace. -
Page 8: Installation Guide
HeatMaster SS Outdoor Furnaces Chimney The chimney on your HeatMaster SS outdoor furnace is a stainless steel double wall insulated chimney. It is attached to the furnace with a stainless steel adapter. The draft on the chimney is typically 0.05-0.1”W.C.. To install chimney extensions be sure to purchase the same chimney as on your furnace (Selkirk Ultra Temp). - Page 9 HeatMaster SS Outdoor Furnaces MF Series TRENCH TRENCH SteelTech Inc recommends the trench to be 24” to 36” deep and wide enough to install your water lines. If possible, have a gradual slope in your trench to allow drainage away from your lines and out of trench bottom.
-
Page 10: Furnace Connection
MF Series HeatMaster SS Outdoor Furnaces FURNACE CONNECTION FURNACE CONNECTION Connections to the furnace are clearly marked. Return (from the house) are the top ports, Supply (to the house) are the bottom ports. The installation of isolation valves at both ends of the pump is recommended as well as a valve at the return line. -
Page 11: Interior Connections
HeatMaster SS Outdoor Furnaces MF Series BUILDING CONNECTIONS BUILDING CONNECTIONS A hole large enough to accommodate the water lines, insulation and PVC piping through is important. Attention to sealing this point with a weather proof insulation on both sides is also important. - Page 12 MF Series HeatMaster SS Outdoor Furnaces INTERIOR CONNECTIONS (continued) INTERIOR CONNECTIONS (continued) DOMESTIC HOT WATER DOMESTIC HOT WATER Flat plate exchanger systems used to pre-heat domestic water tanks are generally easier to install, more efficient and more reactive to hot water demands then tube and shell systems. They are mounted on the supply line and use a convection current to heat the water.
-
Page 13: Operation Guide
HeatMaster SS Outdoor Furnaces MF Series OPERATING THE FURNACE OPERATING THE FURNACE FILLING THE FURNACE WITH WATER FILLING THE FURNACE WITH WATER Your furnace has a vent pipe that protrudes through the roof which is used to fill the furnace with water (remember you may need to remove your return line to the furnace and turn on your pump to get the air out of the water lines). -
Page 14: Care And Maintenance
MF Series HeatMaster SS Outdoor Furnaces CARE AND MAINTENANCE CARE AND MAINTENANCE To obtain the high levels of performance of your furnace, certain maintenance procedures are required periodically to avoid soot, creosote and ash buildup. On a daily basis you need to: Check for creosote buildup until experience shows how often cleaning is necessary. -
Page 15: Troubleshooting
HeatMaster SS Outdoor Furnaces MF Series TROUBLESHOOTING TROUBLESHOOTING If the furnace is running but fails to bring water up to temperature: 1. Check fire. 2. Check fan for operation. 3. Check that the solenoid damper is open to allow air injection. - Page 16 MF Series HeatMaster SS Outdoor Furnaces TROUBLESHOOTING TROUBLESHOOTING If there is a power failure: 1. Open all flow-check and zone valves in the system. Depending on the system design, this may allow convective circulation. NOTE: This does not apply to gravity systems, as they have no flow-check valves and will continue to operate normally without electricity.
-
Page 17: Mf-3000 Wiring Diagram
HeatMaster SS Outdoor Furnaces MF Series www.heatmasterss.com - 13 -... -
Page 18: Mf-5000, Mf-5000E, Mf-10000E Wiring Diagram
MF Series HeatMaster SS Outdoor Furnaces www.heatmasterss.com - 14 -... -
Page 19: Mf-20000E Wiring Diagram
HeatMaster SS Outdoor Furnaces MF Series www.heatmasterss.com - 15 -... -
Page 20: Etc Settings & Specs
MF Series HeatMaster SS Outdoor Furnaces Electronic Temperature Control Settings & Specifications Description Step Indicator Description The Ranco electronic temperature control (ETC) is de- F or C Fahrenheit or Celsius Scale signed to provide on/off control for heating and cooling. It... -
Page 21: Warnings Sheet
HeatMaster SS Outdoor Furnaces MF Series www.heatmasterss.com - 17 -... -
Page 22: Replacement Components List
Below is a list of furnace components with part numbers that may need to replaced from time to time. As part of your warranty with Heatmaster ss these components are covered under warranty for the 1 year. These components are available through your dealer. -
Page 23: Footprint Chart
HeatMaster SS Outdoor Furnaces MF Series www.heatmasterss.com - 19 -...
