  • Page 1 Model No. IMEX35080 Serial No. Write the serial number in the space above for future reference. Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or if there are...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS IMPORTANT PRECAUTIONS .............2 BEFORE YOU BEGIN .

  • Page 3: Before You Begin

    Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). To help us assist you, please ¨ mention the product model number and serial number when calling. The model number is IMEX35080. The serial number can be found on a decal attached to the IMAGE ¨...

  • Page 4: Assembly

    ASSEMBLY Assembly requires two persons. Place all parts of the exercise cycle in a cleared area and remove the packing materials. Do not dispose of the packing materials until assembly is completed. Assembly requires the included tools and your own adjustable wrench PART CHART Use the part drawings below to identify the small parts used in assembly.
  • Page 5 1. Attach the Rear Stabilizer (3) to the Frame (1) with four M8 x 55mm Button Screws (63) and four M8 Black Flat Washers (57). 2. Attach the Seat (12) to the Seat Post (13) with four M6 x 15mm Hex Screws (29) and four M8 Black Flat Washers (57).
  • Page 6 5. Hold the Console Base (9) near the Handlebar (16). Insert the wire harness through the indicated hole in the handlebar. Next, connect the two pulse wires to the two Wires (22) extending from the Handlebar. Attach the Console Base (9) to the Handlebar (16) with four Console Screws (20).

  • Page 7: How To Operate The Exercise Cycle

    8. Position the Upper Side Shields (61, 62) around the Handlebar Post (6) as shown. Make sure that the plastic posts shown in the inset drawing are inserted into the upper holes in the Side Shields (4, 5). Attach the Upper Side Shields with three #8 x 19mm Screws (11).
  • Page 8 DESCRIPTION OF THE CONSOLE If there is a thin sheet of clear plastic on the face of the console, remove it. The innovative console offers an impressive array of features to help you get the most from your workouts. When the manual program is selected, you can adjust the resistance of the pedals with a touch of a button.
  • Page 9 In addition to the matrix, the display will show your pedaling speed, the number of Calories you have burned, the elapsed time, and your total distance. The display will also show your heart rate when the pulse sensor is used (see step 5). Note: If your heart rate is not shown, press the reset button to reset the pulse sensor.
  • Page 10 Measure your heart rate if desired Refer to step 5 on page 9. Note: If your heart rate is not shown, press the reset button to reset the pulse sensor. When you are finished exercising, turn off the power To turn off the power, simply wait for about three minutes.

  • Page 11: Maintenance And Troubleshooting

    Measure your heart rate regularly During the program, slow your pedaling speed briefly and measure your heart rate regularly (refer to step 5 on page 9). Each time you mea- sure your heart rate, the resistance of the pedals will automatically increase or decrease, if neces- sary, to keep your heart rate near the preselect- ed percentage of your maximum heart rate.

  • Page 12: Exercise Guidelines

    EXERCISE GUIDELINES WARNING: Before beginning this or any exercise program, consult your physician. This is especially important for individuals over the age of 35 or individuals with pre-exist- ing health problems. WARNING: The pulse sensor is not a medical device. Various factors may affect the accu- racy of heart rate readings.

  • Page 13: Suggested Stretches

    SUGGESTED STRETCHES The correct form for several basic stretches is shown at the right. Move slowly as you stretchÑnever bounce. 1. Toe Touch Stretch Stand with your knees bent slightly and slowly bend forward from your hips. Allow your back and shoulders to relax as you reach down toward your toes as far as possible.

  • Page 16: How To Order Replacement Parts

    Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). To help us assist you, please be prepared to give the following information when calling: ¥ The MODEL NUMBER of the product (IMEX35080) ¥ The NAME of the product (IMAGE ¥...
