Faber INPL3619SS Dimension And Installation Manual

Inca Pro Plus Range Hood
versatile pro liner and hood
All in one Professional Liner from Faber. Available in three widths and two depths depending on your
needs. With the flexibility of four blower options, the Inca Pro Plus offers the power, style and functionality
you need for today's custom pro hood applications.
Model # Size | Color
PICK A SIZE
INPL3619SS 36" W X 19" D
INPL4219SS 42" W X 19" D
INPL4819SS 48" W X 19" D
INPL3622SS 36" W X 22" D
INPL4822SS 48" W X 22" D
PICK A BLOWER
IB300 Internal Blower 300 cfm
IB600 Internal Blower 600 cfm
IB1200 Internal Blower 1200 cfm
RB900 Remote Blower 900 cfm
RB1200 Remote Blower 1200 cfm
Cabinet Cut Out
Convertible to Recirculating
Controls
Lighting
Ducting Top
Grease Filters
AC Input
AC Power (IB300, IB600, IB1200, 900 RB, 1200 RB)
Annual Electricty Costs
* Note – ran 30 minutes a day on low speed, 365 days, using the North American average of 12.2 cents per kWh.
p.o. box 435 • Wayland, MA 01778 • tel: (508) 358-5353 • fax: (508) 358-5730 • e-mail: info@faberonline.com • www.faberonline.com
Performance Range
60 - 300 cfm
60 - 600 cfm
120 - 1,200 cfm
120 - 900 cfm
120 - 1,200 cfm
Feature Chart
34 3/4", 40 3/4", 46 3/4" (W) X 19 3/4" OR 22 3/4" (D)
Yes - charcoal filter needed, need air return back into kitchen
Varible Speed Dial
2 X 45 (W) Halogen with Dimmer
6" Round OR 10" Round
dishwasher safe SS baffle
120 V - 60 hz
2.7, 3.6, 6.2, 1.9, 2.6 A at 310, 420, 730, 220, 300 W
$5.22 / Year * (600 cfm)
Sound Levels
1.0 - 4.0 sones
1.0 - 6.5 sones
2.0 - 12.0 sones
