USER MANUAL
6 PLACE DISHWASHER
TDW6SS
IMPORTANT // Please ensure that you read through this user manual prior to installation and use. This
manual contains important information to ensure optimal performance and keep you safe. Please retain your
proof of purchase, as this will be required in the event that you require warranty service. Remember to retain
this manual for future reference.
www.tisira.com
Advertisement
Table of Contents
Related Manuals for Tisira TDW6SS
Summary of Contents for Tisira TDW6SS
- Page 1 USER MANUAL 6 PLACE DISHWASHER TDW6SS IMPORTANT // Please ensure that you read through this user manual prior to installation and use. This manual contains important information to ensure optimal performance and keep you safe. Please retain your proof of purchase, as this will be required in the event that you require warranty service. Remember to retain this manual for future reference.
- Page 2 HELLO CONGRATULATIONS ON THE SELECTION OF THIS TISIRA APPLIANCE. Please read through this user manual carefully as it contains information that will ensure that your appliance is installed correctly, important operating and care instructions and also some advice of what you need to do if this appliance...
-
Page 3: Table Of Contents
Dear Customer, Please carefully reading it before using the dishwasher will help you to use and maintain the dishwasher properly. Keep it to refer to at a later date. Contro l Panel...........2 Pass it on to any subsequent owner of the appliance. Dishwasher Features........ - Page 4 When using your dishwasher, follow the precautions listed below: This appliance must be grounded. In the event of a Improper connection of the equipment-grounding malfunction or breakdown, grounding will reduce conductor can result in a risk of electric shock. the risk of electric shock by providing a path of Check with a qualified electrician or service least resistance of electric current.
- Page 5 To get the best performance from your dishwasher, read all operating instructions before using it for the first time. Power on light: To come on when Power ON/OFF Rinse Aid Warning Light : To be on when the button is pressed down. rinse aid dispenser needs to be refilled.
-
Page 6: Rinse Aid Dispenser
Rinse Aid Dispenser The rinse aid is released during the final rinse to prevent water from forming droplets on your dishes. That can leave spots and streaks. It also improves drying by allowing water to sheet off the dishes. Your dishwasher is designed to use liquid rinse aids. -
Page 7: Adjusting Rinse Aid Dispenser
Adjusting Rinse Aid Dispenser The rinse aid dispenser has six or four settings. Always start with the dispenser set on "4". If spots and poor drying are problems, increase the amount of rinse aid dispensed by removing the dispenser lid and rotating the dial to "5". If the dishes still are not drying properly or are spotted, adjust the dial to the next higher number until your dishes are spot-free. -
Page 8: Detergent Dispenser
Detergent Dispenser The dispenser must be refilled before the start of each wash cycle following the instructions provided in the Wash Cycle Table . Your dishwasher uses less dete rgent and rinse aid then conventional dishwasher. Generally, only one tablespoon of detergent is needed for a normal wash load. -
Page 9: Cutlery Basket
Consider buying utensils which are ide ntified as dishwasher-proof. Use a mild detergent that is de scribed as 'kind of dishes'. If necessary, seek further information from detergen t ma nufacturers. For particular items, select a p rogramme with a s low a temp erature. To prevent damage, d o not take gla ss a nd c utlery out of the dishwasher immediately after the programme h as ended. - Page 11 Cutlery should be pla ced in the cutlery basket with handles at the bottom. If the rack has side baskets, the spoon should be loaded individually into the appropriate slots, especially long utensils should be placed in the horizontal position at th e front o f the upper b asket as shown. 3 3 3 Soup spoons 2 Forks...
- Page 13 Means: need to fill rinse into the Rinse-Aid Dispenser. AS/NZS2007.1 AS/NZS2007.1*:This program is the test cycle, the rinse-aid dispenser setting is recommended to Position 6. Pre-wash (50℃) Wash (70℃) For the heaviest soiled loads, Rinse such as pots, pans, casserole Rinse dishes and dishes that have 0.94...
-
Page 14: Unloading The Dishwasher
Premise: You can modify the washing program, When the dishwasher just runs for a short time. Otherwise, the detergent may have already been released, and the appliance may have already drained the wash water. If this is the case, the detergent dispenser must be refilled (see the section entitled "... -
Page 15: Filter Assembly
The filter prevent larger remnants of food o r other o bje cts from getting inside the pump. The filter system con sists of a coarse filter, a flat (Main filter) and a micro filte r (fine filter). Main filter Food and soil particles trapped by this filter are pulverized by a spe cial jet on the spray arm and washed down to drain. -
Page 16: Cleaning The Filter
Remarks: - Inspect the filters for blo cking e very time the dis hwa sher has been used. - By unscrewing the coarse filter.you can remove the filter sys tem.Remove any foo d remna nts and clean the filters under running water. The entire filter assembly should be cleaned once a week. -
Page 17: Cleaning The Spray Arms
Cleaning the Spray Arms The spray arms can be easily removed for periodic cleaning of the noz zles , to prevent possible clogging. Wash them under running water and ca refu lly replace them in th eir seats, checking that their rotary movement is in no way impeded . Grasp the mid dle of the spray arm, pull it upwards to remove it. - Page 18 Position the applianc e in the desired location. The back should rest against the wall behind it, and the sides, along the adjacent cabinets or wall. The dishwasher is equipped with water supply and drain hoses that can b e positioned to the right or the left to facilitate proper installation. For personal safety: DO NOT USE AN EXTENSION CORD OR AN ADAPTER PLUG WITH THIS APPLIANCE.
- Page 19 Insert the drain hose into a drain pipe with a minimum diameter of 4cm, or let it run into the sink, making sure to avoid bending or crimping it. Use the spe ial plastic support that comes with the appliance. The free end of the hose must be at a height lower than 75cm and must not be immersed in water to avoid the back flow of it.
-
Page 20: Water Outlet
How to Drain Excess Water From Hoses If the sink is 1000 higher from the floor, the excess water in hoses cannot be drained directly into the sink. It will b e necessary to drain excess water from hoses into a bowl or suitable container that is held outside and lower than the sink. -
Page 21: Technical Problems
Fuse blown, or the Replace fuse or reset circuit breaker. Remove any other circuit breaker tripped. appliances sharing the same circuit with the dishwasher Power supply is not Make sure the dishwasher is turned on and the door is turned on. closed securely. -
Page 22: Wash Cycle Table
The dishes were not See notes in " Loading the Dishwasher Baskets ". loaded correctly. The programme was Select a more intensive programme. not powerful enough. See" Wash Cycle Table . " Not enough detergent Use more detergent, or change your detergent. was dispensed. - Page 23 The dimensions with * variable “ ” according to actual situation ater pressure: 0.04-1.0MPa Power supply: See rating label Capacity: 6 place settings...
- Page 24 Electrical, drain and water supply line entrances, both sides Space of cabinet Step 1a: If only the body into cabinets, please make this map the size of the cabinet hole.
- Page 25 Electrical, drain and water supply line entrances, both sides. Space of cabinet Step1b ： If the entire decorative panel into the cabinet also, the size of a should be equal to D +3.5 + E +6; size b should be equal to C +6; Meanwhile, the cabinet around the inward booster: the bottom of the entire plane for the E-49 +3;...
-
Page 26: Notes
decorative panel (up) decorative panel (down) Step 2 ： Weight of the decorative panel (up) should be min 3Kg-max 4Kg. Dim.A and B could be alterable by handle, Dim.C,D,E and F could be alterable by fact, If you want to make the decorative panels size same as ′... - Page 27 Step 3: Assemble the decorative panels If the m achine with a decorative plate, no this step. Step 4: Assemble the decorative door on the dishwasher, as figure. First install sidepiece screw between base board and decorative panel (down),in all 4; then pull glide from out door groove ,case 8-screw between decorative panels...
- Page 28 Step Install the dishwasher in aperture, but not full, as figure, adjust screw, let its bottom align aperture s base, ’ then push dishwasher full. Step ： Take out cap, a hole revealing , using screwdriver install screw, bothsides. Then recover the cap in hole.
- Page 29 NOTES...
-
Page 30: Proof Of Purchase
PROOF OF PURCHASE ATTACH YOUR PROOF OF PURCHASE FOR FUTURE REFERENCE... -
Page 31: Warranty Terms & Conditions
WARRANTY TERMS & CONDITIONS... - Page 32 CONTACT DETAILS www.tisira.com...
