- Page 1 1590-CUL-ENG Owner’s Manual Ceiling Fan Installation Instructions Total fan weight with light kit For 1590 Series Fans READ AND SAVE THESE INSTRUCTIONS HC-807...
-
Page 2: Installation
1590-CUL-ENG Installation AFETY WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING: READ AND SAVE THESE INSTRUCTIONS Installation work and electrical wiring must be done by qualified person(s) in accordance with applicable codes and standards (ANSI/NFPA 70-1996), including fire-rated construction. - Page 3 1590-CUL-ENG Before installing the remote receiver . Make sure the DIP switches in the Transmitter and receiver are set the same. Use instrument with a sharp point to Install remote receiver by sliding into opening in Carefully lift fan assembly onto mounting move the switches into the proper positions.
- Page 4 1590-CUL-ENG Plug ballast into the fluorescent tube. Install twin circular fluorescent tube to fan. Carefully place fluorescent lamp into clips on fan. (see insert) Light control Battery com- button partment Fan on/off Foward/reve rse button Fan speed controls Install 9v battery by removing battery cover on back of transmitter and connecting to terminals and re-install cover.
-
Page 5: Troubleshooting
1590-CUL-ENG Trouble Shooting If you have difficulty operating your new ceiling fan, it may be the result of incorrect assembly, installation, or wiring. In some cases, these installation errors may be mistaken for defects. If you experience any faults, please check this Trouble Shooting Chart.
