- Page 1 Aussie Pumps Scud & Ultra Series High Pressure Blasters OPERATION & MAINTENANCE MANUAL Covers: Scud 350 Scud 351 Scud 400 Ultra Predator Plus Feb 2012 IMPORTANT: TO REDUCE RISK OF INJURY, READ OPERATING INSTRUCTIONS CAREFULLY BEFORE USING EQUIPMENT...
-
Page 2: Safety Precautions - Important
GUARANTEE … EXCLUSIVE 3 YEAR PUMP + 3 YEAR ENGINE WARRANTY This Aussie Eco Clean product is guaranteed against faults in manufacture for two years from purchase. The Bertolini pump has a three year warranty, but must be serviced by an authorised service agent every six months to maintain this warranty. -
Page 3: Assembly And Preparation For Use
Aussie Pumps Feb 2012 ASSEMBLY AND PREPARATION FOR USE Before proceeding with assembly of your new Aussie Eco AB high pressure blaster, check that all parts listed below are included. 1 Gun handle assembly and high pressure hose 1 Lance and nozzle assembly Machine Preparation (initial start-up) Check the oil in the pump and gearbox. -
Page 4: Hose Connections
Fitting instructions for optional hose reel Securely clamp the hose reel mounting bar across the top of the Scud frame using the two sets of nuts and bolts supplied. Aussie Pumps recommends using Loctite on the bolts to prevent them vibrating loose. -
Page 5: Pressure Washing
Hoses may now be disconnected from the machine. Failure to release pressure before disconnecting the hose quick coupler will result in the quick coupler o-ring seal blowing out. This o-ring must be replaced before operating machine. Aussie Scud & Ultra … Operation & Maintenance Manual... -
Page 6: Care And Maintenance
DO NOT siphon chemicals through the pump, it is designed for water only. Incoming water supply must not exceed 60ºC, otherwise pumps seal damage could result Follow engine manufactures guidelines for engine maintenance. (see engine manual) Aussie Scud & Ultra … Operation & Maintenance Manual... -
Page 7: Troubleshooting Guide
Engine will not start Out of fuel Fill tank with petrol/diesel Engine defect Return to engine service agent For engine troubleshooting refer to the engine manufacturer’s handbook. Aussie Scud & Ultra … Operation & Maintenance Manual... -
Page 8: Parts Identification
2500 1450 ABBSC400/GX390 Scud 400 Honda 13HP GX390 TTL1330 4000 1450 ABBULTRA/GX620G Ultra Honda 20HP e/s GX620 KTV3021 4000 1450 Predator Plus ABPREDATORPLUS Honda 28HP e/s GX690 RAL 2035H 5000 1450 Aussie Scud & Ultra … Operation & Maintenance Manual... -
Page 9: Replacement Parts
13" WHEEL Engine Mounts AENGINEMOUNTS300 ENGINE MOUNTS (4 NEEDED) Order the right part first time … specify the pump model number when ordering parts. Full parts breakdown available online … www.aussiepumps.com.au Aussie Scud & Ultra … Operation & Maintenance Manual... - Page 10 Aussie Pumps Feb 2012 PUMP PARTS TTL 1520 TTL 2120 (SCUD 350. SCUD 351) Kit No. Part No. Description Pieces B069872973 Oil Seal & Sight Glass Kit B069867973 Valve Kit B069839973 Seal Kit Minor B069836973 Seal Kit Major B069814973 Oil Seal Kit...
- Page 11 B049839973 CAP KIT B89817973 O-RING & SIGHT GLASS KIT Order the right part first time … specify the pump model number when ordering parts. Full parts breakdowns available online … www.aussiepumps.com.au Aussie Scud & Ultra … Operation & Maintenance Manual...
- Page 12 Check all HP components for leaks: Gun/lance, HP hose and all fittings Replace nozzles Check gearbox to engine key for wear, if key is worn see your local Aussie Eco Clean Service Department. NB Damage generated by worn keys is not covered by warranty.
